- Page 1 X509 Product Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 Email: info@realtimes.cn Web Page: https://www.realtimesai.com Address: 11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 Revision History Applicable Revision Date Reason for change Modified by hardware version V1.0 2022-05-05 Initial release V2.0 RT0086 X509 Reference Manual V1.0...
-
Page 3: Table Of Contents
EGRA BBREVIATION ................................16 ETPACK 3.1 Jetpack Component summary ........................16 3.2 How to install Jetpack ...........................16 3.3 Sample application .............................18 3.4 Developer tools ............................18 3.5 Documentation ............................19 TERMS OF WARRANTY ...........................20 COPYRIGHT NOTICE ............................21 X509 Reference Manual V1.0... - Page 4 Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including X509). Anti-static safety protection measures include, but are not limited to the following: a) The smart box should be placed in an anti-static bag during transportation and storage, and then the board should not be taken out during installation and deployment.
- Page 5 2. Scope of technical discussion Due to the wide range of embedded system knowledge and various types of involvement, we can not guarantee that all kinds of questions can be answered one by one. The following content is not X509 Reference Manual V1.0...
- Page 6 Updates of subsequent documents, BSP, driver files and other official account will be updated in time. We will pay close attention to our developments in order to ensure that your information is up to date. We will push through WeChat public. X509 Reference Manual V1.0...
-
Page 7: Product Presentation
Product presentation 1 Introduction X509 is a new Feiyun Smart Box™ designed based on NVIDIA Jetson Xavier NX/TX2 NX modules. By default, it has a built-in Xavier NX module integrating 384-core Volta™ architecture GPU, pre-installed Ubuntu operating system, and has 21TOPS floating-point operation. AI processing power. It is designed with super strong and light aluminum alloy material, conducts heat, and has excellent heat dissipation capacity. -
Page 8: Features
1 x Micro 1 x 128GB 1 x Micro 1 x 128GB 1 x Micro 1 x 128GB SD/eMMC eMMC eMMC eMMC Button 1 x FORCE RECOVERY，1 x SYS_RST Size 148.39mm×111.26mm×66.24mm Power +12V Temperature -25℃—+55℃ -25℃—+60℃ X509 Reference Manual V1.0... -
Page 9: Ordering Information
NX module, pre-installed Ubuntu 18.04, built-in 16GB eMMC; 1 x RTSS-X509-TX2 NX V2.0 USB3.0, 1 x USB2.0, 1 x Micro USB OTG,1 x Mini-HDMI, 1 x GbE , 1 x Micro SD,1 x Debug UART, 2 x RS232, 2 x I2C, 1 x SPI, X509 Reference Manual V1.0... -
Page 10: Wiring Pack Configuration
All network 4G module Order online: https://shop340963258.taobao.com https://mall.jd.com/index-824786.html 1.3 Wiring Pack Configuration Function description Components Quantity HDMI cable Convert Mini HDMI to Standard HDMI System flash cable Micro USB to USB TYPE-A male system flash cable X509 Reference Manual V1.0... -
Page 11: Product Specifications
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Product specifications 1 External interface function and location X509 FRONT AND SIDE X509 BACK X509 Reference Manual V1.0... -
Page 12: Connectors Description
The upper-layer USB and Mini-PCIe share one USB2.0, and the lower-layer USB interface is USB3.0 2.4 Micro SD card slot Function Micro SD card slot Marking Micro SD Type Micro SD（TF） 2.5 Micro SIM card slot Function Micro SIM card slot Marking Type Micro SIM X509 Reference Manual V1.0... -
Page 13: Antenna Interface
2.9 Multifunction Connector Function Multifunction Pin Header Marking Multifuntion-port Type DB25 Pin define Signal Signal 3.3V 3.3V CAN0_H SPI_SCK CAN0_L SPI_MISO CAN1_H SPI_MOSI CAN1_L SPI_CS0 RS232_3_TXD GEN1_I2C_SCL RS232_3_RXD GEN1_I2C_SDA RS232_2_TXD GEN2_I2C_SCL RS232_2_RXD GEN2_I2C_SDA UART2_RTS UART3_RTS UART1_TXD_DBG BUTTON_PWR_ON UART1_RXD_DBG X509 Reference Manual V1.0... -
Page 14: Recovery Button
Function RESET Button Marking RESET Type Reboot the system 2.12 LED Indicator Light Function LED indicator light Marking POWER、HDD Type POWER: The POWER light is on when the power is turned on HDD: Hard drive indicator X509 Reference Manual V1.0... -
Page 15: Product Size Diagram
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Product size diagram 4 Hardware update history X509 hardware update history Version Update Description V1.0 Initial release V2.0 Change the board X509 Reference Manual V1.0... -
Page 16: 软件版本配套说明
The steps to enter Recovery mode are as follows: a) Turn off the system power supply. b) Use a USB cable to connect the Micro USB (OTG) port of the X509 with the Host (PC) development host USB port. c) Press and hold the Recovery button to supply power to the system for more than 3 seconds, and then release the Recovery button. -
Page 17: Jetpack
You must have a Linux host with internet access to run SDK Manager and refresh the developer kit. The supported host operating systems are: Ubuntu Linux x64 Version 18.04 or 16.04 Download and install NVIDIA SDK Manager. X509 Reference Manual V1.0... - Page 18 Use SDK Manager to select and install the required components NVIDIA SDK Manager supports installing software to Jetson core (Flying Cloud Smart Box). For complete instructions, please refer to Chapter 5 of "Xavier NX System Programming Manual". X509 Reference Manual V1.0...
-
Page 19: Sample Application
API debugging through user interface and command line tools. •NSight Graphics for graphics application debugging and evaluation: a consolegrade tool for debugging and optimizing OpenGL and OpenGL ES programs. Run on the Linux host. Support all Jetson products. X509 Reference Manual V1.0... -
Page 20: Documentation
Documentation • CUDA Toolkit • NVIDIA Container Runtime • OpenCV Documentation • Jetson Linux Multimedia API Reference • Nsight Systems • nvprof • Visual Profiler • Nsight Graphics • Nsight Compute CLI • VPI–Vision Programming Interface X509 Reference Manual V1.0... -
Page 21: Terms Of Warranty
Other failures which are clearly due to misuse(such as overvoltage,polarity reversal, the pin bent or broken,the wrong connection,drop damage,transportation damage,damage due to over operating temperature and so on). e) The logo and part number on the product have been deleted or removed. The product is out of warranty. Special concerns X509 Reference Manual V1.0... -
Page 22: Copyright Notice
Without the written permission of the company, no unit or individual may copy, extract, backup, modify, disseminate, translate into other languages, or use all or part of it for commercial purposes in any way or form. X509 Reference Manual V1.0...
