IMPORTANT SAFETY INSTRUCTIONS
WARNING
If the instructions contained in this manual are not followed
precisely, a fire or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors, liquids
or materials near this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any telephones in your building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a qualified
installer, service company or gas supplier.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A
QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR THE LOCAL INSPECTOR'S USE.
Table of Contents
12
12
15
16
25
26
3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Smeg PGFU30X2
Summary of Contents for Smeg PGFU30X2
-
Page 1: Table Of Contents
Table of Contents 1 Installation 1.1 Positioning in the counter top 1.2 Mounting 1.3 Gas supply requirements 1.4 Electrical requirements 1.5 For the installer IMPORTANT SAFETY INSTRUCTIONS WARNING If the instructions contained in this manual are not followed precisely, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 2: Important Safety Instructions
Important Safety Instructions • This appliance is intended for residential use only. • Use this appliance only for its intended purpose. The manufacturer cannot be held liable for damage caused by improper use of this appliance. WARNING • This appliance complies with current safety regulations. - Page 3 Important Safety Instructions NOTE: This appliance is NOT designed for installation in manufactured (mobile) homes or in recreational vehicles (RVs). DO NOT install this appliance outdoors. Improper installation is not covered by the warranty. ow the instructions in this manual may •...
- Page 4 Important Safety Instructions Definitions Safety Codes and Standards This appliance complies with one or • This manual contains important safety symbols and instructions. Please pay more of the following Standards: attention to these symbols and follow all ANSI Z21.1/CSA 1.1 Household instructions given.
- Page 5 Important Safety Instructions • Make sure your appliance is installed • To eliminate the need to reach over the and grounded properly by a qualified surface burners, cabinet storage space installer or service technician. above the burners should be avoided. •...
-
Page 6: Electric Safety
Important Safety Instructions Electric Safety • If required by the National Electrical Code (or Canadian Electrical Code), this appliance must be installed on a WARNING separate branch circuit. • The circuit breaker should have a Before you plug the electrical cord into contact separation of at least 3 mm on an outlet, make sure that all the all poles. -
Page 7: Proposition 65 Warning
Important Safety Instructions Propane Gas Installation • The appliance must be isolated from the gas supply piping system by turning off • The propane gas tank must be equipped its individual manual shutoff valve during with its own high pressure regulator. In pressure testing of the gas supply piping addition, the regulator supplied with this system at test pressures equal to or less... -
Page 8: Related Equipment Safety
Important Safety Instructions Related Equipment Safety Ventilation Recommendations • The appliance should only be used if • Do not obstruct air vents or heat vent installed by a qualified technician in openings. accordance with these installation • We strongly recommend the installation instructions and all applicable of a ventilation hood above this regulations and codes. -
Page 9: High Altitude Installation
Important Safety Instructions High altitude installation How to read the user manual • This appliance can operate up to an This user manual uses the following reading conventions: altitude of 10,000 ft. (3048 m.) elevation above sea level. If desired, for Installation altitudes above 2,000 ft (610 m) Information for the qualified... -
Page 10: Installation
Installation 1 Installation Fixing to the traditional built-in model support structure Safety instructions Make a hole in the countertop of the furniture unit of the dimensions shown in the WARNING figure. Risk of fire • Make sure that the cabinet material is heat resistant. - Page 11 Installation Location of the gas and electric outlets 24" models: inches inches 20 - 50 150 mm 6” 762 mm 30” min. 25 min. 1 260 mm 10” 762 mm 30” 30" models: 25 mm 1” inches 76 mm 3” 38 mm “...
- Page 12 Installation 1. Refer to the dimensions in the figure, 4. Carefully trim any excess material away making sure that the front and rear long from the edge (B) of the seal. sides are flush with the hole. inches NOTE: The brackets should only 3 - 4 be positioned after the cooktop 2.
-
Page 13: Mounting
Installation 1.2 Mounting 24" models: inches Over built-in oven unit The clearance between the cooktop and 29.7 the kitchen furniture or other installed appliances must be enough to ensure 38.5 sufficient ventilation and air discharge. If installed above an oven, a space should 30"... -
Page 14: Gas Supply Requirements
Installation 1.3 Gas supply requirements WARNING Explosion hazard • Use a new AGA or CSA-certified connector. opening at rear • Install a manual shut-off valve. On top of empty kitchen unit or drawers • Securely tighten all gas connections. • If connected to LPG, have a qualified If there are other pieces of furniture (side technician ensure that the gas pressure walls, drawers, etc.), dishwashers or... - Page 15 Installation Do not bend or damage the flexible Place the gasket (supplied with the unit) connector when moving the appliance. The between the inlet and the regulator. Position pressure regulator has 3/8" female pipe the regulator so that the cap is easily threads.
- Page 16 Installation Testing for gas leaks If the flame is completely or mostly yellow, verify that the regulator is set for the correct FIRE HAZARD fuel. Retest after adjustment. Use a soapy solution Some yellow streaking is normal during the WARNING to check for leaks.
- Page 17 Installation Burner and nozzle characteristics tables To set the range for propane gas or to revert to Natural Gas, refer to the tables below. For 24" models: Natural Gas QT (BTU) 3600 9100 12000 Injector Ø (mm) 0.90 1.40 1.65 QR (BTU) 1200 2500...
- Page 18 Installation • Connect the gas supply line to the • Over time, the gas taps may become pressure regulator using a 1/2” flex gas difficult to turn and jam. Clean them line connector between the manual shut- internally and replace the lubrication off valve and the pressure regulator.
- Page 19 Installation Conversion to propane gas (LPG) This appliance is shipped from the factory for use with natural gas. Use this kit to convert the appliance for use with propane WARNING gas, if necessary. Comply with the following: Ensure that the range is This conversion kit must be installed by a converted for use with the appropriate gas qualified service agency in accordance...
- Page 20 Installation Setting the pressure regulator for Conversion kit parts list propane gas This conversion kit consists of the following To convert the regulator to the type of gas components: used, the following must be done: • One Gas Conversion label. 1.
- Page 21 Installation Replacing the burner nozzles 3. Replace the burner nozzles using a 7 mm socket wrench according to the type of 1. Remove the components from the gas to be used (see “Burner and nozzle cooktop. characteristics tables”). 2. Remove the flame-spreader crowns and corresponding burner caps.
-
Page 22: Conversion To Natural Gas
Installation After the conversion, complete the Gas must be carried out by a qualified Conversion label (part no. 92849A078) technician. and attach it to the rear of the appliance. Conversion to natural gas Do not cover any other labels with the Gas This appliance is shipped from the factory Conversion label. -
Page 23: Electrical Requirements
Installation 1.4 Electrical requirements Make sure that the power supply rating matches the rating indicated on the ID WARNING plate. The ID plates are located in a visible position on the back of the appliances. Electrical shock hazard These ID plates must never be removed. •... -
Page 24: For The Installer
Installation Recommended Grounding Method 1.5 For the installer • The plug must remain accessible after the For your personal safety, this appliance installation is complete. Do not kink or must be grounded. This appliance is fitted trap the mains connection cable. with a 3-prong grounding plug.
