- Page 1 SystemMobile S61T User guide...
-
Page 2: Table Of Contents
SystemMobile S61T ― User guide Contents Symbols, safety .........................................2 General safety information .....................................3 Correct use ..........................................4 Improper use ..........................................4 Personnel qualifications ......................................5 Safety instructions ........................................5 Product description ........................................6 Operating data ...........................................6 Assembly and set-up .........................................7 Commissioning and operation .................................... 10 Maintenance and servicing work .................................. -
Page 3: General Safety Information
S61T. Observe the regulations pertaining to accident prevention and environmental protection that apply in the country and workplace where the product is being used. Use only item products that are in perfect working order. Failure to use original spare parts will invalidate the product warranty! Check the product for obvious defects. -
Page 4: Correct Use
SystemMobile S61T must be used only in accordance with the technical data and safety requirements set out in this document. SystemMobile S61T is a technical item of factory equipment and is not intended for private use. If major modifications are made, the documentation will need to be renewed or supplemented in accordance with the Machinery Directive. -
Page 5: Personnel Qualifications
▪ Always ensure the product is used correctly. ▪ You may start up the product only after it has been ascertained that SystemMobile S61T satisfies country-specific provi- sions and internal company safety regulations. ▪ Conduct a new risk analysis and assessment for each major modification made to completed machinery. -
Page 6: Product Description
The product is used for industrial purposes. SystemMobile S61T offers stepless height adjustment and manoeuvrability without an electric drive, making it ideal for mobile work benches in environments where there is no direct power source. SystemMobile S61T is adjusted using a foot pedal. -
Page 7: Assembly And Set-Up
Relative humidity 5% to 85% The hydraulically height-adjustable SystemMobile S61T is intended for use in an area that is protected from the weather. ▪ The area should be free from mould and fungus and show no traces of rodents or other pests. - Page 8 SystemMobile S61T ― User guide Assembling SystemMobile S61T □120 □120 106.4 □80 ⌀6.8 (8 M8 (4 Base plate Top plate...
- Page 9 Caps To ensure the Lift Module is not unintentionally extended, do not pick up SystemMobile S61T by its table top. If the Lift Module is pulled out by hand, the foot pedal must be pumped up to the top end position to vent the system.
-
Page 10: Commissioning And Operation
Individuals without the proper authorisation are not permitted to disassemble system components. If components are found to be damaged, please contact your local item GmbH branch or distribution partner. Caution: Failure to observe instructions in the user guide can result in injury. - Page 11 SystemMobile S61T ― User guide SystemMobile S61T must be incorporated into its working environment to suit the relevant application and in line with internal company regulations. ▪ In every situation, you must ensure that the product will not tip over and the load is securely positioned when travelling around curves, over ramps and on slopes.
-
Page 12: Maintenance And Servicing Work
When maintaining SystemMobile S61T, it is important to ensure that all moving elements are secured so that they cannot be moved inadvertently. Rotating and moving parts can cause serious injury! All work on and with SystemMobile S61T must be performed with “safety first”... -
Page 13: Disposal
Improper disposal of this height-adjustable application can pollute the environment. Please therefore dispose of the height-adjustable SystemMobile S61T in full accordance with the laws of your country. Caution: Environmentally hazardous. The disposal of individual components must be handled by an approved specialist com- pany due to the potential for environmental pollution. -
Page 14: Hydraulic Oil
The following details are provided by the manufacturer. The complete safety data sheet can be found on the relevant product page in our Online Shop. If you have any questions, please contact your local item GmbH branch or distribution partner. - Page 16 Industrietechnik GmbH Friedenstrasse 107-109 42699 Solingen Germany Phone +49 212 6580 0 info@item24.com item24.com...
