- Page 1 Avalon Series Aesthetics Swing Barrier Installation Guide Version: 1.0...
- Page 2 Revision History Description Revision Date Author Reviewer Julia.Huang Original Document V1.0 02/12/2025...
- Page 3 1 Overview Avalon-S1000 Avalon-S1200 Convenient Verification Area* Verification Area Traffic Indicator Barrier Material Status Indicator Infrared Sensor Maintenance Door Backboard This configuration provides an accessible design to accommodate individuals with mobility limitations.
- Page 4 2 Dimensions Avalon-S1000 Unit: inch/mm Top View 4.72"/120mm Side View Front View Side View 2.0"/50mm 70.87"/1800mm 7.87"/200mm Bottom View 10 - 0.63" x 1.22" (10-16mm x 31mm) 27.56"/700mm 6 - 3.15" x 1.18" 47.24"/1200mm (6-80mm x 30mm) 59.06"/1550mm...
- Page 5 Avalon-S1200 Unit: inch/mm Top View Front View Side View Side View 70.87"/1800mm 7.87"/200mm Bottom View 10 - 0.63" x 1.22" (10-16mm x 31mm) 6 - 3.15" x 1.18" (6-80mm x 30mm) 27.56"/700mm 47.24"/1200mm 59.06"/1550mm...
-
Page 6: System Composition
3 System Composition The Avalon-S1000 and Avalon-S1200 can be combined to form a single, dual or multi-lane system, and users can choose the appropriate combination according to actual needs. It should be noted that Avalon-S1200 needs to be used in conjunction with Avalon-S1000. Single-lane Unit: inch/mm 25.59"/650mm... - Page 7 4 Wiring Single-lane wiring Sub device 5-core connecting wire(M-S) AC110/220V input FACP (Fire alarm) Access controller cable Main device Dual-lane wiring Sub device Sub device Main device Main device Remarks: The multi-lane wiring method is similar.
-
Page 8: Installation Requirements
5 Installation Requirements 1. It is recommended that the turnstile must be installed on a horizontal solid platform with a height of 2.0" to 3.9"(50mm to 100mm). 2. It is recommended that the turnstile should not be used in the corrosive environment. 3. - Page 9 7 Installation Cabinet Step 1 Determine and Mark the Mounting Positions 1. Please refer to the user's manual and complete the power-on self test operation before installation. 2. The first step is to determine the location for the cabinet installation. Once this has been done, the marking template should be placed according to the installation distances shown in the following figure.
- Page 10 Step 2 Foundation and Pre-assembled Components 1. Dig a recess 2.0" (50mm) deep with the dimensions shown below. For laying out pre-assembled components. 2. Place the pre-assembled components into the recess and pour concrete to fix it in place. Pre-assembled components: 62.99"/1600mm 7.87"/200mm Fixed the pre-assembled components:...
- Page 11 Step 3 Wireway Laying 1. Dig a recess of 2.0" (50mm) depth between the wire holes on both sides of the channel with the dimensions shown below. Recesses can be dug at positions 1 and 2 . 2. Then lay two 0.8" to 1.0" (20 to 25mm) diameter PVC pipes as shown below. 3.
-
Page 12: Detailed Installation Instructions
8 Detailed Installation Instructions Step 1 Removal of Gantry Frames 1. Remove gantry frame Working in pairs or multiples, lift the gantry frame from each end and remove the gantry frame once it is raised. Take care to maintain balance at both ends. Note: After the frame is raised, unplug electrical connections such as indicator lights, speakers, etc. - Page 13 3. Removing the movement lower cover Loosen the screws of the lower movement cover and remove the cover. Step 2 Mounting Fixing 1. Place the chassis on the pre-mounted L-type ground screws in accordance with the fixing holes on the bottom of the chassis, and lay the communication cables and 220V power cables at the same time.
- Page 14 2. Installation of gantry frames Align the locating pins and concealed fasteners on the gantry frame, and with two people working together, insert the frame flush into the gate box body. Note: Connect the indicator lights, speakers and other electrical appliances. Gantry Frame Locating Pins Concealed...
-
Page 15: Wiring Diagram
9 Wiring Diagram... - Page 16 Copyright © 2025 ARMATURA LLC. All rights reserved.
