- Page 1 APB-112 IW-D-USB Press Conference Audio Distribution Amplifier Owner’s manual...
- Page 2 Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, re or other hazards. These precautions include, but are not limited to, the following: WARNING Do not open If you notice any abnormality •...
- Page 3 Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the device or other property. These precautions include, but are not limited to, the following: CAUTION • Do not expose the device to excessive dust or vibrations, or extreme cold or heat (such •...
-
Page 4: The Package Contains
Dear customer, APB-112 IW-D-USB APB-112 IW-D-USB is an active AudioPressBox unit with one channel DANTE interface, 8 XLR transformer ballanced and isolated output with The unit is powered directly from Dante network via PoE. It is a PoE Class 3 device. - Page 5 1.) USB-C 4.) Mic/Line switch Mic = -20dBu, Line = + 6dbu XLR Ouputs Eight Individually transformer balanced 5.) Output level indicator and isolated outputs with switchable output level: Mic = -20dBu, Line = + 6dbu. Standard Neutrik 3-pin XLR connector -20dBu Power LED 6.) Dante connector...
- Page 6 Usage APB-112 IW-D-USB is designed for use as a distribution audio ampli er for press conferences. It features APB-112 IW-D-USB is suitable for xed installations with integrated Dante network. applied compressor and limiter to reduce the dynamics of the signal especially for speech.
- Page 7 Set up the levels Set up the output level on your source device to reach the nominal output on APB – 0dB LED APB-112 IW-D on Output Level indicator. You can also set the output level switch for each output as desired –...
- Page 8 Audio Press Box APB-112 IW-D-USB Type 1 in 12 Out Groups Input section Inputs RJ45 - Dante -18dBFS Output section Analog Outputs Outputs 8 Line/MIC level Balanced, XLR +6dBu +20dBu (no load) +14dBu (600Ohm) Output impedance MIC: 220 Ohm LINE: 600 Ohm >70 dB...
- Page 9 Audio Press Box APB-112 IW-D-USB Indicators Output level. Power Power Mechanical 280x138x50mm 2700 g...
-
Page 10: Block Diagram
Block diagram... - Page 11 e-mail: sales@audiopressbox.com | web: www.audiopressbox.com Tel: +421 2 20 999 700...
