- Page 1 B4U-FILTER PRE-FILTER SKIMMER SYSTEM MODEL BS 202PSN TWO STAGE PRE-FILTER SKIMMER WATER 80% CLEANED B4 IT REACHES YOUR FILTER Congratulations on purchasing a Pro-Series Automatic Skimmer & Pre-Filter System 9226...
- Page 2 PRO SERIES AUTOMATIC SKIMMER & PRE-FILTER SYSTEM MODEL BS 202PSN We are confident that you too will discover why Blue Torrent products are unparalleled industry-wide. Our decision to produce the finest quality products has allowed us to gain the respect of the entire pool industry.
- Page 3 BS 202PSN AUTOMATIC SKIMMER & PRE FILTER SYSTEM PARTS DESCRIPTION PART # MODEL # BS 26298 Pre Filter Bag BS 26905 Eyeball Kit BS 26484 Stand Off BS 40061BLK Hose Fittings BS 25673 Top Cover BS 08370 Vacuum Plate AC 93378 Strainer Basket BS 25623 Skimmer Weir...
- Page 4 INSTALLING YOUR NEW SKIMMER STEP 1 If this is a new pool, fill pool per manufacturer’s instructions to 2” below the return opening prior to installing your filter. If this is an existing pool, drop water level to 2” below return opening before proceeding to step 2.
- Page 5 STEP 4 Line up skimmer body with holes on gasket from the outside of the pool (see figure 4) and insert skimmer screws through plate and into all openings on skimmer body (see figure 5). Figure 4 - Lining up skimmer body with gasket STEP 5 Using a phillips head screwdriver...
- Page 6 STEP 8 Use Teflon tape (BS 35858) to cover all threads on hose fitting (BS 26646BLK) and screw hose fitting with threads facing upwards into skimmer body bottom opening (see figure 7). STEP 9 Figure 7 - Applying Teflon tape to hose adaptor Cut vinyl covering skimmer opening with razor blade carefully as close as...
- Page 7 STEP 13 Attach a 1-1/4” or 1-1/2” hose onto fitting installed in step 8 and clamp into place using one stainless steel clamp Figure 12 - (see figure 13). Attach the loose end of Attaching hose the hose to fitting on intake of pump to pump (typically opening on front of pump) and clamp into place (see figure 12).
- Page 8 INSTALLATION OF RETURN FITTING STEP 1 Unscrew all pieces of return fitting so that you have six pieces separated into: • 2 rubber gaskets • 1 cork gasket • 1 ball seat • 1 locknut • 1 return (circular ring with threaded back) Locking Ring Ball Seat...
- Page 9 STEP 5 STEP 6 Place second rubber gasket over threads Take the locknut (see figure 6) and so it is touching the outside part of the wall. screw it onto the threads with the flat side Place cork gasket on in the same fashion in facing the pool (see figure 7).
- Page 10 VACUUMING PROCEDURE When it is necessary to vacuum your pool, please follow the guidelines listed below in order to ensure proper suction and successful vacuuming. 1. Make sure that you have a vacuum head with handle, telescopic pole and vacuum hose that is at least 6’...
- Page 11 7. Place vacuum elbow with fat side over top of vacuum plate and make sure that longer side is pointing into the pool (see figure 2). Facing into skimmer opening towards pool Figure 2 - Vacuum Plate & Elbow on basket 8.
- Page 12 OPTIONAL BONDING PLATES A) The bonding post is installed in the bonding port of the skimmer housing (pic A) B) Disassemble bonding post. Remove bonding screw, nut, plate and washer from the bonding post (pic B) C) Insert the bonding post into the bonding port from the inside of the skimmer housing (pic C) D) Reinstall the washer, plate nut and screw in that order onto the bonding post (pic D)
- Page 13 BLUE TORRENT BLUE TORRENT B4U-SKIMMER SYSTEM B4U-SKIMMER SYSTEM Model: BS 202PSN ONE YEAR LIMITED WARRANTY One year limited warranty from date of purchase. The BS 202PSN Skimmer System is guaranteed to be free of manufacturers defects in material and workmanship under normal use in accordance with the proper installation and operation manual.
