ARMATURA Avalon Series User Manual

Aesthetic swing barrier
Hide thumbs Also See for Avalon Series:
Table of Contents

Advertisement

Quick Links

Download this manual
SG5000 & SG5200
User Manual
User Manual
Avalon Series Aesthetic Swing Barrier
Date: February 2025
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Avalon Series and is the answer not in the manual?

Questions and answers

Related Manuals for ARMATURA Avalon Series

Summary of Contents for ARMATURA Avalon Series

  • Page 1 SG5000 & SG5200 User Manual User Manual Avalon Series Aesthetic Swing Barrier Date: February 2025 Version: 1.0...
  • Page 2 Without the prior written consent of ARMATURA LLC, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ARMATURA LLC and its subsidiaries (hereinafter the "Company" or "Armatura").

  • Page 3: About The Manual

    Avalon-S1000 & Avalon-S1200 User Manual referenced by this manual, even if Armatura has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors. Armatura periodically changes the information herein which will be incorporated into new additions/amendments to the manual.

  • Page 4: Safety Instruction

    If the top caps should be open and the device should be powered on for maintenance,  make sure: Power off the fan to prevent the operator from getting injured accidentally. P a g e |III Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 5 Do not aim the device at the sun or extra bright places. A blooming or smear may occur  otherwise (which is not a malfunction however), and affecting the endurance of sensor P a g e |IV Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 6 SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE  SURFACE ONLY. The instructions shall require connection of the equipment protective earthing conductor  to the installation protective earthing conductor. P a g e |V Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 7: Table Of Contents

    4. Terminal Description ......................23 4.1 Gate Control Mainboard Panels ..................23 4.2 Main/Sub Device Motor Control Board ................26 5. Wiring Instructions ........................ 28 5.1 Main-sub Location ......................28 P a g e |VI Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 8 8. Maintenance ........................... 35 8.1 Chassis Maintenance ..................... 35 8.2 Movement Maintenance ....................35 8.3 Power Supply Maintenance ................... 35 9. Troubleshooting ........................36 10. Packing List ........................... 37 P a g e |VII Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 9: Overview

    Avalon-S1000 & Avalon-S1200 User Manual 1. Overview The Avalon Series Swing Barrier represents a pinnacle of access control engineering, integrating advanced CGL assembly technology with precision-engineered security solutions. Utilizing tempered glass and acrylic components, the barrier delivers superior structural integrity and sophisticated design.

  • Page 10: Performance & Safety Features

    1.1.2 Performance & Safety Features Power-On Self-Test Automatically detects hardware and functional issues at startup.  Power-Off Fail-Safe Swing arms unlock during power failure for emergency evacuation.  Anti-Clamping Functionality P a g e |2 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 11: User Guidance

    Doors unlock automatically during power failure or fire alarm activation. Anti-Panic Functionality  Swing arms can be manually pushed open during emergencies. 1.1.5 Certifications CE, FCC Certified (Compliant with international safety and quality standards)  P a g e |3 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 12: Appearance

    Front View Side View 2.0"/50mm 70.87"/1800mm 7.87"/200mm Bottom View 10 - 0.63" x 1.22" (10-16mm x 31mm) 27.56"/700mm 6 - 3.15" x 1.18" 47.24"/1200mm (6-80mm x 30mm) 59.06"/1550mm P a g e |4 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 13 Front View Side View 70.87"/1800mm 7.87"/200mm Bottom View 10 - 0.63" x 1.22" (10-16mm x 31mm) 6 - 3.15" x 1.18" (6-80mm x 30mm) 27.56"/700mm 47.24"/1200mm 59.06"/1550mm P a g e |5 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 14 36.22"/920mm 25.59"/650mm Standard Lane Wide Lane / ADA Lane High-barrier Lane Dual-lane Standard Lane Wide Lane / ADA Lane Multi-lane Standard Lane Wide Lane / ADA Lane P a g e |6 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 15: System Components

    Convenient Verification Area* Status Indicator Verification Area Infrared Sensor Traffic Indicator Maintenance Door Barrier Material Backboard *This configuration provides an accessible design to accommodate individuals with mobility P a g e |7 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 16: Technical Specifications

    Compatible with external facial recognition systems Side mount option: RFID/QR Code/RFID+QR Code / Mobile Credentials Chassis Material Tempered Glass and High-carbon Steel Chassis Colour White (Standard), Customizable P a g e |8 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 17 Controller Armatura Controller: AHDU-1260/ AHDU-1460 (Optional) Under mount RFID, QR code & Mobile Credentials reader: (support model: Armatura EP10C & Armatura EP20 Series & Armatura VG10CKQ Series) under mount fingerprint reader: Armatura EP30CF Series under mount facial recognition terminal: coming soon...
  • Page 18 Anti-panic push opening in operation Wide walkway for wheelchair or easier access Accompanied wheelchair or child passage management (under mount facial recognition & Side mount RFID & QR code reader version) P a g e |10 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 19: Authentication Methods

    *The configuration on the left side of the picture above is accessible to persons with disabilities. Surface Mount Option: Mounting Pole (Compatible with FT10CMQ / OmniAC20 / OmniAC30). P a g e |11 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 20: Card Verification

