1. INTRODUCTION 1.1. GENERAL NOTES This document outlines and defines the installation, operation and maintenance procedures for the Ixys PCB CS PWM. The manual will contain all relevant data and methods to be able to use and maintain the device for its intended purpose.
Page | 4 Doc. No.: 100447-ICS-PD-UMN-0001 Name: User Manual Revision No: 2. HEALTH, SAFETY AND ENVIRONMENT 2.1. GENERAL Safety Notes and General Precautions shall be presented to all personnel concerned prior to testing, operation, maintenance and repair. The operations shall be performed by the responsible engineer/supervisor.
PWM outputs and analog inputs for connection of solenoids and analog sensors. 3.2. TECHNICAL DATA General Manufacturer Ixys AS Description PCB CS PWM Weight ~150g Dimensions 96 x 90 x 13mm (PC104 format) Electrical Data Supply Voltage...
Packing not carried out in an ESD protective way 3.4. ORDERING Ixys Part Number Description 100447 PCB CS PWM 3.5. ACCESSORIES Ixys Part Number Description 112075 Connector – 4 Way Cable contact Wago 2092-1124 100086 Connector – 4 Way Cable contact Wago 733-104...
5. OPERATION 5.1. NORMAL OPERATION The board can be attached to another Ixys CS-range board configured as master. The board will then share power and communication with the master board and all outputs and inputs will be presented in the master board Modbus registers.
User Manual Revision No: 6. REGISTERS For Ixys CS Slave PCBs the Register addresses are meant as offsets from the start register each board gets in the Modbus registers in the Master PCB of the stack of boards. 6.1. DATA TYPES The following table describes the data types used on Ixys boards.
