ENGO CONTROLS DOOR EDOORZB Quick Manual

EDOORZB | ZigBee Door/Window Sensor
Quick Guide
Producer: Distributor:
Engo Controls S.C. QL CONTROLS Sp z o.o. Sp. k.
43-200 Pszczyna 43-262 Kobielice
3E Górnośląska St. 4 Rolna St.
Poland Poland
www.engocontrols.com
DOOR
Introduction
EDOORZB is a battery-operated magnetic sensor, compatible with the ZigBee 3.0
standard. A change in the state of the device automatically sends a signal to a
ZigBee Internet gateway (Engo EGATEZB). It can be used to create rules for the
operation of home appliances (scenes) and where you need information about
the opening or closing of doors, windows, garage doors, etc.
Using the Engo Smart app, it is possible to create a relationship between the
window opening sensor and the room temperature thermostat (e.g. if the
window is opened, the heating or air conditioning is turned off). The opening is
detected by the distance between the sensor and the magnet.
The product is designed for indoor use only.
The sensor must be combined with a universal ZigBee 3.0 gateway (Engo EGATEZB).
Product Compliance
This product complies with the following EU Directives: 2014/53/EU, 2011/65/EU

Technical Informations

Power supply
Communication
Ver. 1
Date of issue: IX 2022
Dimensions

EDOORZB installation

1
Remove the battery cover.
Stick the sensor and magnet to the frame and sash of the door / window,
CR2450
ZigBee 3.0, 2.4GHz
72x42x16 mm
2
Remove protective film of the sensor.
3
no more than 5mm from each other.

Explanation for LED indicator

LED indicates current status
of the device
LED INDICATOR DEVICE
STATUS STATUS
This mode is triggered by
Green
The LED The device is in
long button press
flashes pairing mode
(reset button hold for 8 sec.).
Device is properly connected to
Single flash of the the device sends
the network and app can receive
Green LED information to the app
information from sensor.

Installation of the door sensor in the app

Make sure your router is within range of your smartphone. Make sure you are
connected to the Internet. This will reduce the pairing time of the device.

STEP 1 - DOWNLOAD ENGO SMART APP

Download the ENGO Smart app from Google Play or Apple App Store and install
it on your smartphone.
DESCRIPTION
