Tera DLT-10 Quick Start Manual

Data Loggers
The new series of DLT-10 and DLT-11 loggers are portable electronic devices with an OLED display and a USB interface. The logger measures and records temperature
and relative humidity data into its internal non-volatile memory. These devices are used for monitoring temperature and relative humidity.
The logger is equipped with a built-in Swiss-made temperature and humidity sensor. In addition to the built-in sensor, the logger can support up to two external
temperature sensors connected via a USB port. The logger is powered by a replaceable lithium battery, which lasts for several years depending on the usage
conditions and recording interval. It connects to a computer through a USB port to set parameters and download recorded data using the free LoggerSoft software.
Data stored in the logger's memory can be saved in CSV or PDF formats.
Key Features
• Measurement of air temperature and relative humidity
• Data recording in a user-defined mode
• Display and recording of alarm conditions
•
USB interface for reading data and configuring the logger's operation mode
• Compatibility with Windows XP, 7, and 10
• Display of modes, alarms, and current sensor readings on a high-contrast OLED display
•
Flexible configuration of the logger's operation mode using the free LoggerSoft software
Design features
Data logger is made from polycarbonate case with a standard USB connector, high-contrast OLED display and two control buttons. Logger is also supplied with a
magnetic mount.
Model
Q-ty of Measuring Channels
Available channel configurations²
Indication
Logging Interval
Battery Type
Battery Lifespan (by regular conditions)
Memory (readings)
Sensor Curve
Operating Temperature Range, °С
Accuracy, °С
Response Time, sec
Sensor Curve
Operating Humidity / Temperature Range
Humidity / Temperature accuracy
Response Time, sec
Sensor Curve
Operating Temperature Range, °С
Accuracy, °С
Connection
¹ - External temperature probe is supplied separately
² - ET - external temperature probe, IT - internal temperature sensor, IHT - internal RH and temperature sensor
³ - relative humidity accuracy is 3% (10...90%), ≥ 4% (0...10% and 90...100%)
⁴ - Т - operating temperature range
PJSC TERA
Vsikhsvyatska str, 7, Chernihiv, Ukraine
Tel: +38 (0462) 606-740, 606-840
info@ao-tera.com.ua
www.ao-tera.com.ua
89 mm
TECHNICAL SPECIFICATIONS
DLT-10 DLT-10-Pt¹ DLT-10-2Pt¹
1 2 3
IT IT + ET IT + 2 ET
ТМP116
-30...60
0,5
180
Pt1000
-50...100, -50...250,
-50...500, -100...100
-
± (0,4 + 0,002 x |T|⁴)
USB3
Dealer in Ukraine:
SV Altera, Kyiv
Tel: +38 (044) 49-61-888, 49-61-818
office@sv-altera.com
www.svaltera.ua
DLT-10-TC¹ DLT-10-AT DLT-10-2AT
Logger Specifications
2 2
IT + ET IT + 4-20 mA 2 х 4-20 mA
OLED 0.96', resolution is 128х64 pixels, display by pressing a button
From 1 minute to 1 hour
1 bettery (½ AA 3,6 V 1Ah 14250)
Over 5 years
2 621 440 (RH & Temp)
Specifications of Internal Temperature Sensor
Specifications of Internal Humidity and Temperature Sensor
-
Specifications of External Temperature Probe
ХА (К) 4-20 mА
-40...250, 0...500,
Set by the logger
0...850, 0...1250
± 2,5 (up to 375°С)
or ± 0,0075 x T 0,5 %
(over 375°С)⁴
By USB cable
Dealer in Moldova:
ElectroTechnoImport, Chișinău
Tel: +37 (322) 844-688
office@electroimport.md
www.electroimport.md
DLT-10 & DLT-11
DLT-11 DLT-11-Pt¹
2 2 3
IHT IHT + ET
-
SHT31
-30...60 °С / 0...100%
0,5 °С / 3%³
180
Pt1000
-50...100, -50...250,
-50...500, -100...100
-
± (0,4 + 0,002 x |T|⁴)
USB3
DLT-11-2Pt¹
4
IHT + 2 ET
