- Page 1 INSTALLATION MANUAL 2021 Copeland commercial HVACR variable frequency drive – EVH series...
- Page 2 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
-
Page 3: Table Of Contents
Step 1 – EVH drive overview Receiving and inspection Real time clock activation Rating label Keypad button overview Nomenclature Step 2 – Copeland EVH drive installation Dimensions and weights Mounting FR0 mounting instructions FR1 mounting instructions FR2 mounting instructions FR3 mounting instructions... -
Page 4: Safety Precautions
Due to the and dangerous operation charge in the capacitors, these parts may still be live after disconnection. Fit appropriate warning signs 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 5: Step 1 - Evh Drive Overview
Receiving and inspection The Copeland EVH series VSD has met a stringent series of factory quality requirements before shipment. It is possible that packaging or equipment damage may have occurred during shipment. After receiving your Copeland series VSD, please check for the following: Table 1. -
Page 6: Rating Label
Rating label/carton label Keypad button overview 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 7: Nomenclature
8: 48vdc IP54=54 150=150A F: Internal EMI filter 7: 74vdc 9D9=9.9A E: Onboard DC choke & EMI filter 3: 350vdc 025=25A N: No EMI filter, no choke 6: 650vdc 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 8: Step 2 - Copeland Evh Drive Installation
(340.7) (888.5) (753.0) (707.0) (288.0) (282.0) (220.0) (220.0) (9.0) (70.0) 14.61 40.75 33.27 31.38 19.13 18.90 15.75 15.75 0.35 246.91 (371) (1035) (845) (797) (486) (480) (400) (400) (112) 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 9: Mounting
(144) 11.81 3.94 (300) (100) (260) 3.15 6.30 11.81 7.87 (80) (160) (300) (200) (395) 3.15 6.30 15.75 12.99 230V: 435 (739) (80) (160) (400) (330) 480V/600V: 400 (679) 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 10: Fr0 Mounting Instructions
2. US version FR0 without EMC kit, there are no magnetic ring and EMC grounding plates, but it is necessary to connect the output cable shield to the bottom metal surface with a M4*10 screw 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 11: Fr2 Mounting Instructions Fr3 Mounting Instructions
FR2 mounting instructions FR3 mounting instructions Step 1: Step 1: Step 2: Step 2: 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 12: Fr4 Mounting Instructions Fr5 Mounting Instructions
FR4 mounting instructions FR5 mounting instructions Step 1: Step 1: Step 2: Step 3: Step 2: Step 4: 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 13: Fr6 Mounting Instructions
3/8-inch screws and four M8 or 3/8-inch nuts with an M8 or 2/8-inch wrench. The opening dimensions on the mounting plate should follow required dimensions (refer to the drive mounting template printed on the outside carton). 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 14: Ground Wiring
Ground wiring Warning! Connect only in voltage-free state! Clamp install: For screw torques and wire stripping by frame please see picture For FRO only 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 15: Grommets Install
Rubber grommet installation instructions Step 1: Step 4: Step 2: Step 5: Step 3: Step 6: 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 16: Input Power And Motor Cable Stripping Lengths
• Strip the motor and power cables as shown above. • Both UL and IEC tools may be used • Applies to strained wire, solid wire, or ferrule installations 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 17: Circuit Breakers
• Earthing conductor size is determined by the maximum overcurrent device rating used ahead of the drive according to UL 508C Table 6.4. • If power cubes or bypass are used, a UL listed class RK5, J, T or equivalent fuse is recommended. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... - Page 18 Table 5. So, if phase conductor size is changed, earthing conductor size should also be changed accordingly. • If power cubes or bypass are used, a Class gG/gL fuse is recommended. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
- Page 19 • Earthing conductor size is determined by the maximum overcurrent device rating used ahead of the drive according to UL 508C Table 6.4. • If power cubes or bypass are used, a UL listed Class RK5, J, T or equivalent fuse is recommended. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
- Page 20 5-1:2007 Table 5. So, if phase conductor size is changed, earthing conductor size should also be changed accordingly. • If power cubes or bypass are used, a Class gG/gL fuse is recommended. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
- Page 21 • Earthing conductor size is determined by the maximum overcurrent device rating used ahead of the drive according to UL 508C Table 6.4. • If power cubes or bypass are used, a UL listed Class RK5, J, T or equivalent fuse is recommended. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
-
Page 22: Panel Mounting
For fans, make sure it is blowing air in the correct direction. If it is running in reverse, please see the box in the above diagram. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 23: Step 3-Control Board Layout
Step 3—Control board layout 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 24: I/O Terminal Connections
+10 V for AI1, it is important to wire AI1—to ground (as shown by dashed line). If using +10 V for AI1 or AI2, terminals 3, 5, and 6 need to be jumpered together. • AI1+ and AI2+ block that it can support 10K potentiometer. 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series... -
Page 25: Step 4 - Drive Startup And Setup
If this was pressed at the first question, the Startup Wizard will be cancelled. Once you have connected power to your Copeland EVM frequency converter, and the Startup Wizard is enabled. Follow these instructions to easily set up your device. -
Page 26: Main Menu Navigation
For any further explanations of the below items please see Copeland AE bulletin AE-1466. Information for Items 6-13 can be found in Copeland mobile or OPI for the specific compressor model. For general motors, on the nameplate. Now the Startup Wizard is done. It wont show again on the next power up. - Page 27 2020ECT-37 (1/21) Copeland commercial HVACR variable frequency drive – EVH series...
