RS-232 to RS-422/485 Converter
with 15 kV ESD protection
English
Jumper Setting Terminator
Jumper Setting On
J4 for RTS J5 for CTS
J2 for Tx J3 for Rx
DIP-Switch Setting Modes
Automatic Setup Mode: RS-422/485
Pin assignment D-Sub 9 Pin connectors
PIN
RS-422 4-Wire RS-485
1 Tx- Tx-
2 Tx+ Tx+
Bedienungsanleitung
Manual del usuario
Instrukcja obsługi
Bruksanvisning
Használati utasítás
Εγχειρίδιο χρήστη
Product-No: 64265
User manual no: 64265-a
www.delock.com
Jumper Setting Off
J4 for RTS J5 for CTS
J2 for Tx J3 for Rx
Forces Mode: RS-422
Transmission Signal
2-Wire RS-485
D-
D+ TX
RS-232
