Installation instruction
LOGIC S2 93011
6 213 492 811 931
= ANO
LOGIC S2 93030
6 213 492 811 932
= ANO
LOGIC S2 93055
6 213 492 811 933
= ANO
LOGIC S2 93530
6 213 492 811 952
= ANO
LOGIC S2 93555
6 213 492 811 953
= ANO
110mm
4"-5/16
4mm
3/16"
85mm
3"-3/8
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Application
Floor recessed
For indoor & outdoor use
Color Finish
110mm
4"-5/16
ANO - Alu anodized
Light source
1 x POWERLED WHITE 7,1W
Product description
Anodised aluminum housing with hardened glass cover
For 350mA-DC current controlled, class 2 power limited circuits only.
Do not interconnect in parallel.
Anti-wicking cable 2x20 AWG included
Suitable for dry, damp or wet locations, floor recessed
Dust-tight - Protected against the effects of temporary immersion
Weight: 1,3lbs 0,6kg
Accessories not supplied (required)
6 213 19 08
Options (not supplied)
6 216 12 00
6 216 12 02
NORTH AMERICAN EDITION
GENIE BOX 80 S / 90 S
IP67 CONNECTOR 3P
LOGIC S2 A
IP67
Conforms to ANSI/UL Std. 2108
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update ALLU 03/01/2019
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for deltalight LOGIC S2 93011
Summary of Contents for deltalight LOGIC S2 93011
- Page 1 6 216 12 00 JUNCTION BOX 6 216 12 02 IP67 CONNECTOR 3P NORTH AMERICAN EDITION Conforms to ANSI/UL Std. 2108 Cert. to CAN/CSA Std. 22.2 No. 250.0 HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca Last Update ALLU 03/01/2019...
- Page 2 LUMINAIRES MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN. CHECK WITH LOCAL AND NATIONAL CODES FOR PROPER INSTALLATION. TO PREVENT ELECTRICAL SHOCK, DISCONNECT ELECTRICAL SUPPLY BEFORE INSTALLATION OR SERVICING NORTH AMERICAN EDITION HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca...
