Exposed pedal flushometer for flux bowl, 1 1/2" spud, 1,58 gpf, exposed pedal flushometer for nao, nao 17 and nao wall, flux bowl, 1 1/2" spud, 0,92 gpf, exposed pedal flushometer for flux bowl, 1 1/2" spud, 1,26 gpf

Advertisement

Quick Links

FB-110-38
Fluxómetro de Pedal Expuesto para Taza Flux, Spud
de 38 mm, 6 LPD
Exposed Pedal Flushometer for Flux Bowl, 1 1/2"
Spud, 1,58 GPF
FB-110-38-3.5
Fluxómetro de Pedal Expuesto para Taza Flux Nao,
Nao 17 y Nao a Pared, Spud de 38 mm, 3,5 LPD
Exposed Pedal Flushometer for Nao, Nao 17 and Nao
Wall, Flux Bowl, 1 1/2" Spud, 0,92 GPF
FB-110-WC-4.8
Fluxómetro de Pedal Expuesto para Taza Flux, Spud
de 38 mm, 4,8 LPD
Exposed Pedal Flushometer for Flux Bowl, 1 1/2"
Spud, 1,26 GPF
