Mockett WCS13 Manual

WCS13
!
·
To reduce the risk of electric shock use indoors.
·
For use on a normally dry work surface.
· If any malfunction occurs, do not attempt to disassemble or
repair.
· Avoid placing the charger in a high temperature environment
or near fire.
·
Allow enough clearance for part operation.
·
Do not place metal on the wireless charging area.
·
Metal objects, bank cards, digital IC cards should not be
placed between the charger and the phone to avoid damage
· Do not plug into another power distribution unit.
SPECIFICATIONS
·
6 ft. cord length.
·
USB-C ports are for charging use only.
· USB-C output is 45W MAX. shared per pair.
·
Wireless output is 15W MAX.
·
Recommended table thickness is 1/2" [12.50mm] MIN. to
3" [76.00mm] MAX.
· Mobile device must be equipped with a wireless charging
receiver (Wireless charging accessories not included.). Check
mobile manufacturer for compatibility.
1
Make a cutout in the desired location on your work surface.
Allow enough clearance for unit operation. DO NOT place unit
where cable is strained or trapped.
2025.02.20
WARNING
!
4-3/32" DIA.
[104.00mm]
TOP VIEW
3-5/32 DIA.
[80.00mm]
CUTOUT
TABLE OF CONTENTS
5-5/16"
[135.00mm]
3-1/8" DIA.
[79.00mm]
FRONT VIEW
2
Install the WCS13 into the cutout and make sure it is fully
leveled onto the work surface.
1
. . . . . . . . . . . . 1X WCS13
. . . . . . . . . . . 1X Lock Ring
7/16"[11.50mm]
4-19/32"
[117.00mm]
1/4"
[6.50mm]
WCS13
Work Surface
(Not Included)
