ENGO CONTROLS EPIR Quick Manual

EPIR
EPIR | ZigBee Motion Sensor
Quick Guide
Works with Powered By
GET IT ON
Available on the
Ver. 1.1
Release date: XI 2024
Soft: V1.0.6
Producer:
Engo Controls sp. z o.o. sp. k.
43-262 Kobielice
Rolna 4 St.
Poland
www.engocontrols.com
Device description
3
1
2
4
1. Function button
Pressing for 10 seconds activates
pairing mode and factory reset
2. Sensor area
3. LED diode
Flashing red - active pairing mode
with the application
Single red flash - motion detection
4. Stand
The sensor can stand alone or be
mounted on a stand
Technical specifications
Power supply CR2450
Comunication ZigBee 3.0, 2.4GHz
Dimensions [mm] 84 x Φ34
Introduction
The battery-powered motion sensor is not only a tool for detecting movement, but
when combined with the app, it enables the automation of many everyday tasks.
Detection of movement can trigger a multiple actions, such as switching ON/OFF
lights, starting the hot water pump or initiating advanced scenarios with devices on
the Zigbee 3.0 network. The internet gateway is required for installation in the app.
Product features
Works with ENGO Smart (Compatible with Tuya App)
ZigBee 3.0 communication standard
Motion detection
Detection angle 150˚, detection distance 7m
Product Compliance
This product complies with the following EU Directives: 2014/53/EU, 2011/65/EU.
Safety information
Use in accordance with national and EU regulations. Use the device only as intended,
keeping it in a dry condition. The product is for indoor use only. Installation must be
carried out by a qualified person in accordance with national and EU regulations.
Installation
Installation must be performed by a qualified person with appropriate electrical qual-
ifications, in accordance with the standards and regulations in force in a given country
and in the EU. The manufacturer is not responsible for non-compliance with the in-
structions.
ATTENTION:
For the entire installation, there may be additional protection requirements, which the
installer is responsible for.
