Summary of Contents for Baby Lock BLE1 AT-2
- Page 1 SERVICE MANUAL MODEL BLE1 AT-2 Serial Numbers Canada Au. N.Z U.S.A. 700051 700001 D9 159500 I9 309547 From Vol. 2.0...
- Page 2 1.Construction of Covers New Adjusting Gauge Distance of chain looper tip from center of chain looper shaft (BLE5-2, BLE8-2, BLE8W-2) 72.8 Distance of lower looper tip from center of lower looper shaft 55.7 Distance of lower looper tip from right side of right needle (BLE5-2, BLE8-2, BLE8W-2) Distance of lower looper tip Distance of Upper looper tip...
- Page 4 Before adjustment of Thread delivery System(ATD) In case you can not get the proper stitches, please check the following items before you adjust the Thread Delivery System. a) Is thread positioned between discs? Double check the thread position. b) Does spring in the head thread guide catch thread properly? BLE1AT-2's head thread guide is exclusive for BLE1AT-2, You can not use other head thread guides for LX,DX,SX on BLE1AT-2.
- Page 5 0.9mm 0.4mm Rear clearance adjustment Front clearance adjustment Shut Open position position Shut Open position position...
- Page 6 3-3 HOW TO REPLACE THE TIMING BELT OF THREAD DELIVER Y UNIT (see P6) a) Loosen the presser foot joint link fixing screw A( 24 upper screw). b) Loosen the thread delivery unit fixing screw c) Remove 2 pcs of the thread delivery unit fixing screw d) Push the thread delivery unit downward and remove the timing belt of thread delivery unit Then, remove the motor belt and you can replace the timing belt of thread delivery unit.
- Page 8 3-6 REPLACEMENT OF SENSOR CABLE (see P.8) Needle thread and looper thread sensor cable consists of 1 13 pcs of fine stainless wire and its pulling strength is 13kg (3 lb.). Therefore, it is almost unnecessary to replace the sensor cable. In case you replace the cable, refer the followings; There are 3 types of sensor cable and each cable is different length.
- Page 10 4. ADJUSTMENT OF STITCHES fabric : cotton 1-layer thread : 100% polyester spun thread (maxi-lock or metrosene thread) needle : ORGAN HAX1SP #11/CR machine: 1-needle (right), 3-thread sewing width : 5.0mm (max) length : 3.0mm D.F. : N stitch selector : B 4-1 ADJUSTMENT OF NEEDLE THREAD SENSOR CABLE The needle thread sensor cable effects the timing of both needle thread and looper threads.
- Page 11 Turn Clockwise Become Loose Turn Counter-clockwise Become Tight Needle thread sensor cable Looper thread sensor cable Needle thread sensor cable adjusting screw Looper thread sensor cable adjusting screw Fine Tuning screw Standard Position...
-
Page 12: Adjustment Of Needle Threader
5. ADJUSTMENT OF NEEDLE THREADER (see P12) Before you adjust the needle threader, you are required to exchange the new needles of ORGAN HAX1SP #11CR as the bent needles or different needles cause the incorrect timing of needle threader. Also, you are required to make sure that needles are positioned in the needle clamp holder correctly. - Page 14 6. Checking threading steel pipe joint (see p .14) a) Set the machine for looper threading. b) Move the lock button release lever slightly to the right. c) Check the connecting point whether the looper threading pipe joint and threading steel pipe is fitted each other properly .
-
Page 16: Troubleshooting
8. TROUBLE SHOOTING 8-1 NEEDLE THREADS ARE UNBALANCED ; * Is the serger threaded correctly? See Quick Reference Guide * Are the threads snapped in the head guide? See Instruction Book P.12 * Is the stitch selector positioned correctly? See Quick Reference Guide * Is the looper thread fine-tuning screw positioned correctly? See Instruction Book P.13 * Are the threads recommended high quality?
