- Page 1 Operating Instructions Smart Bluetooth Door Lock Item no: 3060830...
- Page 2 Table of Contents Introduction ....................Product documentation................Intended use..................... Delivery contents ..................Description of symbols................Safety instructions ..................General..................Handling ..................Operating environment..............Operation..................Battery..................Product overview ..................Door lock ..................Door lock dashboard ..............Getting started ..................Mobile app ....................Adding the door lock to the mobile app........
- Page 3 11.3 Setting user-level passwords ............11.4 Generating temporary passwords ..........11.5 Generating remote passwords ............. 11.6 Using the passage mode (without authentication) ....... 11.7 Resetting all authentication methods ........... 11.8 Default authentication settings ............. 12 Emergency situations ................12.1 Using the mechanical key to unlock..........12.2 Supplying emergency power............
- Page 4 1 Introduction Thank you for purchasing this product. If there are any technical questions, please contact: www.conrad.com/contact 2 Product documentation The product is documented by different sets of instructions: ■ Installation instructions ■ Operating instructions (for download only) Use the link www.conrad.com/downloads (alternatively scan the QR code) to download the instructions (or new/current versions if available).
- Page 5 The product is dust-protected according to IP5X. The product is intended for indoor use only. Do not use it outdoors. Contact with moisture must be avoided under all circumstances. If you use the product for purposes other than those described, the product may be damaged.
- Page 6 The symbol warns of hazards that can lead to personal injury. 6 Safety instructions Read the operating instructions carefully and especially observe the safety information. If you do not follow the safety instructions and information on proper handling, we assume no liability for any resulting personal injury or damage to property.
- Page 7 ■ If it is no longer possible to operate the product safely, take it out of operation and protect it from any accidental use. DO NOT attempt to repair the product yourself. Safe operation can no longer be guaranteed if the product: –...
- Page 8 7 Product overview 7.1 Door lock Component Description/Notes/Action Outer door handle Password confirmation key After you enter a password/PIN, press the key to confirm your entry and unlock the door. Keypad Enter passwords/PINs. RFID smart card reader Place smart key cards onto the reader to unlock the door.
- Page 9 Component Description/Notes/Action Indicator light The indicator flashes red if an incorrect password/PIN is used. Cylinder Inner door handle ■ USB-C® port If the battery is depleted, supply emer- gency power via a 5 V/DC USB-C® power supply. ■ The USB-C® port is not a charging port. Key hole Insert the mechanical key and turn the key clockwise to unlock.
- Page 10 7.2 Door lock dashboard Component Description/Notes/Action Battery level indicator Replace the door lock battery before the battery is depleted.
- Page 11 Component Description/Notes/Action Unlock button Move the mobile device close to the door, then tap and hold the button until the door lock un- locks. Message area View door lock activity. Member management Manage door lock users. Settings menu Configure security settings and authentication methods.
- Page 12 9 Mobile app 9.1 Adding the door lock to the mobile app After adding the door lock to the mobile app, you can configure and manage the door lock. Note: The user account under which the door lock is registered is automatically the administrator user.
- Page 13 10 Managing users 10.1 User types The administrator can authorize or restrict functions for different user types. Every user is managed by the administrator. User User functions ■ Administrator Perform any function. ■ User without Tuya user ac- Use passwords to unlock. count ■...
- Page 14 Preconditions: The mobile device is connected to the Internet. 1. Open the mobile app and go to the door lock dashboard. 2. Tap the button Member Management. 3. Add a family member or other member. 4. Configure the user. Refer to Configuring users that have a Tuya user account [} 14] for instructions.
- Page 15 Permission Description Password management The user is authorized to add and delete their own passwords. Card management The user is authorized to add and delete smart key cards. Unlock with Mobile Phone The user is authorized to unlock the door lock with their mobile device.
- Page 16 11 Managing authentication 11.1 Using mobile devices to authenticate (unlock) Preconditions: Bluetooth is enabled on the mobile device. The mobile device is near the door lock. 1. Open the mobile app and go to the door lock dash- board. 2. Connect to the door lock by touching the unlock but- ton.
- Page 17 Note: The supplied smart key cards are unique to the door lock. If you have multiple door locks of the same model, you must use the smart key cards that belong to each door lock. Note: You can register your own smart key cards. The door lock supports third-party MIFARE®...
- Page 18 11.3 Setting user-level passwords A user level password belongs to a user that is configured in the mobile app. If the administrator is the only registered user, all user level passwords belong to the ad- ministrator. Preconditions: The mobile device is connected to the Internet. Bluetooth is enabled on the mobile device.
- Page 19 Preconditions: You are authorized to generate temporary pass- words. The mobile device is connected to the Internet. Bluetooth is enabled on the mobile device. The mobile device is near the door lock. 1. Open the mobile app and go to the door lock dash- board.
- Page 20 Important: Be very careful with remote passwords. An individual can keep the password for later use and unlock the door at a point in time that you did not expect. This is possible because the timer that invalidates the password only starts after the individual uses the password for the first time.
- Page 21 3. Under Settings, enable the passage mode by tapping the slider Automatic lock switch to disable the slider. à The lock emits a beep sound. à The unlock button lights orange. à The passage mode is enabled and everyone can open the door. à...
- Page 22 à The door lock will reset all authentication settings and apply the default au- thentication settings. à The door lock is disabled in the mobile app. à The door lock is reset to the default authentication settings. Refer to Default au- thentication settings [} 22] to learn more.
- Page 23 12.2 Supplying emergency power If the battery is depleted, you can use a USB-C® power source to temporarily sup- ply power and use the door lock. 1. Attach the supplied suction cup to the cover. 2. Lightly pull the cover and rotate the cover to the right. 3.
- Page 24 ■ Click on the following link to read the full text of the EU declaration of conform- ity: www.conrad.com/downloads Enter the product item number in the search box. You can then download the EU declaration of conformity in the available languages. 15 Disposal 15.1 Product This symbol must appear on any electrical and electronic equipment...
- Page 25 15.2 (Rechargeable) batteries Remove batteries/rechargeable batteries, if any, and dispose of them separately from the product. According to the Battery Directive, end users are legally obliged to return all spent batteries/rechargeable batteries; they must not be disposed of in the normal household waste. Batteries/rechargeable batteries containing hazardous substances are labelled with this symbol to indicate that disposal in household waste is forbidden.
- Page 26 à The door lock emits a beep sound to confirm that the battery supplies power. 17 Technical data Power supply......1x 3V CR123A battery Idle current........ max. 50 uA Active current......100 mA Emergency power supply ..5 V/DC via USB-C® Lock type Grade........
- Page 27 Smart card encryption ....Crypto-1 Bluetooth authentication Bluetooth protocol..... BLE V4.2 Wireless frequency band..2.402 - 2.480 GHz Wireless range ......max. 15 m Wireless transmission power ... 3.25 dBm Mechanical authentication Mechanical key......Yes Others Ingress protection ....IP5X Operating temperature ....
- Page 28 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
