Induction Hob
User manual
NZ63C4035** / NZ63C4036**

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NZ63C4035 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NZ63C4035 Series

Summary of Contents for Samsung NZ63C4035 Series

  • Page 1 Induction Hob User manual NZ63C4035** / NZ63C4036**...

  • Page 2: Table Of Contents

    Contents Contents Operation Using this manual Switching the appliance on The following symbols are used in this User Manual: Switching the appliance off Model name & serial number Selecting cooking zone and power level Safety instructions Max Boost Keep Warm Disposing of the packaging material Timer Proper disposal of your old appliance...

  • Page 3: Using This Manual

    Using this manual Safety instructions Please take the time to read this owner’s manual, paying particular attention to the The safety aspects of this appliance comply with all accepted technical and safety safety information contained in the following section, before using your appliance. standards.
  • Page 4 Safety instructions This Appliance should be allowed to disconnection from the The appliance is not intended to be operated by means of an supply after installation. The disconnection may be achieved by external timer or separate remote-control system. having the plug accessible or by incorporating a switch in the CAUTION: The cooking process has to be supervised.
  • Page 5 The surfaces are liable to get hot during use. CAUTION This appliance can be used by children aged from 8 years and Be sure the appliance is properly installed and grounded by a above and persons with reduced physical, sensory or mental qualified technician.
  • Page 6 Safety instructions Do not use the hob to heat aluminium foil, products wrapped Always keep the control panels clean and dry. in aluminium foil or frozen foods packaged in aluminium Never place combustible items on the hob, it may cause fire. cookware.

  • Page 7: Disposing Of The Packaging Material

    This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, visit our sustainability page available via www.samsung.com English 7...

  • Page 8: Installing The Hob

    Installing the hob Installing the hob Tools you will need WARNING Be sure the new appliance is installed and grounded only by qualified personnel. Please observe this instruction. The warranty will not cover any damage that may occur as a result of improper installation. Technical data is provided at the end of this manual.

  • Page 9: Installing Into The Countertop

    Installing into the countertop WARNING Pay attention (conformity) to phase and neutral allocation of house connection and NOTE appliance (connection schemes); otherwise, components can be damaged. Warranty does not cover damage resulting from improper installation. Make a note of the serial number on the appliance rating label prior to installation.
  • Page 10 Installing the hob Normal Installation Type Unit : mm Unit : mm min. min. 500 mm 500 mm min. min. 50 mm 50 mm ±1 ±1 ±1 ±1 max. R25 max. R25 min. 55 min. 55 min. 50 min. 50 Drawer Oven Flushed Fit Type (Only NZ6******FK model can be installed)

  • Page 11: Components

    Before you start Cooking zones NZ63C4035** Components Induction hob Bracket Spring English 11...

  • Page 12: Control Panel

    Before you start Control panel NZ63C4036** Control panel 1 - NZ63C4035** 02 03 04 Control panel 2 - NZ63C4036** 02 03 04 On/Off To activate and deactivate the hob. Timer To turn timer on or off and set timer. Keep warm To keep cooked food warm.

  • Page 13: Induction Heating

    Induction heating Safety shutoff If one of the cooking zones is not switched off or the power level is not adjusted • The Principle of Induction Heating: after an extended period of time, that particular cooking zone will automatically When you place your cookware on a switch itself off.

  • Page 14: Residual Heat Indicator

    Before you start Residual heat indicator Cookware When an individual cooking zone or the hob is turned off, the presence of residual Use flat-bottomed cookware that completely heat is shown with an (for “hot”) in the corresponding cooking zone display. contacts the entire cooking zone.
  • Page 15 Cookware for induction cooking zones Other induction cookware The Induction burner can only be turned on when cookware with a magnetic base Some cookware has thin magnetic material on the bottom to work with an is placed on one of the cooking zones. You can use the cookware identified as induction heating hob.
  • Page 16 Before you start Suitability test Correct positioning Cookware is suitable for induction cooking Correct Incorrect if a magnet sticks to the bottom of the cookware and the cookware is labelled as suitable by the cookware manufacturer. Flat-bottomed cookware and straight Cookware with curved or warped sides bottoms or sides...

  • Page 17: Using The Touch Buttons

    Energy saving tips Using the touch buttons To operate the touch buttons, touch the desired button with the tip of your pointed Follow these tips to save power finger until the relevant displays illuminate or go out, or until the desired function consumption.

  • Page 18: Operation

    Operation Switching the appliance on Suggested settings for cooking specific foods The numbers in the table below are guidelines. The power level required for The appliance is switched on using the On/Off key. Press the On/Off key for various cooking methods depend on a number of variables, including the quality approximately 1-2 seconds.

  • Page 19: Max Boost

    Max Boost Timer The Max Boost function makes additional power available to the each cooking Using the timer as a safety shutoff zones. (example : bring a large volume of water to the boil) After Max Boost times, the cooking zones automatically sets back to the highest If a specific time is set for a cooking zone, the cooking zone will shut itself off once heat setting.

  • Page 20: Pause/Resume

    Operation Pause/Resume Child safety lock The Pause/Resume function simultaneously switches all cooking zones that are You can use the child safety lock to safeguard against unintentionally turning on a switched on to the low power setting and then back to the power level that was cooking zone and activating the cooking surface.

  • Page 21: Maximum Power Limit

    How to connect the hob You can adjust the power limit using the Pause & Lock key. (3000 W, Before you can use the remote features of your Samsung hob, you must pair it to 4000 W, 7400 W) the SmartThings app.

  • Page 22: Hood Control

    This product features a Bluetooth device that you can use to connect the hob to WARNING Samsung hood control models. Through the Bluetooth connection, you can use the Cleaning agents must not come into contact with a heated ceramic glass surface: hood control function on the SmartThings app.

  • Page 23: Stubborn Soiling

    Stubborn soiling Hob frame (option) To remove food that has boiled over WARNING and stubborn splashes, use a glass Do not use vinegar, lemon juice or scale remover on the hob frame; otherwise dull scraper. blemishes will appear. Place the glass scraper at an angle to Wipe the frame with a damp cloth.

  • Page 24: Troubleshooting And Service

    Troubleshooting and service Troubleshooting and service Troubleshooting Information code Possible cause Solution A fault may result from a minor information that you can correct yourself with There is a problem with the Restart the appliance the help of the following instructions. Do not attempt any further repairs if the burner temperature sensor.

  • Page 25: Service

    What should I do if the cooking zone will not switch on or off? Service This could be because of one of the following possibilities: Before calling for assistance or service, please check the section “Troubleshooting”. • The control panel is partially covered by a damp cloth or liquid. If you still need help, follow the instructions below.
  • Page 26 8009 4000 only from landline, toll free SWEDEN 0771-400 300 www.samsung.com/se/support 80111-SAMSUNG (80111 726 7864) www.samsung.com/gr/support from mobile and land line AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support GREECE (+30) 210 6897691 from mobile and www.samsung.com/ch/support (German) SWITZERLAND 0800 726 786 land line www.samsung.com/ch_fr/support (French)
