Owner's Manual
(OLED Monitor)
Please read this manual carefully before operating your set and retain it for future reference.
45GX950A
www.lg.com
Copyright
2025 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraGear 45GX950A and is the answer not in the manual?

Questions and answers

Related Manuals for LG UltraGear 45GX950A

Summary of Contents for LG UltraGear 45GX950A

  • Page 1 Owner's Manual (OLED Monitor) Please read this manual carefully before operating your set and retain it for future reference. 45GX950A www.lg.com Copyright 2025 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS ASSEMBLING AND PREPARING ............4 USING THE MONITOR ................ 12 - Installing ..........................5 - Connecting to a PC ......................12 Moving and Lifting the Monitor ..................5 HDMI Connection ......................12 Installing on a Table ......................6 DisplayPort Connection ....................13 Using the Kensington Lock ....................6 USB-C connection ......................13 - Connecting AV Devices .....................13 Installing on the Wall ......................7...
  • Page 3 PRODUCT SPECIFICATION ..............21 - Support Mode ........................22 (Preset Mode, HDMI) ......................22 (Preset Mode, DisplayPort/USB-C) ...................24 HDMI Timing (Video) ......................26 TROUBLESHOOTING ................27 LICENSE .................... 28 OPEN SOURCE SOFTWARE NOTICE INFORMATION ......28...

  • Page 4: Assembling And Preparing

    • To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer • Always use genuine LG components to ensure safety and product performance. from which you purchased the product. • The product warranty will not cover damage or injury caused by the use of unauthorised components.

  • Page 5: Installing

    Installing CAUTION • Avoid touching the monitor screen as much as possible. Moving and Lifting the Monitor - This may result in damage to the screen or some of the pixels used to create images. • If you use the monitor panel without the stand base, its button may cause the monitor to become unstable When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or and fall, resulting in damage to the monitor or human injury.

  • Page 6: Installing On A Table

    Installing on a Table Using the Kensington Lock • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website the wall to ensure sufficient ventilation.

  • Page 7: Installing On The Wall

    Installing on the Wall Installing the Wall Mount Plate To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
  • Page 8 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could • The wall mounting bracket is optional. You can obtain optional accessories from your local dealer. lead to injury. Use an authorised LG wall mount and contact the local dealer or qualified personnel. • •...

  • Page 9: Product And Button Description

    Product and Button Description : Wall Mount Plate : Back of the Monitor : Standard screw : Max. 8 mm : Joystick Button : [Dual-Mode] Button...

  • Page 10: How To Use The Joystick Button

    How to Use the Joystick Button Adjusting the Stand Height You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ Place the monitor mounted on the stand base in an upright position. down with your finger.

  • Page 11: Adjusting The Angle

    Supported Drivers and Software Adjusting the Angle Place the monitor mounted on the stand base in an upright position. You can download and install the latest version from the LGE website (www.lg.com). Adjust the angle of the screen. - Monitor Driver / The angle of the screen can be adjusted forward or backward from -10°...

  • Page 12: Using The Monitor

    CAUTION HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion.

  • Page 13: Displayport Connection

    Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •...

  • Page 14: Connecting Peripherals

    Connecting Peripherals Headset Connection Connect peripherals to the monitor via the headset port. USB Device connection NOTE The USB port on the product functions as a USB hub. • Peripheral devices are sold separately. Peripheral devices connected to the USB IN port can be controlled from the PC. •...

  • Page 15: User Settings

    USER SETTINGS Main Menu Features NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu Press the joystick button on the back of the monitor. Move the joystick up/down and left/right to set the options. Joystick Button Main Menu Description...

  • Page 16: Menu Settings

    Move the joystick up/down and left/right to set the options. - [Personalized Picture]: Set up a customised picture mode tailored to your preferences. Please install the LG To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
  • Page 17 • [Adaptive-Sync]/[VRR]: This function shows a clear screen without screen tearing or stuttering in the game NOTE environment. • The [Game Mode] can be set depends on the Input signal. However, screen flickering may occur in some game environments. • - Supported Interface: DisplayPort/USB-C (Adaptive-Sync), HDMI (VRR).

  • Page 18: [Picture Adjust]

    [Picture Adjust] • [Six Color]: Meets the user requirements for colors by adjusting the hue and saturation of the six colors (red, green, blue, cyan, magenta, and yellow) and then saving the settings. [Settings] > [Picture Adjust] - Hue: Adjusts the tone of the screen colors. •...

  • Page 19: [Input]

    [Input] [General] [Settings] > [Input] [Settings] > [General] • [Input List]: Selects the input mode. • [Language]: Sets the menu screen to the desired language. • [OLED Screen Move]: Moving the screen minutely at regular intervals helps to prevent panel noise caused by Sub Screen images that have been fixed for a long time.

  • Page 20: Important Information For Preventing Image Retention

    Important Information for Preventing Image Retention • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. - [High]: Saves energy using the high-efficiency [SMART ENERGY SAVING] feature. Unlike regular LED/LCD monitors, pixels in the OLED monitors emit light on their own, achieving a perfect black - [Low]: Saves energy using the low-efficiency [SMART ENERGY SAVING] feature.

  • Page 21: Product Specification

    PRODUCT SPECIFICATION Dimensions: Monitor Size (Width x Height x Depth) • With Stand (mm): 991.6 x 665.6 x 342 • Without Stand (mm): 991.6 x 460.7 x 225.5 Specifications are subject to change without notice. The symbol ~ means alternating current, and the symbol means direct current.

  • Page 22: Support Mode

    Support Mode (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000...
  • Page 23 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks Recommended ([Dual-Mode]: [On(16:9 37")], [On(16:9 27")] 1920 x 1080 420.567 330.116 or [On(16:9 24")]) Recommended ([Dual-Mode]: [On(Full Wide)], [On(21:9 39")] 2560 x 1080 420.566 330.115 or [On(21:9 34")]) 5120 x 2160 226.580 100.035 3840 x 2160...

  • Page 24: (Preset Mode, Displayport/Usb-C)

    (Preset Mode, DisplayPort/USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 720 x 480...
  • Page 25 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks Recommended ([Dual-Mode]: [On(Full Wide)], [On(21:9 39")] 2560 x 1080 420.566 330.115 or [On(21:9 34")]) 5120 x 2160 226.580 100.035 3840 x 2160 385.905 165.058 Recommended ([Dual-Mode]: [Off(16:9 37")] Recommended ([Input Compatibility Version]: [1.4] / [2.1]) 5120 x 2160 385.905 165.058...

  • Page 26: Hdmi Timing (Video)

    HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 720P 45.0 1080P 67.5 1080P 135.0 2160P 135.0 2160P 255.0...

  • Page 27: Troubleshooting

    Do you see an "Unrecognised monitor, Plug and Play (VESA DDC) monitor found" message? • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports Plug and Play function.

  • Page 28: License

    HDMI Licensing LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Administrator, Inc. such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.
  • Page 29 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
