- Page 1 Wall Mounted Energy Storage Battery Installation and Operation Manual +86-21-54326236 +86-21-54326136 info@aforenergy.com Building 7, No.333 Wanfang Rd, Minhang District, Shanghai, China. 201112...
- Page 2 AF5000W-LF Operation Manual CONTENTS 1 Technical Data 2 Product Overview Brief Introduction Interface Introduction 2.2.1 Switch ON/OFF 2.2.2 LED Indicator Definition 2.2.3 CAN / RS485 Port 2.2.4 RS232 Port 3 Installation Guide Checking Before Installation 3.1.1 Checking Outer Packing Materials 3.1.2...
- Page 4 1. Switch ON AF5000W-LF has built-in BMS (Battery Management System), which can Turn on a single AF5000W-LF, turn on the air switch, then press the circular weak manage and monitor cells information including voltage, current and temperature. current switch (more than 3 seconds) on / off button, the LED flashes and the battery Besides that, BMS can balance cells charging to extend cycle life.
- Page 5 When all slave pack are closed, the master pack will be closed (sleep mode). For a single AF5000W-LF, turn off the Circular weak current switch. For multiple AF5000W-LF in parallel, turn off the Circular weak current switch on the main battery first.
- Page 6 Quantit Quantit Battery box Wall mounting bracket Ground screw Hanging bracket Bottom support bracket Desiccant User manual Outgoing Inspection Report Connet cable...
- Page 7 3.2 Tools 3.4 Installation Instructions 3.4.1 Dimensions Model Tools Knife Measuring tape Socket wrench 10/16mm Installation Rubber mallet Cross Screwdriver Hammer drill 10mm ESD gloves Safety goggles Anti-dust respirator Protection Safety shoes 141.5 Minimum mounting distance between battery pack and equipment: 3.3 Installation requirements 150mm 150mm...
-
Page 8: Installation Procedure
STEP 3 3.4.2 Installation Procedure Hang AF5000W-LF on the wall bracket and tighten it STEP 1 Drill the hole with an 10mm drill bit as follows and fix the wall bracket to the wall. Fastening Screw STEP 2 STEP 4 Install the hanging bracket. - Page 9 STEP 5 1. Load power exceeding 5kW requires at least 2 units Parallel operation. Connect power cable. 2. The maximum number of Number of parallel machines is 15. The power of the inverter selected for the battery module must be less than the maximum output power of the battery module.
- Page 10 Warning For the inverter with only one battery input port, the wiring method of the combiner box must be added. For 2 units -15 units is 5KW - 10KW. (The number of units in the middle of the diagram is omitted.In order to ensure equal current flow, the length of the two positive and negative poles connecting lines must be the same.) Warning...
- Page 11 Warning When using an inverter of 10kW or above, the positive and negative ports of each battery must be connected to the combiner cabinet in the wiring method shown in the figure below. For 2 units -15 units is 10KW - 20KW. (The number of units in the middle of the diagram is omitted.In order to ensure equal current flow, the length of the positive and negative poles connecting lines must be the same.)
- Page 12 to Inverter to Inverter...
