Ion+
Connect
®
Digital Level Control Switch and Alarm
with Internal Cellular Module
Introduction
The Ion+ Connect is a residential sump/sewage
ejector pump controller equipped with the Ion
sensor and integrated cellular texting module. The
device will run a manual pump up to 12 FLA, can
sense up to 72" of water, has customizable start/stop/
alarm levels, and provides alarm notifications via
SMS text for alarms like high water, pump fail, power
fail, and many more.
Model # INPC20428 - Cord length 10 (ft)
Model # INPC20430 - Cord length 20 (ft)
What's in the Box
1
Connec
W W W . I O N P R O D U C T S . N E T
POWER PUMP ALARM
CELL
INPUT:
120VAC 60HZ 15A
OUTPUT:
120VAC 60HZ 12FLA 72LRA
PUMP
TEST
SILENCE/
PATENTS PENDING
RESET
PATENT NO. 8,591,198
LOCK/
UNLOCK
REMOTE
DIGITAL
REMOTE
ALARM
LEVEL
ALARM
INPUT
SENSOR
CONTACT
The Ion+ Connect comes with:
1. Ion+ Connect
Pump Controller equipped with 10' 115 VAC
15A cord.
2. Ion Sensor with pipe clamp
Connects to Ion+ Connect to provide level
signal.
www.ionproducts.net
level
®
3
2
OPERATION MANUAL
Dated: 02/10/2020
Document Name: Ion+Connect_OM
3. Antenna Extender
For mounting the antenna outside of the
basement for better cellular signal
Features
The following illustration describes the physical
features of your Ion+ Connect.
1
2
1. Power LED
Indicates the power status of unit.
Refer to the LED section for details.
2. Pump LED
Indicates the pump status.
Refer to the LED section for details.
3. Alarm LED
Indicates alarm status.
Refer to the LED section for details.
4. Cell LED
Indicates cellular connectivity status.
Refer to the LED section for details.
5. Pump Test
Hold down button for 5 seconds to manually
run pump.
6. Silence / Reset
Momentarily push for Alarm Silence.
Hold to reset unit.
7. Lock / Unlock
Press for approximately 3 seconds to
unlock unit to accept SMS text configuration
commands. Press again after unlock to lock
unit from accepting SMS text configuration
commands.
Page 1 of 12
3
4
5
6
7
8
9
10
Advertisement
Table of Contents
Related Manuals for Metropolitan Industries Ion+ Connect
Summary of Contents for Metropolitan Industries Ion+ Connect
- Page 1 Features The following illustration describes the physical features of your Ion+ Connect. Introduction The Ion+ Connect is a residential sump/sewage ejector pump controller equipped with the Ion level ® sensor and integrated cellular texting module. The device will run a manual pump up to 12 FLA, can sense up to 72”...
-
Page 2: Installation
(over 110° F or under 45° F) the temperature sensor will alarm. If your Ion+ Connect alarms when it is plugged in, please see Troubleshooting, Page 6. b. Determine pipe bracket mounting orientation for the Ion sensor (See Figure B, Page 3). -
Page 3: Antenna Extender
Attach one end of the cable to the Ion+ Connect, and attach the Ion+ Connect's antenna to the other end of the cable as shown here. - Page 4 Summary section, Page 7-9 for the full list of 1. Power On, Set Up, Test settings and commands available). You can now plug the Ion+ Connect into a dedicated AC a. Press and hold the “Unlock/Lock” button for outlet 115V, 15 Amp circuit.
- Page 5 5. Configure the Name of Your Ion+ Connect notification to those on the list. You can also test the pump by texting “pump test” to the Ion+ You can give your Ion+ Connect a name that it uses Connect. in the notification messages it sends.
-
Page 6: Troubleshooting
Ion+ Connect. 1. Test the pump without the Ion+ Connect 2. Plug the pump back into the Ion+ Connect and plug the Ion sensor back into the Ion+ Connect. a. Plug the pump directly into the wall outlet, without plugging it into the Ion+ Connect. - Page 7 Commands Summary These are the commands accepted by the Ion+ Connect. Note: The commands under the Admin Settings section will only be accepted if the unit is first unlocked by holding the UNLOCK button on the faceplate until it beeps twice.
- Page 8 Basic Setup Commands Command Example Description name [Name Of Unit] name Smith Residence Sets description of unit location/name of Ion+ Connect ph1 [Phone Number] ph1 7778889999 Sets first phone number to notify ph1 clear Removes phone number from Notification List...
- Page 9 Ion+ Connect OPERATION MANUAL ® Dated: 02/10/2020 Digital Level Control Switch and Alarm Document Name: Ion+Connect_OM with Internal Cellular Module Page 9 of 12 alarm level low alarm level low 0 Sets the value in inches for low level alarm threshold [# of inches] alarm temp low alarm temp low 45...
- Page 10 Ion+ Connect OPERATION MANUAL ® Dated: 02/10/2020 Digital Level Control Switch and Alarm Document Name: Ion+Connect_OM with Internal Cellular Module Page 10 of 12 alert en batt Enable / Disable battery alerts alert en power Enable / Disable power alerts alert en unlock Enable / Disable unlock alert alert en input...
-
Page 11: Optional External Connections
Command Summary). Information to User Changes or modifications not expressly approved by Metropolitan Industries will void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 12 Page 12 of 12 1 Year Residential Warranty Coverage and Term. Metropolitan Industries, Inc. (“Metropolitan”) warrants to the original purchaser (the “Buyer”) of each Ion Technologies product (the “product”), that any part thereof which proves to be defective in material or workmanship within one (1) year from date of manufacture, will be replaced at no charge with a new or remanufactured part, F.O.B.
