- Page 1 J-Master USE AND MAINTENANCE MANUAL (USER AND MAINTENANCE) DEVICE FOR REMOTE MANAGEMENT OF IONIZING MODULES...
- Page 2 These instructions are translated from Italian (the original language). JONIX S.p.A. reserves every right concerning this manual, including the right to make any necessary change or improvement to its products and to the manual at any time and without notice. It is forbidden to reproduce in full or in part...
- Page 3 J-Master Thank you purchasing the J-Master device. This manual contains the information and all that is required for the transportation, installation, use and maintenance of the device for remote management of ionizing modules J-Master Improper installation of the device and/or failure to comply with the instructions in this manual, may invalidate the warranty that the Manufacturer issues for its products.
-
Page 4: Table Of Contents
J-Master TABLE OF CONTENTS 1 - GENERAL INFORMATION 1.1 - SERIAL NUMBER PLATE 1.2 - LIABILITY 1.3 - SYMBOLS 2 - WARNINGS AND GENERAL PROHIBITIONS 3 - OPERATING SYSTEM J-Master 3.1 - INTRODUCTION 3.2 - SUPERVISION AND CONTROL SYSTEM 4 - TECHNICAL DATA 4.1 - COMPONENT DESCRIPTION 4.1.1 - Technical features 4.2 - SPARE PARTS AVAILABLE ON ORDER... -
Page 5: General Information
Failure to comply with the instructions contained in this Use and Maintenance Manual releases JONIX S.p.A. from any liability. For any data not included or not deducible from the following pages it is recommended to contact the manufacturer at the operational headquarters JONIX S.p.A. -
Page 6: Symbols
S.p.A. from the QR code on the device. Repairs and maintenance work must be carried out by JONIX authorised S.p.A. staff or by qualified staff according to the provisions set out by this manual. Do not alter or tamper with the device as it can lead to hazards and the manufacturer of the device shall not be liable for any damage caused. - Page 7 When installing, commissioning and operating this product, it is mandatory to observe the requirements and instructions specified in this manual. disclaims any liability for damage caused to people, animals or JONIX S.p.A. property due to installation, adjustment and maintenance errors or by improper use.
-
Page 8: Operating System J-Master 10
The software allows the devices to be controlled in both Stand Alone and Modbus mode in the same system. The change of control mode of the devices (from Stand Alone to Modbus and vice- versa) is always modifiable. However, the operation must be performed by the company Jonix spa or by an authorised installer. -
Page 9: Technical Data
J-Master 4 - TECHNICAL DATA FRONT VIEW REAR VIEW 4.1 COMPONENT DESCRIPTION 01 Opening/closing box screws 04 QR code label user and maintenance manual 02 Display box 05 RJ45 connection port 03 Display touch screen 4.3" 06 Terminal block for power supply and signal connection 4.1.1 Technical features Dimensions Connectable... -
Page 10: Reception, Transport And Storage
J-Master 5 - RECEPTION, TRANSPORT AND STORAGE 5.1 PACKAGING and its accessories are delivered in specific protective packaging and must remain J-Master intact until they are assembled. The materials that were not installed for technical requirements are supplied with suitable enclosure secured to the inside or outside of the device itself. The package includes: - N°... -
Page 11: Installation And Commissioning
J-Master 6 - INSTALLATION AND COMMISSIONING ATTENTION! Before carrying out any operation on the devices read ALL the instructions in this manual carefully. Definitions: USER: USER/OPERATOR: QUALIFIED STAFF: Person, organisation or Individual been Individuals who have completed a company who or which authorised by the user to specific course and are therefore purchased... -
Page 12: Getting Started
J-Master • Use the type of power supply shown on the label. If you are not sure about the type of power supply available, ask your local retailer or electricity provider for assistance. • Do not touch the inside of the device, unless specified otherwise in the instructions contained in this manual. -
Page 13: Installing The Device
J-Master 6.4 INSTALLING THE DEVICE The J-Master device is designed to be installed on the wall in civil (or similar) environments not subject to bad weather or the presence of water. The box is secured with special plugs (see the "attachments" chapter). The recommended installation height is 1500 mm from the floor;... -
Page 14: Electric Power Supply And Control Signals
1 to 10 devices equipped with board for remote control (JX11000042). J-Master In order to manage the devices, an RS485 serial line with Modbus protocol must be created that will connect the J-Master10 with all the devices present. 14 - 32... - Page 15 J-Master The connection must start from the display (Pin 6-7) and make in/out on all devices up to the last one which, unlike the others, will be programmed as a line terminator (it is recommended not to invert the polarities of the serial). The cable to be used must be 2-conductor + earth twisted and shielded (Belden recommended).
