VALKYRIE VK02 Installation Manual

VK02
LCD Installation Manual
01
Step 1: Insert the mini HDMI and Type-C plugs into the corre-
sponding sockets on the back of the screen.
Vertical GPU
02
Step 1: Remove the graphics card baffle bracket, move the perforat-
ed baffle to the first slot position, and then pass the wire through the
baffle hole.
1/2
NOTE 1:The illustrated RED LINES represent cables.
NOTE 2:The LCD secondary screen needs to be connected to the
HDMI interface of the graphics card.
If the number of interfaces is insufficient, you need to purchase an
adapter cable, such as DisplayPort male to HDMI female.
Step 2: Cable routing
*Please pre-assemble the cables before assembling the hardware to avoid difficulties in routing the cables after the hardware assembly has been completed.
*When starting the windows system for the first time, do not connect the HDMI and USB interfaces to the graphics card/motherboard to prevent the system from recognizing the
secondary screen as the main.
Step 2: Tighten the screws to fix the baffle.
With VK02 LCD Version
1x 10.1" Touch Screen
LCD Screen
Step 3: Reintall the graphics card bezel bracket.
Screen Brightnes
Adjustment
Power Button
Step 4: Plug HDMI into the graphics card. Connect the USB inter-
face to the motherboard USB interface.
*Start the computer and the monitor normaly then
connect the HDMI and Type-C interface.
Step 7: Pass the cables through the baffle as shown in the image.
Plug HDMI into the graphics card and connect the USB interface
to the USB port on the motherboard.
*Start the computer and the monitor normaly then
connect the HDMI and Type-C interface.
