ZAURA
Before you begin
•
In the box are ZAURA Starters and Masters.
•
Do not yet insert batteries in the Masters.
•
Decide which configuration you prefer:
– Easiest
Configuration, for Non‐Dimming systems (recom‐
mended): begin with Step One, over there on the right.
–
Custom Configuration, for systems with Dimmers: refer to the
next page.
–
For systems that will include Range Extenders, or for assistance,
see the ZAURA RF Wireless Lighting Control Installation Guide
(UM0229), available on www.zilog.com.
•
Assemble your tools.
•
See the www.zaura.com website for:
–
Troubleshooting info
–
Support materials, videos and documentation
–
Replacement parts ordering info
Local Contact Info
Less Energy BV
Anthonetta Kuijlstraat 47
3066 GS Rotterdam
+ 31 10 7144 844
c.hermes@less‐energy.nl
www.less‐energy.nl
QS008101‐0211
™
RF Wireless Lighting Control
→
Installing a System without Dimming Controls
Step One
A.
Replace the existing starters with the ZAURA starters.
B.
Turn on the light switch (all lights should be illuminated).
Step Two
A.
Insert a battery in the Master.
B.
Wait 1 minute.
C.
Press the Associate Non‐Dimmer button once and release.
D.
Wait 30 seconds to allow the association to complete.
Step Three
A.
Mount the base of the Master in the center of the room using the
screws or the sticky tape provided.
B.
Attach the Master to the base.
Step Four
A.
Exit the room. Your lights should extinguish within a few minutes.
B.
Reenter the room. Your lights should illuminate.
www.zilog.com
Quick Start Guide
®
Copyright ©2011 Zilog
, Inc. All rights reserved.
Advertisement
Table of Contents
Summary of Contents for IXYS Zilog ZAURA
- Page 1 ™ ZAURA RF Wireless Lighting Control Quick Start Guide Before you begin Installing a System without Dimming Controls • In the box are ZAURA Starters and Masters. Step One • Do not yet insert batteries in the Masters. Replace the existing starters with the ZAURA starters. • Decide which configuration you prefer: Turn on the light switch (all lights should be illuminated). – Easiest Configuration, for Non‐Dimming systems (recom‐ → mended): begin with Step One, over there on the right. Step Two – Custom Configuration, for systems with Dimmers: refer to the next page. Insert a battery in the Master. – For systems that will include Range Extenders, or for assistance, Wait 1 minute. see the ZAURA RF Wireless Lighting Control Installation Guide Press the Associate Non‐Dimmer button once and release. (UM0229), available on www.zilog.com. Wait 30 seconds to allow the association to complete. • Assemble your tools.
- Page 2 Installing a System with Dimming Controls Step Five Mount the base of the Master in the center of the room using the Step One screws or the sticky tape provided. Identify the luminaries that you want to be non‐dimming and Attach the Master to the base. replace their existing starters with the ZAURA starters. Step Six Turn on the light switch (all lights should be illuminated). Exit the room. Your lights should extinguish within a few minutes. Step Two Reenter the room. Your lights should illuminate. Insert a battery in the Master. Wait 1 minute. Press the Associate Non‐Dimmer button once and release. Wait 30 seconds to allow the association to complete. Step Three Identify the luminaries for which you want dimming capability and replace their existing starters with the ZAURA starters. Turn on the light switch (all lights should be illuminated). Step Four Press the Associate Dimmer button once and release. Wait 30 seconds to allow the association to complete.
