Summary of Contents for Haier HWD150-BP14986ES8U1

  • Page 1 User manual Washer-dryer HWD150-BP14986ES8U1...
  • Page 2 Thank you Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions con- tain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.

  • Page 3: Table Of Contents

    Content 1-Safety information ......................... 4 2-Product description ........................8 3-Control panel ..........................9 4-Programmes ..........................13 5-APP Instructions ...........................16 6-Daily use ............................17 7-Eco-friendly washing ........................22 8-Care and cleaning ........................23 9-Troubleshooting ...........................26 10-Installation ...........................29 11-Technical data ..........................33...

  • Page 4: 1-Safety Information

    1-Safety information Read the following safety instructions before using the appliance WARNING! Before fi rst use Make sure there is no transport damage. Make sure all transport bolts are removed. Remove all packaging and keep out of children´s reach. Handle the appliance always with at least two persons because it is heavy.
  • Page 5 1-Safety information WARNING! Daily use Do not remove or insert the plug in the presence of flammable gas. Do not hot wash foam rubber or sponge-like materials. Do not wash any laundry which is polluted with flour. Do not open detergent drawer during any wash cycle. Do not touch the door during the washing process.
  • Page 6 1-Safety information WARNING! Daily use Do not dry following items in the appliance: Items which are unwashed. Items which have been contaminated with infiammable substances such as cooking oil. acetone, alcohol. benzine, petrol. kerosene, spot removers. turpentine, waxes, wax removers or other chemicals. The fumes can cause a fire or explosion.
  • Page 7 1-Safety information Installation Ensure a location which allows opening the door fully. Do not install the appliance behind a lockable door. a sliding door or a door with hinges on the opposite side of the appliance door as this limits the full opening of the appliance door.

  • Page 8: 2-Product Description

    2-Product description Note: Due to technical changes and diff erent models, the illustrations in the following chap- ters may diff er from your model. 2.1 Picture of appliance Front (Fig. 2-1): Rear side (Fig. 2-2): 1 Shipping bolts (T1-T4) 1 Dispenser drawer 2 Back cover 5 Washer door 3 Back cover screws...
  • Page 9 panel Note: Variety Apperance and features will vary. 5 Function buttons 1 “Power“ button 3 Display 7 “Start/Pause“ button 6 Setting buttons 2 Programme selector 4 Dispenser drawer Note : Acoustic signal In following cases an acoustic signal sounds: 3.1 “Power“ button Touch this button (Fig.

  • Page 10: 3-Control Panel

    3-Control panel 3.2 Programme selector By turning the knob (Fig. 3-3) one of 14 programmes can be selected, related LED will light up, its default settings will be displayed. 3.3 Display The display (Fig. 3-4) shows following information: Wash time End time delay Error codes and service information Function buttons and “Start/Pause“...
  • Page 11 Note: Factory settings To get best results in each programme Haier has w c default settings. If there is no special requirement default settings are recommended. 3.5.1-Function button “Delay“ Press this button (Fig. 3-7) to start the programme with a delay. End time delay could be increased in steps...
  • Page 12 3-Control panel 3.6 Setting buttons Individual settings for water temperature (Temp.), spin speed (Speed) extra rinse times (Extra Rinse) can be set to programmes. Each setting has several options to be set from minimum to maximum. Note: Settings Settings are not aviliable on some programmes. 3.6.1-Setting button “Temp.“...

  • Page 13: 4-Programmes

    4-Programmes Wash Programmes The wash programmes are optimized for specific types of laundrys. Select the programme that most closely matches the items being washed. Settings shown in bold are the suggested settings for the programme. Detergent compartment for: Liquid or powder Detergent Softener or care product Sanitizer Optional,...
  • Page 14 4-Programmes Detergent compartment for: Liquid or powder Detergent Softener or care product Sanitizer Optional, Not available º Max. Extra load Temperature Spin speed Rinse Programme Wash l Dry in °C in rpm 1 2 3 Fabrics type in kg 1000 Baby care / Cotton/Synthetic 7.5 l 5...
  • Page 15 4-Programmes Functions below are available on specifi c programmes to provide enhanced performance. “O” indicates that function can be selected to the programme. “-” indicates that function cannot be selected to the programme. Options Programme Dry Level Delay i-time Cotton Synthetics Delicate Bedding...

  • Page 16: 5-App Instructions

    5-APP Instructions APP Instructions Download and Install Haier Smart APP Scan the instruction page QR code with your mobile phone to download and install Haier Smart APP client Registration and Login. Connect to the home Wi-Fi，open the Haier Smart APP, register an account and log in, press and hold the power button until C5 appears on the washing machine interface, click the"+"...

