VPC13-C33-G1
VPC15-C53-G1
Chromebox Slot-in PC
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
Model No. VS20584
P/N: VPC13-C33-G1 | VPC15-C53-G1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chromebox VPC13-C33-G1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ViewSonic Chromebox VPC13-C33-G1

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
  • Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
  • Page 3: Table Of Contents

    Contents Introduction ..............4 Rear View ........................4 Initial Setup ..............5 Installing the Chromebox ..................5 Making Connections ............ 6 Network Connection....................6 USB Connection ......................6 Using the Device ............7 Selecting an Input Source ..................7 IFP Series ......................... 7 CDE Series........................ 8 Appendix ..............
  • Page 4: Introduction

    Introduction Rear View Number Item Description Antenna Wi-Fi antenna interface. LINE-Out Audio out for connected headphones or microphones. USB C USB 3.2 port; Type-C interface. HDMI Extend content out to another display device. Standard RJ45 (10M/100M/1G) internet connection port. NOTE: This network port is only used for PC. USB 2.0 USB 2.0 port.
  • Page 5: Initial Setup

    Initial Setup Installing the Chromebox 1. Remove the slot-in PC cover of the display. NOTE:  Some IFP models may not have the slot-in PC cover. 2. Using the handle of the Chromebox, carefully insert it into the PC slot of the display.
  • Page 6: Making Connections

    Making Connections Network Connection To connect to the Internet or a network, connect one end of a RJ45 cable to the LAN port of the Chromebox, then connect the other end to your network. USB Connection USB peripherals such as keyboards, mice, storage devices, etc. can be connected to the Chromebox’s USB ports.
  • Page 7: Using The Device

    Using the Device Selecting an Input Source IFP Series To select an input source: 1. Tap the Settings icon from the toolbar to display the Input Soruce menu. 2. Tap the PC source. 3. Tap a blank area outside of the menu to exit. NOTE: ...
  • Page 8: Cde Series

    CDE Series Custom To select an input source: 1. Press INPUT/ on the remote control. 2. Press ▼/▲ on the remote control to select the PC source. 3. Press OK/ENTER on the remote control. 4. Press EPG/BACK/ on the remote control to exit. NOTE: ...
  • Page 9: Appendix

    Appendix General Specifications Category Item Specifications 1 x HDMI out (Max: 3840 x 2160 @ 60 Hz) 1 x RJ45 (LAN) (10M/100M/1G) 2 x USB 2.0 (5V/0.5A) 2 x USB 3.2 Gen. 1 (5V/0.9A) Ports 1 x USB Type C Microphone/Headphone combo jack (3.5 mm) 2 x Antenna jacks (2.4G/5G dual bands)
  • Page 10: Antenna Information

    Antenna Information Category Specifications Antenna Type Dipole Manufacturer INPAQ TECHNOLOGY Model Name DAM-L14-B4-N0-000-04-02 2400~2483.5MHz: 1.49 (dBi) 5150~5250 MHz: 2.91 (dBi) 5250~5350 MHz: 2.06 (dBi) Antenna Gain 5470~5725 MHz: 1.59 (dBi) 5725~5850 MHz: 2.81 (dBi) 5945~6425 MHz: 1.73 (dBi) Bluetooth/BLE 2400~2483.5 MHz 10 dBm IEEE 802.11b/g/n/ax 2400~2483.5 MHz...
  • Page 11: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement FCC ID: PD9AX211NG This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 12: Industry Canada Statement

    Industry Canada Statement IC ID: 1000M-AX211NG CAN ICES (B) / NMB (B) This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with Industry Canada license-exempt RSS standard(s): Operation is subject to the following Two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 13: Country Code Statement

    Country Code Statement For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. Pour les produits disponibles aux États-Unis/Canada du marché, seul le canal 1 à 11 peuvent être exploités. Sélection d’autres canaux n’est pas possible. IC Radiation Exposure Statement This device complied with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
  • Page 14: Ce Conformity For European Countries

    CE Conformity for European Countries The device complies with the EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and Radio Equipment Directive 2014/53/EU. https://www.viewsonicglobal.com/public/products_download/safety_ compliance/acc/VS20584_CE_DoC.pdf The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE).
  • Page 15 These devices comply with RF specifications when the device is used at 20 cm from your body. Operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. La bande 5150-5250 MHz est réservés uniquement pour une utilisation à...
  • Page 16: Declaration Of Rohs2 Compliance

    Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Actual...
  • Page 17: Indian Restriction Of Hazardous Substances

    Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...
  • Page 18: Copyright Information

    Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association.
  • Page 19: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTE:  You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...
