  • Page 1 ® Ergonomic Chair User Manual...
  • Page 2 Make Work Enjoyable.
  • Page 3 PRODUCT OVERVIEW Applicable Environment: Indoor use, not suitable for open air and humid environment Product Purpose: Suitable for study room, office, business workspace and others Loading Capacity: 136kg or less (300 lbs or less) Carried Standard: Applicable Standards, ANSI BIFMA X5.1, EN1335, QBT 2280 Safety Precaution: Can not ride backwards.
  • Page 4 In The Box...
  • Page 5 In the Box M8 Screw (x2) Alley Key (x1) Caster (x5) Chair Body (x1) Wheel Base (x1) Gas Lift (x1) Right Armrest (x1) Left Armrest (x1)

  • Page 6: Assembly Guide

    Assembly Guide...

  • Page 7: Assembly Process

    Assembly Process Install the Casters. Insert the 5 Casters into the Wheel Base. Push firmly to lock them into place. Install The Gas Lift. Position the Gas Lift into the Wheel Base.
  • Page 8 Assembly Process Install The Armrests. Install the chair Left and Right Armrests by Allen Key and M8 Screws.
  • Page 9 Assembly Process Install The Gas Lift and Wheel Base Align the top of the Gas lift into the bottom of the Chair Body Tilt Mechanism. Push to lock it into place.
  • Page 10 Assembly Process Flip The Chair Over. Installation is complete. Flip the chair over from the ground.
  • Page 11 Assembly Process Test And Adjust. Adjust the chair settings by following the next chapter: User Guide.
  • Page 12 User Guide...

  • Page 13: Seat Height Adjustment

    Seat Height Adjustment Joystick is in front of the right armrest. Release the joystick to lock the height. Recommendation: Adjusting to the position where your legs are vertical while sitting and your feet are flat on the ground. Lower Raise You can angle the joystick without Angle the joystick then the seat will overbending yourself.
  • Page 14 Lumber Adjustment Joysticks are located on both sides of the backrest. Adjust the lumbar with both hands at the same time to dynamically fit your back. WARNING: Do not operate the lumbar support with one hand or adjust it while laying on it to avoid damaging the product.

  • Page 15: Seat Depth Adjustment

    Seat Depth Adjustment Joystick is at the back of right armrest. Lift the joystick, slide the seat forward and backward, you will feel comfortable after long-time sitting. Recommendation: Adjusting to a position where there is at least 5 cm gaps between the back of the knee and the edge of the seat.

  • Page 16: Adjust Angle

    Backrest Angle Lock The joystick is on the left side of the armrest. With the leg rest function (for some models), you can enjoy the zero gravity experience. Please release the joystick after adjustment. Adjust Angle Lock Lean back and adjust the joystick to Loosen the joystick to release, smoothly.
  • Page 17 Tilt Tension Control - Model 1 Adjustment handle is at the bottom of the seat pad. You can adjust the back elasticity by rotating the handle in accordance with your weight. Recommendation: Adjusting to an angle that you can feel resistance when leaning back, but with some difficulty in leaning.
  • Page 18 Tilt Tension Control - Model 2 The handle is at the bottom of the right side seat pad. You can adjust the back elasticity by rotating the handle in accordance with your weight. Recommendation: Adjusting to an angle that you can feel resistance when leaning back, but with some difficulty in leaning.

  • Page 19: Arm Height Adjustment

    Arm Height Adjustment The bottom is at the bottom of the armrest. Press the button to unlock. Recommendation: Adjusting to a position where your elbows can touch the surface of armrests when your shoulders are naturally drooping. Unlock Height Adjustment Press the button to unlock...

  • Page 20: Angle Adjustment

    Neck Support Adjustment Multi-dimensional flexible adjustment to fit the neck curve position. Recommendation: Adjusting to a degree where the head and neck support can carry the neck and shoulders to maintain the position of the cervical spine when naturally bent. Height Adjustment Angle Adjustment...
  • Page 21 Arm Cap Adjustment You can adjust and rotate the armrest covers to fit your preferred angle. Recommendation: Adjust the armrest covers to support the hand-elbow-shoulder alignment when sat down. Four Directions Sliding Adjustment You can directly slide the armrest cover You can rotate the armrest cover.
  • Page 22 Stretchable Leg Support - Some Model Adjusting the leg support with the angle of the backrest will provide the best body support and lead to a comfortable experience. Recommendation: Adjusting to a position where the leg rest can support your calf. Flip Up Pull Pull to a suitable position...

  • Page 23: Maintenance

    Maintenance...
  • Page 24 Maintenance With regular care and maintenance, HEXCAL product is able to provide many years of superior performance. To maintain the quality and satisfaction of HEXCAL product, please follow the cleaning procedures as followed: When in use: • Do not touch it with blades or sharp objects.
  • Page 25 Fabric seatback Normal cleaning • Vacuum fabric as needed using an upholstery attachment. • Do not brush fabric or use a vacuum attachment with a rotary brush. • Brushing may permanently damage the nap or change the character of the fabric. •...
  • Page 26 • With top-quality leather, perfection is not flawless. HEXCAL leather is like any other premium leathers. It has some tiny and subtle markings caused by the healed nicks and cuts that occur during the life of the animals. The unique beauty and character of HEXCAL products lies on such natural markings.
  • Page 27 Caring for Leather The leather of HEXCAL is extremely soft, supple, durable and resistant. To keep it that way, it’s important to care for your leather as follows: Normal cleaning 01 Frequent vacuum or dusting with clean and dry cloth. Too much scrubbing may damage the leather.

  • Page 28: Troubleshooting

    Troubleshooting Solution Failure Causes Seat cannot lift up 01 The seat cushion is loaded when adjusting the Adjust the height when the cushion is empty height 02 The seat cushion has reached the highest level Please set your preferred height between the highest and lowest range Seat height cannot be fixed 01 The height control paddle is released...

  • Page 29: Warranty

    02 faulty workmanship 03 faulty function within 2 years of purchase (if any part is no longer available or out of manufacture HEXCAL will replace it with a functional replacement part). This warranty will only be valid if the product is purchased.
  • Page 30 Do not soak or wash the product in water! Do not hang any bags or place any objects on the armrests Do not use any part or accessory not provided by HEXCAL! or the backrest! So as not to affect the stability of the seat.
  • Page 31 Perfect Your Workspace, Perfect Your Work.
  • Page 32 Copyright © 2015 - 2024 Hexcal...
