- Page 1 SystemMobile S41T User guide...
-
Page 2: Table Of Contents
SystemMobile S41T ― User guide Contents Symbols, safety .........................................2 General safety information .....................................3 Correct use ..........................................4 Improper use ..........................................4 Personnel qualifications ......................................5 Safety instructions ........................................5 Product description ........................................6 Operating data ...........................................6 Assembly and installation ......................................8 Commissioning and operation ....................................9 Functions ..........................................10 Maintenance and serving work .................................. -
Page 3: General Safety Information
Moving parts can cause serious injury! You must therefore read and follow the safety instructions set out below. All work on and with SystemMobile S41T must be performed with “safety first” in mind. Do not place your hand near the moving parts of height-adjustable SystemMobile S41T when they are unlocked. -
Page 4: Correct Use
SystemMobile S41T must be used only in accordance with the technical data and safety requirements set out in this document. Height-adjustable SystemMobile S41T is a technical item of factory equipment and is not intended for private use. If major al- terations are made to height-adjustable SystemMobile S41T, compliance with the Machinery Directive will need to be renewed and the documentation supplemented accordingly. -
Page 5: Personnel Qualifications
▪ Observe the applicable safety regulations, accident prevention and environmental protection regulations of the country in which the product is used, in which the product is used. ▪ Only use the item product if it is in perfect technical condition. ▪ Observe all instructions on the product. -
Page 6: Product Description
Product description The product is used in industrial applications. Stepless height adjustment and mobility without an electric drive characterise the SystemMobile S41T. Customised equipment allows the transport trolleys to be adapted to all work processes, making production faster and more flexible. - Page 7 SystemMobile S41T ― User guide Ther SystemMobile S41T is suitable for use in electrotechnically hazardous areas thanks to the selection and installation of appropriate components. Consultation with your item representative is recommended. Environmental considerations: ▪ Operating temperature range -5°C to +40°C ▪...
-
Page 8: Assembly And Installation
SystemMobile S41T ― User guide Assembly and installation M8x40 M8x40 0.0.602.38 0.0.602.39 0.0.602.40 0.0.602.41... -
Page 9: Commissioning And Operation
▪ Extreme scenarios such as steep inclines and collisions with obstacles at speeds in excess of the stipulations in DIN EN 1757-3 can increase the likelihood that SystemMobile S41T will tip over and cause damage and injuries. ▪ Height-adjustable SystemMobile S41T can be damaged if it comes into contact with obstacles, and its service life may be shortened. -
Page 10: Functions
SystemMobile S41T ― User guide Functions The tray can be adjusted in two ways: Pressing the black plastic lever releases the gas spring, allowing the user to raise or lower the tray to any point within the available travel range. -
Page 11: Maintenance And Serving Work
When maintaining SystemMobile S41T, it is important to ensure that all moving elements are secured so that they cannot be moved. Moving parts can cause serious injury! All work on and with SystemMobile S41T must be performed with “safety first”... - Page 12 Industrietechnik GmbH Friedenstraße 107-109 42699 Solingen Germany Phone +49 212 6580 0 info@item24.com item24.com...