    Access Controller. Try to keep the face in the centre of the screen during authentication. Please face towards the camera and stay still during face registration. P a g e |12 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 21 Avalon-S1000 & Avalon-S1200 User Manual Recommended Standing Posture and Facial Expression: Note: Please keep your facial expression and standing posture natural while enrollment or verification. NO ENTRY RFID RFID P a g e |13 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 22: Installation

    The reference figure is shown below: P a g e |14 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 23: Installation Cabinet

    Standard Lane Mounting Holes Marking template 10 - 0.63" x 1.22" (10-16mm x 31mm) 6 - 3.15" x 1.18" (6-80mm x 30mm) Wiring Holes 27.56"/700mm 59.06"/1550mm P a g e |15 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 24 Dig a recess 2.0" (50mm) deep with the dimensions shown below. For laying out pre-assembled components. Place the pre-assembled components into the recess and pour concrete to fix it in place. Pre-assembled components 62.99"/1600mm 7.87"/200mm P a g e |16 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 25 Then lay two 0.8" to 1.0" (20 to 25mm) diameter PVC pipes as shown below. After threading the cable out of the PVC pipe, pour concrete to f ix it in place. P a g e |17 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 26 Tighten the nuts to hold the cabinet in place. Don't tighten it completely until after you're sure it won't move anymore. The finished result is shown below: 3.9"/100mm Cabinet Pre-assembled components 2.0"/50mm P a g e |18 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 27: Detailed Installation Instructions

    Disassembly of maintenance door assembly Remove the maintenance door fixing screws from the top and then remove it with a glass suction cup. P a g e |19 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 28 Step 3 Put the Gantry Frames Back On After tightening the chassis, install the lower movement cover and then the maintenance door assembly. P a g e |20 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 29 It is recommended that warning lines be marked on the ground and used to alert users. A warning line can alert users to wait outside the line until the previous user completes the verification process and passes through the turnstile. P a g e |21 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 30 Avalon-S1000 & Avalon-S1200 User Manual P a g e |22 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 31: Terminal Description

    ZERO1:Closing position adjustment. After pressing ZERO1,  VALID1 lights up, manually adjust both swing gates to the Zero Adjustment closing position, then press ZERO1 again, VALID1 goes out. ZERO2:Invalid.  P a g e |23 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 32 TX: Transmit port of RS232 Interface  RS485 +: Positive port of RS485  -: Secondary port of RS485  Extended Input Used to implement extended functions Interface P a g e |24 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 33 10.(DB9) interface. Protection Lock Note: For normal operation, the switch must be turned back to the “WORK” position. Ethernet Customisable Ethernet communication interface. Interface P a g e |25 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 34: Main/Sub Device Motor Control Board

    NO: When the dialling code is set to the NO direction, the driver board is the main. When dialled in the direction of numbers, the driver board is the sub. P a g e |26 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 35 Encoder and motor hall wire access terminal Interface 24V-48V DC power supply input Power Input Clutch C+, C- U, V, W Motor Interface Three-phase power supply for motors PE Shielded Cable P a g e |27 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 36: Wiring Instructions

    5.1 Main-sub Location Sub Device Main Device Sub Device Sub Device Main Device Main Device Single-lane Dual-lane 4 Lines Sub Device 4 Lines Main Device Multi-lane P a g e |28 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 37: Slotting Position

    ECU-panel connection wire. Each main device is then powered individually. The following diagram shows how the different channels are wired. Wiring Instructions 5-core connecting wire(M-S) AC110/220V input FACP(Fire alarm) Access controller cable Single-lane Dual-lane Multi-lane P a g e |29 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 38: System Wiring Diagram

    Avalon-S1000 & Avalon-S1200 User Manual 5.4 System Wiring Diagram P a g e |30 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 39: Operation Process

    The access controller will send a signal to the revolving door control panel. After receiving the signal P a g e |31 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 40 The alarm signal will not be cancelled until the passenger retreats from the passage. The pedestrian can pass through the passage only after a valid card is successfully verified. P a g e |32 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 41: Machine Operation

    Entry & Exit: access requires verification Operation: Press the MODE (L) and WORK (R) buttons respectively to light the yellow lamps for L3 and R3. Entry Exit RFID RFID P a g e |33 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 42: Visual Indicator Description

    Green (Arrow): Standby. Red (Cross Icon): Door Closing LED Strip Visual Indicators: Indicates whether the gate can open the door when it receives the legal open signal. P a g e |34 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 43: Maintenance

    Perform the safety check on a weekly basis to ensure that the turnstile is safe and ready for user operation. P a g e |35 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 44: Troubleshooting

    When the gate is self-tested, the In the process of self-test, there are wing arm is not in the normal closing obstacles, please remove the obstacles, position! restart the self-test after power-on! P a g e |36 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 45: Packing List

    Avalon-S1000 Avalon-S1000 (Main and Sub) Power Cable Card L-type Ground Bolt M12*200 Washer Spring Washer Avalon-S1200 Avalon-S1200 Power Cable Card L-type Ground Bolt M12*200 Washer Spring Washer P a g e |37 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 46: Revision History

    Avalon-S1000 & Avalon-S1200 User Manual Revision History Revision Date Author Reviewer Description V1.0 02/13/2025 Julia.Huang Original Document P a g e |38 Copyright © 2025 ARMATURA LLC. All rights reserved.
