Model #AR-3001xx-52
USE AND CARE GUIDE
52"RAVIAN™ CEILING FAN
Questions, problems, missing parts?
Contact Customer Service by e-mail at
Support@Arranmorelighting.com
THANK YOU
We appreciate the trust and confidence you have placed in Arranmore Lighting Company,LLC through the purchase of this
ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us on-line at https://
arranmorelighting.com to see our full line of products available for your home improvement needs.
Thank you for choosing Arranmore!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAVIAN AR-3001 52 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ARRANMORE RAVIAN AR-3001 52 Series

Summary of Contents for ARRANMORE RAVIAN AR-3001 52 Series

  • Page 1 Support@Arranmorelighting.com THANK YOU We appreciate the trust and confidence you have placed in Arranmore Lighting Company,LLC through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us on-line at https:// arranmorelighting.com to see our full line of products available for your home improvement needs.

  • Page 2: Important Safety Instructions

    Important Safety Instructions WARNING: To avoid fire, shock and serious personal injury, follow these instructions. 1. Read your owner’s manual and safety information before installing your new fan. Review the accompanying assembly diagrams. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power from being switched on accidentally.

  • Page 3: Table Of Contents

    All costs of removal and re-installation of the fan are the sole responsibility of the owner of the fan and not the retailer that sold the fan or Arranmore Lighting Company, LLC. Arranmore reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty.

  • Page 4: Package Contents

    Package Contents NOTE: Hardware not shown to actual size. Reference # Description Quantity Mounting bracket (preassembled) Canopy Canopy bottom cover (preassembled) Downrod Coupling cover Blade support plate with screws and lock washers Blade Fan motor assembly Decorative motor cover Decorative cap Receiver + 4 wire nuts Remote control + holder + 2 mounting screws IMPORTANT...

  • Page 5: Hardware Contents

    Hardware Contents Reference # Description Quantity Plastic wire nut Wood screw, screw, lock washer and flat washer Safety cable screw, lock washer and flat washer 1.5V AAA battery 42” 2-pin extension cord (only for use longer downrod up to 48”) 42”...

  • Page 6: Initial Installation

    Initial Installation 1. Turn off circuit breakers and wall switch to the fan supply line leads. (Figure 1) DANGER Failure to disconnect power supply prior to installation may result in serious injury or death. Figure 1 2. Determine mounting method to use. (Figure 2) A.

  • Page 7: How To Assemble Your Ceiling Fan

    How to Assemble Your Ceiling Fan 1. Remove the canopy bottom cover (C) from the canopy (B) by turning the canopy bottom cover (C) counterclockwise. Canopy Mounting Remove the mounting bracket (A) from the canopy Screw Canopy Mounting (B) by loosening canopy mounting screws a half turn Screw from the screw head.
  • Page 8 How to Assemble Your Ceiling Fan (continued) 4. Begin by using the original product packaging to create a base to hold the fan. Place the fan motor assembly (H) with the bottom facing up. (Figure 4) Bring a fan blade (G) to the motor and ensure that “UP”...

  • Page 9: How To Wire Your Ceiling Fan

    How to Assemble Your Ceiling Fan (continued) 7. Carefully lift the fan motor assembly (H) up to the mounting bracket (A) and seat the downrod assembly (D) in the mounting bracket (A) socket. Make sure the tab on the mounting bracket (A) socket is properly seated in the groove in the hanger ball/downrod assembly (D).
  • Page 10 How to Wire Your Ceiling Fan (continued) WARNING Ground To avoid possible electrical shock, be sure Conductor White Black electricity is turned off at the main fuse box before wiring. 1. Push the antenna wire through the mounting Outlet Box bracket (A) and insert the narrow end of the receiver (K) into the slide-on mounting bracket (A) until it rests on top of the ball/downrod assembly.

  • Page 11: How To Install Your Decorative Motor Cover

    How to Wire Your Ceiling Fan (continued) 5. Make sure connections are neatly tucked into the ceiling outlet box. (Figure 3) Slide the canopy (B) up to the mounting bracket (A) and place the key holes on the canopy (B) over the Outlet Box loose canopy mounting screws on the mounting bracket (A).

  • Page 12: How To Install Your Decorative Cap

    How to Install Your Decorative Cap CAUTION Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at the fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. 1.

  • Page 13: How To Operate Your Ceiling

    How to Operate Your Ceiling 1. Remove the battery cover by pressing firmly on the arrow and sliding the cover off. Install two 1.5V AAA batteries (DD) (included). Batteries are to be inserted with the correct polarity. Slide the battery cover on the remote control till it click in place.

  • Page 14: Learning Process

    How to Operate Your Ceiling (continued) Learning Process IMPORTANT This fan has been pre-paired at the factory and the fan can be used now. If you have two or more fans, please follow steps below to control each fan independently. Also follow steps below to re-pair the remote control (L) and the receiver when needed.
  • Page 15 How to Operate Your Ceiling (continued) Power OFF: Press and release the power button to turn the fan off. (Figure 3) 1, 2, 3, 4, 5, 6 Speed functions: 1 = for fan MINIMUM speed 2 = for fan LOWER speed 3 = for fan LOW speed 4 = for fan MEDIUM speed 5 = for fan HIGH speed...

  • Page 16: Installing The Remote Control Holder

    How to Operate Your Ceiling (continued) Installing the Remote Control Holder Attach the remote control holder with the two remote control holder mounting screws. (Figure 6) Remote Mounting Screws Control Holder Figure 6 Care and Maintenance Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time.

  • Page 17: Troubleshooting

    Troubleshooting WARNING Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Reverse switch not engaged. 1. Push switch firmly either left or right. Fan does not move. 2. Power is off or fuse is blown. 2.

  • Page 18: How To Order Repair Parts

    HOW TO ORDER REPAIR PARTS When ordering repair parts, always give the following information: • Part Number • Part Description • Fan Model Number Contact Arranmore Support for replacement parts at Support@Arranmorelighting.com. Parts List Model No. AR-3001xx-52 Reference # Description AR Part#...
  • Page 19 (continued) How to Order Repair Parts Model No. AR-3001xx-52 H + I Part #...
  • Page 20 Questions, problems, missing parts? Contact Customer Service e-mail us at Support@Arranmorelighting.com Retain this manual for fu ture use.
