Ref: 213 48 811 XXX
Gebruikshandleiding / Installation sheet / Mode d'emploi / Manual de operatiòn
/ Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册
Ø110
LOGIC 90 R A
A
+
B
C
3
4
LED
7mm - 9 mm
1
E
OPTIONS
GENIE BOX 90 R
213 19 09
CBOX
216 12 00
I
o
P
o
U
100-240V
o
20 mm
SADB 02/04/2025
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for deltalight LOGIC 90 R A
Summary of Contents for deltalight LOGIC 90 R A
- Page 1 Gebruikshandleiding / Installation sheet / Mode d’emploi / Manual de operatiòn / Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册 Ø110 LOGIC 90 R A 93 x 125 OPTIONS 93 x 125 GENIE BOX 90 R 213 19 09...
- Page 2 Gebruikshandleiding / Installation sheet / Mode d’emploi / Manual de operatiòn / Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册 4 = / 3 = N 2 = L 1 = / 7mm - 9 mm 9mm - 12 mm 20 mm 2 ,6Nm Ø...
- Page 3 Gebruikshandleiding / Installation sheet / Mode d’emploi / Manual de operatiòn / Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册 4 = / OPTION GENIE BOX 90 R 3 = N 2 = L 1 = / OPTION GENIE BOX 90 R T=60°C WARNING...
- Page 4 Gebruikshandleiding / Installation sheet / Mode d’emploi / Manual de operatiòn / Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册 Pressure load: 150kg (~1,5kN) Rated maximum surface temperature: 50°C 负载压: 150kg (~1,5kN) （额定）表面最高温度: 50°C Допустимая статическая нагрузка до 1,5kN (до 150кг) Номинальная...
- Page 5 Gebruikshandleiding / Installation sheet / Mode d’emploi / Manual de operatiòn / Инструкция по установке / Gebrauchsanweisung / / دﻟﯿﻞ اﻻﺳﺘﺨﺪام安装手册 Protected against dust particles and the ingress of water when the luminaire is submerged Correct disposal of this product (Waste electrical & electronical equipment) to a maximum depth of 1m for a duration of less than 30 minutes.
