Applicable Asset Models
✓ Beacon Medaes CFAM-PX Series Manifold
Package Contents
✓ Element-B
Safety Information
Review and abide by the safety information found in the Element-B and Beacon Medaes CFAM-PX
Series Manifold user manuals. Ensure compliance with your company safety best practices, which
may include de-energizing equipment before working with electrical connections. Tidy connection
cable to prevent tripping hazards.
Installation Instructions
Receiving the Shipment
1. If this is your first time setting up the Elemental Machines system, you will receive an email for your dashboard
account verification. Save this email for when the devices arrive.
2. When devices are shipped, they will be added to your Elemental Insights™ Dashboard with default names.
When you first log in you will see all your devices with a 'disconnected' status.
3. When devices arrive, carefully remove the contents from the packaging. If any of the contents look damaged,
please send a picture to help@elementalmachines.com.
4. If you have ordered multiple Element-B's, ensure the Element-B being used is configured as Normally Closed
(NC). This can be verified by checking the device label, the dashboard under 'Machine Model', or the packing
list sent with your shipment.
a. Element-B's can either be configured as Normally Closed (NC) or Normally Open (NO) by our team here at
Elemental Machines. Different assets require different configurations. If you have ordered Element-B's for
multiple assets, you may have a mix and need to be aware of attaching the correctly configured device to
the correct asset.
5. Ensure there is an Elemental Machines Gateway set up in the vicinity of the Element-B. Your Gateway type may
vary. Please follow the setup instructions in your gateway user manual.
a. Note: 'Vicinity' is within wireless connection range. This is usually up to 30 meters but can depend on the lab's
layout.
LIT-00506 rev 01 Element-B, EB1 EB2 Beacon Medaes CFAM-PX
Series Manifold Installation Guide
Element-B Installation Guide
For Beacon Medaes CFAM-PX Series Manifold
✓ Connection Cable
1/4
Models: EB1, EB2
Copyright © 2025 Elemental Machines
help@elementalmachines.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Elemental Machines Element-B
Summary of Contents for Elemental Machines Element-B
- Page 1 Installation Instructions Receiving the Shipment 1. If this is your first time setting up the Elemental Machines system, you will receive an email for your dashboard account verification. Save this email for when the devices arrive. 2. When devices are shipped, they will be added to your Elemental Insights™ Dashboard with default names.
- Page 2 Remove these connectors from the slots. Do not remove the spade connectors that have wires attached to them. Figure 2 Remove the circled spade connectors already installed on the manifold LIT-00506 rev 01 Element-B, EB1 EB2 Beacon Medaes CFAM-PX Copyright © 2025 Elemental Machines Series Manifold Installation Guide...
- Page 3 Models: EB1, EB2 For Beacon Medaes CFAM-PX Series Manifold 9. Route the ends of the Element-B Connection Cable, shown in Figure 3a, through the cable gland at the bottom of the manifold, as circled in Figure 3b. Figure 3a (left) Ends of the Element-B Connection Cable Figure 3b (right) Location of the cable gland at the bottom of the manifold 10.
- Page 4 15. Refer to the asset user manual for which alarm conditions can be detected. 16. Set up alert rules on the Elemental Insights™ Dashboard for the Element-B. Guidance on how to do so is available in the Support section of the dashboard.
