OWNER'S MANUAL AND OPERATING INSTRUCTIONS
GAS PRESSURE WASHER
3200 PSI, 2.4 GPM
Model: PWF3201SH
CUSTOMER SERVICE: 1-855-888-3598
Visit Our Website at: www.a-ipower.com
Email Our Technical Support at:
support@a-ipower.com
NOTICE: Do not use E85 or E15 fuel
in this product. It can damage the
engine and void your warranty. Only use
unleaded gasoline containing up to 10%
ethanol.
A-iPower Corp.
Fontana, CA 92337 USA
www.a-ipower.com
WARNING: SAVE THIS MANUAL FOR FUTURE REFERENCE
This manual contains important information regarding safety. Operation,
maintenance and storage of this product. Before use, read carefully and
understand all cautions, warnings, instructions and product labels. Failure
to do so could result in serious personal injury and/or property damage.
3
