- Page 1 RTSS-X306 Product Manual Realtimes Beijing Technology Co., LTD. TEL：400-100-8358 Email: info@realtimes.cn Web Page: https://www.realtimesai.com Address:11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
-
Page 2: Revision History
Revision History Applicable Revision Date Reason for change Modified by hardware version V1.0 2023-06-25 Initial release V1.0 RT0086 RTSS-X306 Product Manual V1.0... -
Page 3: Table Of Contents
OARD LEVEL SUPPORT ACKAGE ................................17 ETPACK 3.1 Jetpack Component summary ........................17 3.2 How to install Jetpack ..........................17 3.3 Sample application .............................19 3.4 Developer tools ............................19 3.5 Documentation ............................20 TERMS OF WARRANTY ...........................21 COPYRIGHT NOTICE ............................22 RTSS-X306 Product Manual V1.0... - Page 4 Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including RTSS-X306). Anti-static safety protection measures include, but are not limited to the following: a) The smart box should be placed in an anti-static bag during transportation and storage, and then the board should not be taken out during installation and deployment.
- Page 5 5) Various peripheral module drivers released by the company; 6) The company's product fault diagnosis and after-sales maintenance services; 2. Scope of technical discussion Due to the wide range of embedded system knowledge and various types of involvement, we can not RTSS-X306 Product Manual V1.0...
- Page 6 Updates of subsequent documents, BSP, driver files and other official account will be updated in time. We will pay close attention to our developments in order to ensure that your information is up to date. We will push through WeChat public. RTSS-X306 Product Manual V1.0...
-
Page 7: Product Presentation
Product presentation 1 Product introduction RTSS-X306 Feiyun Smart Box is the UAV industry solution for Orin NX and Orin Nano core modules. It adopts the active cooling design of aluminum alloy shell, which can adapt to the more harsh working environment. - Page 8 1 x M.2 key M port, 128GB SSD as standard; (Built-in interface) 1 x FAN interface (built-in interface) Support RTC function (built-in RTC battery) 1 x Nano SIM(Built-in expansion interface) Heat-dissipatin Fan heat dissipation g method Dimensions 100mm*71mm*53mm RTSS-X306 Product Manual V1.0...
-
Page 9: Ordering Information
USB3.0, 2 x USB2.0,1 x Micro HDMI,1 x GbE,1 x M.2Key M,1 x M.2Key B,1 x Nano SIM,1 x UART,1 x DEBUG,1 x OSDK,1 x CAN,WIFI6 module,1 x FAN, 1 x RTC, -25℃~+50℃ ； 128GSSD,5G module,wiring package (including XT30 power conversion cable and RTSS-X306 Product Manual V1.0... - Page 10 CAN,WIFI6 module,1 x FAN, 1 x RTC, -25℃~+50℃ ； 128GSSD,5G module,wiring package (including XT30 power conversion cable and interface wiring),provides Realtimes RTS Linux4Tegra software support package, through 3C and CE certification Order online: Taobao Store : https://shop340963258.taobao.com Tmall Store : https://feiyunzhihe.tmall.com/ Jingdong Store : https://mall.jd.com/index-824786.html RTSS-X306 Product Manual V1.0...
-
Page 11: Product Specifications
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Product specifications 1 External interface function and location X306 FRONT X306 BACK RTSS-X306 Product Manual V1.0... - Page 12 Realtimes Beijing Technology Co.,LTD www.realtimesai.com X306(5G)FRONT X306(5G)BACK RTSS-X306 Product Manual V1.0...
-
Page 13: Connectors Description
GH 1.25mm_8P/ A1257WR-S-8P Type Pin define Signal Signal VBUS1 USB2.0_1N USB2.0_1P VBUS2 USB2.0_2N USB2.0_2P 2.5 OSDK interface Function OSDK Type TYPE C Pin define Signal Signal A4,A A1,A 9,B4, 12,B1 ,B12 UART_RX（3.3V） SYNC_PPS（3.3V） USB2.0_P USB_ID USB2.0_N VBUS RTSS-X306 Product Manual V1.0... -
Page 14: Can Interface
2.8 Network interface Function Gigabit network interface GH 1.25mm_8P/ A1257WR-S-8P Type Pin define Signal Signal MDI0_P MDI0_N MDI1_P MDI1_N MDI2_P MDI2_N MDI3_P MDI3_N 2.9 Power interface Function Power input interface Type XT30 Pin define Signal Signal RTSS-X306 Product Manual V1.0... -
Page 15: 5G Antenna
Input voltage range: DC +9~+36V Do not connect cables with power on! 2.10 5G antenna Function 5G antenna Type IPX(IPEX, UFL) to SMA-KY female head (outer screw inner hole) 0.81/ Black line/fourth generation Note: RTSS-X306(5G) version is available RTSS-X306 Product Manual V1.0... -
Page 16: Product Size Diagram
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Product size diagram 4 Hardware update history RTSS-X306 hardware update history Revision Updata description V1.0 Initial release RTSS-X306 Product Manual V1.0... -
Page 17: Software Version Supporting Instructions
Software version supporting instructions The RTSS-X306 is a complete machine form product with Jetson Orin NX/Orin Nano module as the core, providing one-stop terminal equipment for developers to help developers develop applications. RTSS-X306 Feiyun Smart Box supporting software includes: L4T (Linux for Tegra) : L4T provides the "OS"... -
Page 18: Jetpack
Realtimes Beijing Technology Co.,LTD www.realtimesai.com To support all RTSS-X306 smart box interfaces, you need to load the driver patch (BSP: board support package). Use flash mode for system burning. SDK Manager to install all other JetPack components except L4T to get your box up and running quickly. - Page 19 Use SDK Manager to select and install the required components NVIDIA SDK Manager supports installing software to Jetson core (Flying Cloud Smart Box). For complete instructions, please refer to Chapter 5 of "Orin NX System Programming Manual". RTSS-X306 Product Manual V1.0...
-
Page 20: Sample Application
API debugging through user interface and command line tools. •NSight Graphics for graphics application debugging and evaluation: a consolegrade tool for debugging and optimizing OpenGL and OpenGL ES programs. Run on the Linux host. Support all Jetson products. RTSS-X306 Product Manual V1.0... -
Page 21: Documentation
Documentation • CUDA Toolkit • NVIDIA Container Runtime • OpenCV Documentation • Jetson Linux Multimedia API Reference • Nsight Systems • nvprof • Visual Profiler • Nsight Graphics • Nsight Compute CLI • VPI–Vision Programming Interface RTSS-X306 Product Manual V1.0... -
Page 22: Terms Of Warranty
Other failures which are clearly due to misuse(such as overvoltage,polarity reversal, the pin bent or broken,the wrong connection,drop damage,transportation damage,damage due to over operating temperature and so on). e) The logo and part number on the product have been deleted or removed. The product is out of warranty. RTSS-X306 Product Manual V1.0... -
Page 23: Copyright Notice
Without the written permission of the company, no unit or individual may copy, extract, backup, modify, disseminate, translate into other languages, or use all or part of it for commercial purposes in any way or form. RTSS-X306 Product Manual V1.0...
