- Page 1 Installation, Operation, and Maintenance Manual F-W-760 Product code: Description: FLOOR TO WALL RAIL, 760mm x 760mm IOM-F-W-760 Rev 2...
- Page 2 Dimensions are provided as a guide only - some variation may occur due to manufacturing tolerances. NYMAS Group accepts no liability whatsoever for personal injury or damage to product(s) or property that has been caused by incorrect assembly, installation, modification or use of this product. Failure to install/use this product in line with the instructions in this manual will invalidate any warranty and may affect product safety.
- Page 3 Acidic, alkaline, chlorine and solvent based cleaning products. Steam cleaners. DO NOT use cleaning components containing iron (e.g., scour sponge, steel wool). Disposal: Dispose of this product and packaging in line with local authority regulations. Page 3 of 8 IOM-F-W-760 Rev 2...
- Page 4 Product dimensions: (mm) PER MOUNTING PLATE Page 4 of 8 IOM-F-W-760 Rev 2...
- Page 5 Tools required: What's in the box: Pre-installation: CAUTION - Ensure safety warnings section of this document has been read. Page 5 of 8 IOM-F-W-760 Rev 2...
- Page 6 Determine position for fixing the rail, ensuring floor and wall surfaces are smooth, level and capable of taking the required loads. Using a pencil, plot the hole positions on the floor surface. Page 6 of 8 IOM-F-W-760 Rev 2...
- Page 7 A laser / level / plumbline may assist in ensuring the vertical section of the rail is vertical. Drill the required fixing hole locations to the correct diameter and depth for the chosen fixings. FLOOR WALL Page 7 of 8 IOM-F-W-760 Rev 2...
- Page 8 Perform a visual check to ensure the positioning of the rail is correct and that it is safe to use. If you have any questions regarding the product, please contact us at: sales@nymas.co.uk Page 8 of 8 IOM-F-W-760 Rev 2...
