- Page 1 APB-116SB Press Conference Audio Distribution Amplifier Owner’s manual...
- Page 2 IMPORTANT NOTICE FOR THE UNITED KINGDOM Connecting the Plug and Cord IMPORTANT. The wires in this mains lead are coloured in accordance with the following code: BLUE : NEUTRAL BROWN : LIVE As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured makings identifying the terminals in your plug proceed as follows: The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
- Page 3 Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following: WARNING Do not open Water warning •...
- Page 4 Dear customer, Thank you for purchasing AudioPressBox® APB-116SB, the most sophisticated press conference distribution amplifier. Signal from four lectern’s microphones or line inputs (i.e. mixing console) is distributed to independent microphone/line outputs used by multiple journalists, TV Camera operators, audio recorders and reporters at the same time. No more hassle with the multiple microphones on the table or disturbing late-coming reporters.
- Page 5 If Comp switch is set to ON, you can XLR balanced connector. visually monitor the level of Gain redu- ction on this 4-segment indicator bar. 2) Input gain level knob APB-116SB Input your LINE-level source into this 6) Power ON indicator XLR balanced connector. When AudioPressBox® is turned on,...
- Page 6 APB-P112SB - Top panel (Output section) 9) MIC/LINE Outputs 1-16 MIC/LINE level output XLR connectors – every output is individually transformer isolated. 10) MIC/LINE level select switch Balanced Isolated Outputs You can set if you want to get Mic (-20dBu) or Line (+6dBu) level from Line Line Line Line individual output. Line Line Line Line Line Line Line Line Line Line Line Line Balanced Isolated Outputs APB-116SB...
-
Page 7: Specifications
Specifications Audio Press Box APB-116 SB Type 1 in 16 Groups Input section Inputs Input connectors Balanced, XLR Max. input level Line: +32/+2dBu Input Impedance >5kOhm Output section Outputs 16 MIC/LINE level Output connectors Balanced, XLR Nominal Output Level -6/ 0/ +4/ +6 dBu +22dBu (no load) Maximum Output Level +16dBu (600kOhm) Output impedance Mic: 220 Ohm Line: 600 Ohm Transformer isolated outputs: Yes (each output) - Page 8 e-mail: sales@audiopressbox.com | web: www.audiopressbox.com MediaTech Central Europe, a.s., Drienova 34, 821 02 Bratislava, Slovak Republic (EU) Tel: +421 2 4341 7777 | Fax: +421 2 4342 7777...
