Starting the Switch, on page 12 Safety Before you install, operate, or service the switch, see the Regulatory, Compliance, and Safety Information for the Cisco Nexus 3000 and 9000 Series content for important Safety Information. Warning Statement 1071 Warning Definition...
Page 2
Note Statement 407 Japanese Safety Instruction You are strongly advised to read the safety instruction before using the product. https://www.cisco.com/web/JP/techdoc/pldoc/pldoc.html When installing the product, use the provided or designated connection cables/power cables/AC adapters. Warning Statement 1017 Restricted Area This unit is intended for installation in restricted access areas.
Page 3
Installing the Chassis Safety Warning Statement 1028 More Than One Power Supply This unit might have more than one power supply connection. To reduce risk of electric shock, remove all connections to de-energize the unit. Warning Statement 1003 Power Disconnection To reduce risk of electric shock or personal injury, disconnect power before removing or replacing components or performing upgrades.
Page 4
Installing the Chassis Safety Warning Statement 1024 Ground Conductor This equipment must be grounded. To reduce the risk of electric shock, never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available.
Installing the Chassis Installation Options with Rack-Mount Kits Warning Statement 1055 Class 1/1M Laser Invisible laser radiation is present. Do not expose to users of telescopic optics. This applies to Class 1/1M laser products. Installation Options with Rack-Mount Kits The rack-mount kit enables you to install the switch into racks of varying depths. Position the switch with easy access to either the port connections or the fan and power supply modules.
Installing the Chassis Unpacking and Inspecting a New Switch Step 3 Include one or two power sources at the rack. For AC power, provide a power receptacle. Step 4 Include one or two power sources at the rack. For DC power, provide a circuit breaker with terminals for connecting power cables.
• Antistatic mat or antistatic foam. • Grounding cable sized according to local and national installation requirements; the required length depends on the proximity of the switch to proper grounding facilities. Cisco provides a 6 AWG lug in the accessory kit.
This switch does not support port-side exhaust configuration. Rack-Mount the Chassis in a 4-Post Rack This section describes how to install the Cisco N9364E-SG2-Q with kit 8K-2RU-KIT-S/8K-2RU-KIT-L. Caution If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Page 9
Installing the Chassis Rack-Mount the Chassis in a 4-Post Rack Warning Statement 1074 Comply with Local and National Electrical Codes To reduce risk of electric shock or fire, installation of the equipment must comply with local and national electrical codes. Warning Statement 1032 Lifting the Chassis To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles...
Installing the Chassis Grounding the Chassis c) Repeat Step 1b with the other rack-mount bracket on the other side of the switch. Step 2 Install the two rack-mount guides on the chassis. a) Position a rack-mount guides on the side of the chassis with its two holes aligned to the two screw holes on the side of the chassis, and use two M4 flat-head screws to attach the guides to the chassis.
Page 11
Installing the Chassis Grounding the Chassis Ground the chassis. If you are using a 2-post rack, attach a customer-supplied grounding cable. Attach the cable to the chassis grounding pad and the facility ground. If you are using a 4-post rack, ensure that your chassis is grounded through the rack mount system or the power cable (AC or HVDC).
Input Current Input Frequency Output Power Supply Unit PIDs Switches (Max) PSU3KW-HVPI Cisco Nexus 200-277V 50-60Hz 3000W 9364E-SG2-O Before you begin • The switch must be installed and secured to a rack or cabinet. • The switch must be adequately grounded.
Page 13
A setup utility automatically launches the first time that you access the switch and guides you through the basic configuration. For instructions on how to configure the switch and check module connectivity, see the appropriate Cisco Nexus 9000 Series Configuration Guides.
Page 14
Installing the Chassis Starting the Switch Installing the Chassis...
