- Page 1 B-NIMBLE™ Stroller User Guide IMPORTANT: To ensure your child is as safe as possible, read all instructions thoroughly before using this stroller. Store this manual for future reference.
-
Page 3: Table Of Contents
Attaching Britax Infant Car Seat Adapters . . . . . . . . . . . . . . . . . -
Page 4: Warnings
• Children must always be restrained to prevent standing or falling out of stroller. • Only use Britax approved child restraints or carriers with this stroller. • Do not allow children to climb on or play with the stroller. - Page 5 Infant.Car.Seat.Mode • The infant car seat adapters are ONLY compatible with Britax infant car seat and ONLY models from 2009 or newer • Attempting to fit them into another infant car seat can damage the car seat or cause the car seat to fall •...
-
Page 6: Features
Features Canopy.with.Sun.Visor Handles Carry. Strap Chassis. Lock On.right.side. of.frame Infant. Harness Car.Seat. Adapter Buckle Frame. Release. Frame. Lever Release. Lever Leg.Rest Rear. Wheels Under-Seat. Storage. Swivel. Basket Wheel. Locks Front.Wheels • Actual product may vary from images. -
Page 7: In.the.box
In the Box B-NIMBLE. Stroller Canopy.with. Sun.Visor Infant.Car.Seat. Receivers Front.Wheels Britax.Infant.Car. Seat.Adapters Rain.Cover Cup.Holder... -
Page 8: Assembly
Assembly Unfolding the Stroller • Lift the chassis lock and pull the frame apart • Lift up on the handles and pull them away from each other WARNING: To avoid entrapment or pinching, do not fold or unfold when child is in or near stroller •... -
Page 9: Front Wheels
Assembly Front Wheels • Locate the right and left wheels and ensure that the swivel lock lever is locked into place as shown before placing wheels on stroller • Press the wheel assembly onto the mount at the front of the stroller NOTE: Pull down on wheel assembly to ensure that it is locked Canopy... - Page 10 Assembly Cup Holder • Slide the tab on the cup holder into the slot in the cup holder bracket Infant Car Seat Receivers • Place the infant car seat receiver behind the stroller frame and between the two brackets as shown TIP: The receiver should be pointing upward, and the raised lines (Fig.
- Page 11 Assembly Lowering the Infant Car Seat Receivers • Slide the receiver up to release the receiver • While holding the receiver up, rotate to the lower position...
-
Page 12: Operating.instructions
Operating Instructions Parking Brake • Step on the brake pedal on either side of the stroller until the wheels lock • Lift either brake pedal to release the brake Leg Rest Adjustment • Lift leg rest to raise it or press and hold both leg rest levers to lower... -
Page 13: Recline Adjustment
Operating Instructions Recline Adjustment • Lowering: From the back of the seat, press and hold the button on the recline adjuster and pull away from the seat back • Raising: Hold the adjuster strap and slide the recline adjuster to the desired position Swivel Wheels •... -
Page 14: Folding The Stroller
Operating Instructions Folding the Stroller • If infant car seat receivers are attached you must first rotate them to the lower position (Page 9) • Pull up on the carry strap to release the primary frame lock... - Page 15 Operating Instructions • Step on the secondary frame lock to release the chassis WARNING: To avoid entrapment or pinching, do not fold or unfold when child is in or near stroller • Push the stroller forward and continue folding until the chassis lock engages NOTE: You may need to compress the stroller to engage the chassis...
-
Page 16: Securing.your.child
Securing Your Child • Unlatch the harness by depressing the button in the center of the buckle while pulling the two tongues away from the buckle assembly • To raise or lower the harness height, disconnect the buckle tongues and pull the harness strap out from the back of the seat •... - Page 17 Securing Your Child • Buckle the harness by inserting the tongues on the harness straps into the buckle assembly NOTE: Ensure the straps are not twisted as they may become uncomfortable for the child • Tighten or loosen the harness straps by sliding the harness adjusters up or down To reconnect buckle tongues, line up...
-
Page 18: Attaching Britax Infant Car Seat Adapters
Infant Car Seat Mode Attaching Britax Infant Car Seat Adapters • Slide each of the adapters under the infant car seat handle and into the shell until they click into place NOTE: There is a left and right adapter and orientation should be as shown •... -
Page 19: Attaching The Infant Car Seat
Infant Car Seat Mode Attaching the Infant Car Seat NOTE: Seat back should be reclined completely (Page 11) • Line up the locking latches on the infant car seat with the sockets on the infant car seat receivers • Press down until the adapters lock into place IMPORTANT: Infant car seat must be installed rear-facing ONLY... -
Page 20: Rain.cover
Rain Cover... -
Page 21: Care.and.maintenance
Care and Maintenance Parking.Brake. • Periodically check that the parking brake works properly and locks both wheels securely . • Clean out any dirt or debris that may prevent the brake from working . Frame. • Wipe the frame with a damp cloth and mild soap . Use clean, dry cloth or towel to wipe away excess water and soap . -
Page 22: Warranty
. The use of non-Britax Child Safety, Inc . accessories is not approved by Britax . The use of unapproved accessories could cause this product to become damaged or dangerous . Their use automatically voids the Britax warranty . - Page 24 Visit.our.website.at.www .Britax .com.for.more.information . Britax Child Safety, Inc. Tel. : 1-888-427-4829 13501 South Ridge Drive Charlotte, NC 28273 www.Britax.com A Britax Childcare Group Limited company...