  • Page 17: 6-Daily Use

    6-Daily use 6.1 Power supply Connect the washing machine to a power supply (220-240V~/50Hz; Fig. 6-1). Please refer also to section INSTALLATION. 6.2 Water connection Before connecting check the cleanliness and clarity of the water inlet. Turn on the tap (Fig.6-2). Note: Tightness Before use check for leakage in the joints between the tap and the inlet hose by turning on the tap.
  • Page 18 6-Daily use Care chart Washing Washable up to 95°C Washable up to 60°C Washable up to 60°C normal process normal process mild process Washable up to 40°C Washable up to 40°C Washable up to 40°C normal process mild process very mild process Washable up to 30°C Washable up to 30°C Washable up to 30°C...
  • Page 19 6-Daily use 6.5 Selecting detergent ▶ Washing e ffi ciency and performance is determined by used detergent quality. ▶ Use only machine wash approved detergent. ▶ If needed use specifi c detergents, e.g. for synthetic and woolen fabric. ▶ Mind always detergent manufacturer recommendations. ▶...
  • Page 20 6-Daily use 6.6 Adding detergent Slide out the detergent drawer. corresponding compartments (Fig. 6-4). Note: Remove detergent residues before next wash cycle from the detergent drawer. Do not overuse detergent or softener. Please follow the instruction on the detergent package. Always ll the detergent just before the beginning of the wash cycle.
  • Page 21 6-Daily use 6.10 Start wash programme Touch “Start/Pause“ button (Fig. 6-8) to start. Appliance operates according to present settings. Changes are only possible by cancelling the programme. 6.11 Pause/ cancel wash programme To pause a running programme press gently “Start/Pause“. The LED above the button is fl...

  • Page 22: 7-Eco-Friendly Washing

    7-Eco-friendly washing Environmentally responsible use To achieve best use of energy , water, detergent and time you should use the recom- mended maximum load size. Do not overload (hand width clearance above laundry). For slightly soiled laundry select the Quick 15' programme. Apply exact dosages of each washing agent.

  • Page 23: 8-Care And Cleaning

    8-Care and cleaning 8.1 Cleaning the detergent drawer Take always care there are no detergent residues. Clean the drawer regularly (Fig. 8-1): 1. Pull out the drawer until it stops. 2. Press the release button and remove the drawer. 3. Flush the drawer with water until it is clean and insert the drawer back in the appliance.
  • Page 24 Note: Clean Water and power should be cut off after each laundry cycle. To prevent the dirt from sticking to clothes,lint on the interlayer gasket and window should be cleaned. 8.5 Long periods of disuse If the appliance is left idle for a longer period: 1.
  • Page 25 8-Care and cleaning 8-14 8-15 9. Clean carefully pump filter,e.g. using running water (Fig.8-14). 10. Refix it thoroughly (Fig.8-15). 11. Close service flap. CAUTION! Pump fi lter sealing has to be clean and unhurt. If the lid is not full tightened, water can escape.

  • Page 26: 9-Troubleshooting

    9-Troubleshooting Many occuring problems could be solved by yourself without specifi c expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
  • Page 27 9-Troubleshooting Problem Cause Solution  • Temperature sensor error. • Contact the After sales service.  • Heating error. • Contact the After sales service.  • Motor error. • Contact the After sales service.  • Water level sensor error. •...
  • Page 28 9-Troubleshooting Problem Cause Solution Excessive foam fl oats • Detergent is not a appropriate. • Check detergent recommen- drum and/or deter- dations. gent drawer. • Excessive use of detergent. • Reduce amount of detergent. Automatic adjust- • Washing programme duration will •...

  • Page 29: 10-Installation

    10-Installation 10.1 Preparation ▶ Take the appliance out of the packaging. ▶ Remove all packaging material including polystyrene base, keep them out of childrens reach. While opening the package, water drops may be seen on plastic bag and port- hole. This normal phenomenon results from water tests in the factory. Note: Packaging disposal Keep all packaging materials out of children´s reach and dispose them in an environ- mentally friendly manner.
  • Page 30 10-Installation 10.4 Moving the appliance 10.5 Aligning the appliance 10-8...
  • Page 31 10-Installation 10.6 Drain Water Connection Fix the water drain hose properly to the piping. The hose has to reach at one point a height between 80 and 100 cm above the appliance bottom line! If possible keep always drain hose fi xed to the clip at the appliance back. WARNING! Use only the supplied hose set for the connection.
  • Page 32 10-Installation 10.7 Fresh Water Connection 10-12 10-13 Make sure that the gaskets are inserted. 1. Connect the water inlet hose with the angled end to the appliance (Fig. 10-12). Tighten the screw joint by hand. 2. The other end connect to a water tap with a 3/4“...

  • Page 33: 11-Technical Data

    Net weight in kg 11.2 Product dimensions FRONT VIEW Wall TOP VIEW PRODUCT DIMENSIONS HWD150-BP14986ES8U1 A Overall height of product mm l l a l l a D Depth of door open mm 1260 E Minimum door clearance to adjacent wall mm Note:The exact height of your washer is dependent on how far the feet are extended from the base of the machine.
