ECHO ROWER
HOW TO REPLACE THE GLIDE RAIL
IMPORTANT SAFETY INFORMATION
DISCLAIMER:
Resistance training, gymnastics training, and activities at height
are potentially dangerous and may lead to severe injury or even
death. Use common sense when training, obtain instruction in the
proper execution of movements, and understand your limitations.
This equipment must only be used by competent and responsi-
ble persons. Obtaining instruction in appropriate techniques and
methods of use is your own responsibility. You assume all risks and
responsibilities for all damage, injury or death which may occur
during or following incorrect use of this equipment in any matter
whatsoever. Rogue Fitness bears no liability beyond the replace-
ment value of the equipment in question.
Rogue Fitness • 545 E 5th Ave. Columbus, Ohio 43201 • Customer Service: 614-358-6190 • Team@RogueFitness.com
WARNING:
MISUSE OF THIS PRODUCT CAN RESULT IN SEVERE INJURY.
Both Rogue Fitness and buyer disclaim any express or implied
warranty, including, without limitation, warranties or merchant-
ability and/or fitness for a particular purpose with respect to the
equipment. Buyer assumes all liability to use of equipment.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ECHO ROWER and is the answer not in the manual?

Questions and answers

Summary of Contents for ROGUE ECHO ROWER

  • Page 1 Rogue Fitness bears no liability beyond the replace- ment value of the equipment in question. Rogue Fitness • 545 E 5th Ave. Columbus, Ohio 43201 • Customer Service: 614-358-6190 • Team@RogueFitness.com...
  • Page 2 STEP 1 - HOW TO REPLACE THE GLIDE RAIL Tools Required: Parts Required: • Flat Head Screwdriver • Replacement Glide Rail • 11mm Wrench • Warning: When handling the glide rail the • T27 Wrench use of gloves is required to prevent injury. •...
  • Page 3 STEP 2 • Using the T27 and 11mm wrenches, remove the 4 bolts and nuts holding the plastic glide rail end cap in place. • With the end cap removed, slide the seat off the rail. page 3 of 5...
  • Page 4 STEP 3 • Wearing gloves, use a flat head screwdriver to carefully pry up the end of the glide rail. • Gripping the end of the rail, peel up and away from the rower to detach it from the main beam. •...
  • Page 5 STEP 4 • Peel the backing off the double stick tape. • Working towards the rear of the rower, applying light pressure, secure the part to • With the tape facing down, insert one end the beam top. of the glide rail under the lip at the front of the main beam, pushing it forward until it •...
  • Page 6 STEP 5 • With the part in place, use a clean rag to press down on the rail working from the front to the rear of the rail. • This downward pressure helps the double stick tape properly adhear to the beam. page 6 of 5...
  • Page 7 STEP 6 • Before reinstalling the seat, check the • Reattach the end cap, ensuring the top rollers for any signs of damage or wear. If and bottom profiles are properly orientated. necessary, clean them using a clean rag • Glide rail installation complete. and a mild, multi-purpose cleaner.