-
Page 16: User Interface
J-Master 7 - User Interface allows the user to view the status of connected devices. J-Master The user will be able to: - View devices; - View if devices are correctly connected to the Modbus RS485 serial port; - View whether the device is on or off; - View any reports (generator maintenance, generator replacement, fault);... - Page 17 J-Master The activated device display will look like the screenshot on the right: If one or more devices require periodic maintenance (cleaning of the generators) a Flashing yellow “LED” message, corresponding to each device, positioned in the top right of the corresponding icon and the central “maintenance required”...
- Page 18 J-Master Clicking on each device will access the page dedicated to the specific information of the selected device. This section will display: - the address of the peripheral device (from 1 to 10); - the command mode (Stand Alone: external contact; Modbus: from program to display); - The threshold limit of the operating hours during which the generators are scheduled to be cleaned (Maintenance) and replaced (Replacement);...
- Page 19 J-Master In the event of an anomaly or when one of the devices requires assistance, two yellow icons with an exclamation mark (!) will appear on the sides of the clock to signal the requirement for intervention of one or more devices. The display can be connected to a local LAN network.
-
Page 20: Maintenance Technician Interface
By pressing the icon on the right you access the QR code display screen for downloading the user/maintenance manual. By default the password is but it can be customised by the installer or by the company Jonix s.p.a. 20 - 32... - Page 21 J-Master Press the “Ent” key to confirm the keypad code. press the central grey icon with the gears to access the Mainte- nance Technician menu. Press the "Clock" key to access the date and time settings: 21 - 32...
- Page 22 J-Master After setting the time and date, to save press the save icon in the bottom left To return to the main menu press green icon in the bot- tom right Press the “IP” key to generate the static IP with which to remotely access the display.
- Page 23 J-Master By pressing the "Languages" key it will be possible to change the language in which the various operations on the display are de- scribed. The languages available are Ital- ian, German, French, Spanish and English. To change language simply press on the flag. To return to the main menu press the green icon in the bottom...
- Page 24 In the example, only devices 1 and 2 (enabled) can be controlled, while devices 3 to 10 are not enabled. Adding devices can only be performed by Jonix spa or by an authorised installer.
- Page 25 J-Master Following the intervention, the parameters will be restored. As can be seen in the screenshots, a red “LED” has been inserted to indicate which parameter to restore. Maintenance: Replacement: Once the reset is performed, the hour meter will be reset to zero. case Maintenance Reset,...
-
Page 26: Maintenance
J-Master 9 - MAINTENANCE does not require any type of extraordinary maintenance; it is recommended to J-Master periodically (at least once every 2 months) clean the surfaces of the container and the display with a damp microfibre cloth. Do not use liquid cleaners or sprays, soap or the like. 10 - OPERATIONAL CHECK AND TROUBLESHOOTING This section summarises the most common problems that may arise when using the unit. -
Page 27: Disposal
J-Master In the event that you experience a malfunction other than those described above contact qualified staff (retailer, Manufacturer). Disconnect the device from the power supply and contact qualified staff for assistance even in the event of one or several of the cases below: •... -
Page 28: Attachments
J-Master ATTACHMENTS OVERALL DIMENSIONS J-Master FIXING HOLES 28 - 32... - Page 29 J-Master NOTES ............................................................................................................................................................................................................................................................................................................................................................................................29 - 32...
- Page 30 J-Master ..........................................................................................................................................................................................................................................................................................................................................................................................................................30 - 32...
- Page 32 JONIX Benefit Corporation Registered Office: Operational Headquarters: Research and Development info@jonixair.com Viale Spagna 31/33 Via dell’Artigianato, 1 Headquarters: Certified mail: jonixsrl@legalmail.it 35020 Tribano (PD) - Italy 35020 San Pietro Viminario Via Tegulaia 10/b Ph. +39 049 9588511 (PD) – Italy...
