OXI INSTRUMENTS ONE MKII Quick Start Manual

Get the full manual here
oxiinstruments.com/oxi-one/manual
Sequencer Modes
Hold [Shift] + Press [1] - [8] to open the settings for the chosen sequencer. Mode can be changed in this menu by turning Knob 4.
Mode Grid
Monophonic
1 note per step, 1 track.
Ideal for simple leads, bass lines and drum
beats based on a single monophonic track.
To transpose:
C C# D D# E
Seq [1] - [8] + [Pad] + Turn Knob (2)
Steps
Chord
1 chord per step, 1 track
Select from predefined chord libraries. In
keyboard mode, a library of chords can be
selected into a pad group.
C C# D D# E
To transpose:
Steps
Seq [1] - [8] + [Pad] + Turn Knob (2)
Stochastic
1 note per step, 1 track
Feed a generative engine with notes
and then control the rhythmic and
melodic randomization.
C C# B D D# E
Notes Control
Keyboard Mode
Press [Keyboard] to transform the pad grid into a chromatic style keyboard, drum
pads or sequence specific controller. Hold [Shift] + [Keyboard] to activate preview
mode and audition any pressed step on the sequencer mode.
cv gate
C C# D D# E F F# G G# A A# B
First set of pads affect the note pitch which controls of the function
can be accessed typically by the right side pads.
MIDI & CV Outs
To set the MIDI Output for each sequencer, Hold [Shift] + Seq [1] - [8].
Turn Knob 1 (Ch). Multitrack has a channel per track. Tap multi track
column 1 to select the track to edit.
SEQ1 Setup 1/3
Ch Out PC
+
1 A ALL OFF
Tag us on social media:
@oxiinstruments, #oxione #oxiinstruments
Mode Grid
Polyphonic
7 notes per step, 1 track.
Create chords or note groups.
Offers more flexibility than chord mode.
To transpose:
C
Seq [1] - [8] + [Pad] + Turn Knob (2)
Multitrack
1 notes per step, 8 tracks.
Each row represents a mono track. Each
track can control an independent channel
instrument.
C
Matriceal
1 Note per step, 4 tracks.
Generates melodic or rhythmic phrases
into a 16 step trigger pattern. Overlaid
with 9 dynamic parameter matrices.
C
Keyboard arp can also be accessed by pressing
[Arp] which automatically selects keyboard mode
for some sequencers.
1
Knob 1 (Type) Turns the Arp on or off.
To set the CV Output, Hold [Shift] + press [Gen].
For each sequencer row, columns 1-8 activate CV 1-8 outputs and
columns 9-16 activate the equivalent Gate outputs 1-8.
CV
Mode
+
MONO
Getting started
Power On
USB-C powers or charges.
Tap On/Off to turn on or hold on/off
to shut down OXI ONE.
1
Connect by MIDI or CV/Gate an DAW or an
C# D D# E
Steps
MIDI Channel: [Shift] + [1], Then turn Knob 1
Sequencer View
Sequencer view can be considered the main 'home' location in the structure of OXI ONE. This is the default start up view and can quickly be
accessed by double tapping the [Back] button. The [Back] button can be used to navigate back in menus and holding [Shift] + pressing
[Back] opens the configuration menu options. Actual details will be based on the sequencer mode.
C# D D# E
Steps
Swing.
Amount for the sequencer
Sequencer Mode
Tempo BPM
Time division
Sequencer or last track
C# D D# E
4 tap / turn encoders
Edit a primary value or
choose an option
Editing
Activate or deactivate step.
Quickly tap [Pad].
Step parameter page.
Hold [Pad].
Gates Muting steps.
Hold last [Mute] + tap [Pad].
Advanced Performance Sequencer
Select Sequencer
Tap [1] - [8] to select a sequencer.
Hold [Shift] + [1] - [8] for the settings
including to select the sequencer mode.
2 3
Connect Gear
Tap some pads on the piano roll style
external instrument. grid view to set notes.
Tap any step [Pad] to active or deactivate.
MONO 50% F INT
105.0
Pattern 3
1/16 CHROMATIC - C2
MONO 50% F INT
VEL OCT GATE REPT
105.0
Pattern 3
1 2 3 4
1/16 CHROMATIC - C2
BPM SWNG SCAL ROOT
1 2 3 4
Turn Tap
Open grid column editor, a menu or to
confirm a function selection.
Activate or deactivate tie.
Tap
Hold 1st [Pad] + tap last [Pad]
Select sequencer
Hold
Tap [1] - [8]
Sequencer Mute / Activate.
+
Hold [Mute] + tap [1] - [8]
Play the Sequencer
Tap [Play] start playback.
Tap [Stop] to stop and reset to the start.
4 5
Program Steps
F. Follower Mode On
Clock source. Internal or External
Battery state indicator
Active pattern
Scale, root and octave
Primary parameters
Secondary [Shift] parameters
Represent displayed options
[Shift] + Turn
Edit a secondary value or
choose an option
+
