- Page 1 Installation Guide Steam Adapter Kit / Steam Head for DTV+ Français, page ″Français-1″ Español, página ″Español-1″ 1381955-2-A...
- Page 2 WARNING: Risk of scalding or burning. Stay away from the steam head during operation. The steam head is hot during operation. WARNING: Risk of personal injury or property damage. Avoid coming in contact with the water tank and/or steam 1381955-2-A Kohler Co.
- Page 3 The steam generator operates at high temperatures. NOTICE: Use this unit only for its intended use as specified in this manual. DO NOT use attachments not recommended by Kohler Co. NOTICE: Follow all plumbing, electrical, and building codes. _________________________________________________________________...
-
Page 4: Tools And Materials
Tools and Materials Socket Wrench with 1" Socket Dielectric Grease Drill w/ 3/8", 7/16", & 2-1/2" Hole Saw (match hole saw Sealant 100% Silicone to wall material) Tape Sealant Pipe Nipples 1381955-2-A Kohler Co. -
Page 5: Before You Begin
The steam heads do not need to be located in the same area. Locate the steam head(s) as far away as possible from any shower seating area. Locate the temperature sensor on the wall 5″ (127 mm) down from the ceiling. Kohler Co. 1381955-2-A... - Page 6 Before You Begin (cont.) Make sure that there is adequate clearance between the steam lines and any surrounding surfaces, or apply appropriate insulation to the steam lines. 1381955-2-A Kohler Co.
- Page 7 Download and install the latest software for connected components. This may take an hour or more to complete based on system configuration and internet connection speed. Do not disconnect the power from any component during software download and installation. Kohler Co. 1381955-2-A...
-
Page 8: Prepare The Site
Install the finished wall. Drill or cut a 2-1/2″ (64 mm) hole centered around the elbow in the wall. Mark the temporary pipe nipple at the finished wall surface. Remove the temporary pipe nipple from the elbow. 1381955-2-A Kohler Co. - Page 9 Make sure that the gasket is compressed to achieve a good seal around the housing. If needed, use an appropriate sealant to achieve a watertight seal. Press the steam head into the housing with the well positioned at the top. Kohler Co. 1381955-2-A...
-
Page 10: Install The Temperature Sensor
IMPORTANT! Do not pinch, nail, wedge, or use undue force when handling the sensor wire. Any damage may result in temperature sensor failure. Insert the temperature sensor wire through the drilled hole. Route the wire behind the wall to the steam generator location. 1381955-2-A Kohler Co. - Page 11 Allow the sealant to cure before use. Loop the cable through the ferrite on the adapter end of the cable, and snap the ferrite closed. Use the cable tie provided to encircle and lightly secure the looped cable and ferrite. Kohler Co. 1381955-2-A...
- Page 12 Apply dielectric grease in all the connectors and wires. Connect the 16″ (406 mm) white crossover cable to the steam adapter and the steam generator. Connect the temperature sensor wire to the corresponding port on the steam adapter. 1381955-2-A Kohler Co.
- Page 13 Install the Adapter – Single Steam Head (cont.) Connect the data cable to the steam adapter and route the cable to the controller installation location. Kohler Co. 1381955-2-A...
- Page 14 Connect the 16″ (406 mm) white crossover cable to the steam adapter and the inlet side of the 3-way coupler. Connect the 10″ (254 mm) black straight-through cable to the output side of the 3-way coupler and the first generator. 1381955-2-A Kohler Co.
- Page 15 3-way coupler and the second generator. Connect the temperature sensor wire to the corresponding port on the steam adapter. Connect the data cable to the steam adapter and route the cable to the controller installation location. Kohler Co. 1381955-2-A...
-
Page 16: Complete The Installation
Restore the power at the main breaker panel. For information on system setup and operation, refer to the guide on the controller product page at us.kohler.com. Before Operating the System for the First Time: Download and install the latest software for connected components. -
Page 17: Operation
Failure to initiate power clean after the third reminder will result in the system locking. Power clean must be run to resume steam operation. Kohler Co. 1381955-2-A... -
Page 18: Care And Cleaning
• Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring pad to clean surfaces. For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care & Cleaning information, call 1-800-456-4537. Troubleshooting NOTE: For DTV+ system troubleshooting, refer to the guide on the K-99695 controller product page at us.kohler.com. - Page 19 If (green status light necessary, use the on steam generator provided test kit to is off). ensure that the steam generator is working properly. Kohler Co. 1381955-2-A...
- Page 20 Inspect the cable for damage and replace if necessary. C. An error has C1. Check the error code occurred. on the user interface. See the corresponding error code in this document. 1381955-2-A Kohler Co.
- Page 21 B1. Use the provided test damaged (green kit and instructions status light on to identify the source steam generator is of the problem. on). B2. Call the Customer Care Center using the information provided on the back page of this manual. Kohler Co. 1381955-2-A...
- Page 22 B. The temperature B. Confirm that the setpoint has temperature setpoint already been is greater than the reached. current steam room temperature. Increase the temperature setpoint if desired. 1381955-2-A Kohler Co.
- Page 23 If an error message appears, see the appropriate error message troubleshooting. B. The session time B. Restart the session limit was met or timer or increase the the temperature temperature setpoint setpoint was met. to restart steam. Kohler Co. 1381955-2-A...
