Summary of Contents for CAME-TV WAERO PRO
- Page 1 WAERO PRO USER MANUAL V 2.5.2...
- Page 2 CAME-WAERO Wireless Intercom System Thank you for choosing our product. It features advanced 1.9G DECT technology with built-in dual antennas for clear calls and stable connections. It supports up to 8 sub-devices without a HUB, allowing 9 people to talk simultaneously. The grouping function enables flexible team communication.
- Page 3 CAME-WAERO Wireless Intercom System Quick Start Guide Open the battery compartment, insert the battery, and power on. *The hinge parts come in two colors: red and blue, to distinguish between the Master headset and the remote headsets. The Master headset needs to be powered on each time it is used, while the remote headsets can be flexibly turned on or off depending on the number of users.
- Page 4 CAME-WAERO Wireless Intercom System Turn on the microphone Mute on: Microphone off when the boom is up, listen only, no speaking. Mute off: Boom down, microphone on, listen and speak. Please note the arrow indicator on the end of microphone. Clear and stable communication can only be achieved and is when the arrow is pointing directly at your mouth...
- Page 5 CAME-WAERO Wireless Intercom System Select to use in the same group or in groups. Group B Button Group A Button Total 9 members can be arbitrarily divided into 2 subgroups, with only members within the same group able to communicate with each other. ①...
- Page 6 CAME-WAERO Wireless Intercom System Best Practice Suggestions for Optimal Performance: ① All remote headsets should operate around the master headset with in the working range. ② There should be no obstacles between the remote headsets and the master headset. 1700ft(518m) 1700ft(518m) Master...
- Page 7 CAME-WAERO Wireless Intercom System Product Structure Overview Headband Size Adjustment Function Buttons Switch Function ChargingBattery Indicator Indicator Microphone USB-C Input Battery Compartment...
-
Page 8: Function Buttons
CAME-WAERO Wireless Intercom System Function Buttons Group A / Volume Up Button Long press to enter Group A, short press to increase volume. MF Button Long press for broadcast (unique to the master device), short press to announce current group. Group B / Volume Down Button Long press to enter Group B, short press to decrease volume. - Page 9 CAME-WAERO Wireless Intercom System Charging and Power Indicator USB-C Charging Red light flashing Battery charging Green light Battery fully charged Red & Orange light flashing USB-C powered, no battery Battery Only（No Input on USB-C） Red light Low battery Orange light Medium battery Green light High battery...
-
Page 10: Troubleshooting
CAME-WAERO Wireless Intercom System Troubleshooting This product is pre-paired when shipped, and usually re- pairing is not necessary. If an individual remote headset can not communicate, re-pairing is required. Here's how: Pairing Method: · On the master headset, press both the A and B group buttons simultaneously until the indicator starts flashing blue and red alternatively. - Page 11 CAME-WAERO Wireless Intercom System Reset Operation If the master headset or remote headset encounters pairing issues, you can try reset the master headset and then re-pairing. · Partial Reset: In the pairing state of the master headset, remote headsets that are not powered on will be cleared. ·...
- Page 12 CAME-WAERO Wireless Intercom System Pairing Scenarios If two out of the five remote headsets in the set have communication issues, please follow these steps: ① Turn on the power of all five headsets (remote headsets that are not powered on will be automatically cleared of pairing when the master headset pairs).
- Page 13 CAME-WAERO Wireless Intercom System FCC Regulatory Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ① this device may not cause harmful interference, and ② this device must accept any interference received including interference that may cause undesired operation.
- Page 14 CAME-WAERO Wireless Intercom System If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ·...
-
Page 15: Aftersale Services
We are committed to providing you with top-notch after-sales service and support to ensure your satisfaction and address any concerns you may have promptly. Email: Americas: americas@came-tv. com Outside Americas: europe@came-tv.com Follow Us: https://www.facebook.com/CameTvGear/ https://www.instagram.com/cametv/ https://www.youtube.com/c/CameTVgear/videos...
