- Page 1 SAND SHARK UNIVERSAL INSTRUCTIONS INCLUDES BASE FOR FILTER AND PUMP TOOLS • Phillips head screwdriver • Flat head screwdriver REQUIRED • O-ring lube 10475...
- Page 2 PARTS FOR SAND FILTER NOTE See breakdown on following page for model specific part lists. FILTER BASE TANK 4 WAY VALVE CLOSURE CLAMP STAND PIPE VALVE O-RING HOSE CLAMPS (6) PRESSURE GAUGE STRAIGHT FITTING (3) TEFLON TAPE SHORT HOSE (1) HOSE ADAPTERS (2) DRAIN PLUG LONG HOSE (2)
- Page 3 FILTER PARTS BY MODEL PART # MODEL # DESCRIPTION AC 85685 Filter Base AC 83402 Drain Plug AC 83380 Stand Pipe AC 83399 Filter Tank AC 83348 O-Ring AC 83364 Flange Clamp AC 83321 4 Way Valve AC 84514 Bolt Kit BS 40061 Straight Fitting BS 35815...
- Page 4 ASSEMBLY INSTRUCTIONS FOR SAND FILTER NOTE Filter may be partially assembled; however, nothing has been properly tightened. DO NOT operate filter system without completing assembly instructions. STEP 1 • Remove the valve from the box and place it to the side until instructed to attach it. •...
- Page 5 STEP 2 ATTACHING THE DRAIN ASSEMBLY If drain assembly is all together, take it apart. Take one rubber gasket and put over threaded part of the drain assembly. Flat part of gasket must be flush against sealing plate. From inside the tank insert drain assembly through hole in bottom of tank, you will see the threaded part on the outside of the tank.
- Page 6 STEP 3 • The filter and pump should be attached to the base prior to filling the filter with sand as it will be difficult to maneuver after the tank is full. A. CRADLE STYLE MOUNT • Pumps with cradles located directly under the motor should be aligned with the 4 holes that match up to the cradle.
- Page 7 STEP 4 • Before filling tank with sand, place nub on bottom of tank into notched out piece of the base, twist to the right till snug. • P , cover standpipe lace standpipe inside the filter with the round plastic standpipe protector to prevent sand from entering standpipe.
- Page 8 STEP 4 — CONTINUED • Lubricate with o-ring lube to ensure proper seal on tank.(O-Ring lube not included) • Push o-ring against the lip of the valve. It MUST sit flat against the lip to protect from leaking at the valve. •...
- Page 9 STEP 4 — CONTINUED • Once valve is in place, hold clamp as shown and position clamp around lip of filter and over edge of valve. 2 long screws and nuts are provided to put clamp together. • The clamp should sit flat around the lip of the tank and valve.
- Page 10 HOSE CONNECTIONS FOR STANDARD ABOVEGROUND POOLS 1. Take the short hose. Place a clamp onto each end of the short hose. Leave loose. Slide one end of the short hose over the exhaust port of you pump. This is the port opening at the top of the pump not the one in front of the pump.
- Page 11 OPERATING YOUR FILTER NOTE Your filter cannot be run if the water is not at the proper level in the pool. Running the filter without water can cause serious damage to your pump and filter. • Prime filter prior to starting up filter system. DO NOT turn motor on until system has been primed, you can damage your pump.
-
Page 12: Troubleshooting
TROUBLESHOOTING SHORT POOL WATER WON’T CLEAR UP WATER FLOW FILTER CYCLES 1. Check skimmer and pump 1. Check for algae in pool and 1. Check chlorine, pH and total strainer baskets for debris. superchlorinate as required. alkalinity levels and adjust as required. -
Page 13: Year Limited Warranty
Blue Torrent’s PUMPS AND FILTERS are warranteed as follows: 1 YEAR LIMITED WARRANTY Blue Torrent warrants its Pumps and Filters to be free of defects in material and/or workmanship for a period of one year from the original date of purchase and/or installation.
Need help?
Do you have a question about the Sand Shark and is the answer not in the manual?
Questions and answers
The filter is one piece? How do you put the sand in and get the cartridge all the way down to seal it back up?
The Blue Torrent Sand Shark filter is not a one-piece unit; it includes multiple parts such as a base, filter tank, standpipe, 4-way valve, and other components.
To add sand:
1. Place the nub on the bottom of the tank into the notched base and twist right until snug.
2. Insert the standpipe into the filter and cover it with the plastic protector.
3. Fill the tank with filter-grade sand around the standpipe until the sand level is between 1/2 and 3/4 of the tank height.
4. Remove the plastic protector and fill the tank with water until just below the standpipe opening.
To seal the cartridge:
- Lubricate the tank's O-ring with O-ring lube (not included) to ensure a proper seal.
This answer is automatically generated
@Mr. Anderson How do I separate the standpipe from the valve? It came out in one piece as I’m replacing the sand. I’m afraid to break it.
where is the on/off switch on the filter?
