Thank you Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance. Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance.
1-Safety information Before switching on the appliance for the fi rst time read the follow- ing safety hints!: WARNING! Daily use This appliance is intended to be used in household and similar applications such as: -Staff kitchen areas in shops, offi ces and other working environ ments;...
Page 5
1-Safety information WARNING! Make sure carpets or rugs do not obstruct the base or any of the ventilation openings. After installation, the appliance must be positioned so that the plug is accessible. The maximum load capacity of dry clothes depends on the model used (see control panel).
1-Safety information Intended use This appliance is intended for washing machine-washable laundry only. Anytime follow the instructions given on the label of each garment label. It is designed exclusively for domestic use inside the house. It is not intended for commercial or industrial use.
2-Installation 2.1 Preparation Make sure there is no transport damage. Make sure all transport bolts are removed. Handle the appliance always with at least two persons because it is heavy. Take the appliance out of the packaging. Remove all packaging material including protecting fi lm on cabinet, polystyrene base, keep them out of children reach.
Page 8
2-Installtion Note: Keep in safe place Keep the transportation bolts in a safe place for later use. Whenever the appliance is to be moved at fi rst reinstall the bolts. 2.4 Moving the appliance If the machine is to be moved to a distant location, re- place the transportation bolts removed before instal- lation to prevent damage.
Page 9
2-Installation Following connections are possible: 2.6.1 Drain hose to sink Hang the drain hose with the U-support over the edge of a sink with adequate size (Fig. 2-5). Protect the U-support suffi ciently against slip- ping. 2.6.2 Drain hose to waste water connection The internal diameter of the stand pipe with vent-hole must be minimum 40 mm.
Page 10
2-Installation 2.8 Electrical Connection 2-10 Before each connection check if: power supply, socket and fusing are appropriate to the rating plate. the power socket is earthed and no multi-plug or extension are used. the power plug and socket are strictly according. Only UK: The UK plug meets BS1363A standard.
3-Practical hints 3.1 Load tips When sorting laundry, make sure: • have eliminated metallic objects such as hair clips, pins, coins, from laundry; • to have buttoned pillow cases, closed zips, tied loose belts and long robe ribbons; • to have removed rollers, hooks or clips from curtains; •...
Page 12
3- Practical hints Note: Detergent When washing heavily soiled whites, we recommend using cotton programs of 60°C or above and a normal washing powder (heavy duty) that contains bleaching agents that at medium/high temperatures provide excellent results. For washes between 40°C and 60°C the type of detergent used needs to be appropri- ate for the type of fabric and level of soiling.
4-Product description Note: Deviations Due to technical changes and diff erent models, the illustrations in the following chap- ters may diff er from your model. 4.1 Picture of appliance Rear side (Fig. 4-2): Front (Fig. 4-1): 1 Detergent / Softener drawer 1 Transportation bolts (T1-T4) 2 Worktop 2 Power cord...
5-Control panel 4 Function buttons 1 Programme selector 3 Detergent/Softenener drawer 5 “Start/Pause” button 2 Display Note: Acoustic signal The acoustic signal can be selected if necessary: see DAILY USE (P29, 8.13) 5.1 OFF Turn the knob to any position (except OFF) to start the machine.
Note: Factory settings To get best results in each programme Hoover has well defi ned specifi c default set- tings. If there is no special requirement default settings are recommended. on " "...
Page 16
5-Control panel on " " 5.5.3 Function button“ “ Dose r (Fig. • Thanks to Eco Doser (Fig.5-9), the appliance is able to suggest the optimal amount of washing detergent to pour into the drawer based on the actual load. •...
Page 17
5-Control panel 5-12 5.5.6 Function button“ “ This button (Fig.5-12) allows you to choose between three • This button (Fig.5-12) allows you to choose between three diff erent options: - PREWASH • This option allows you to make a prewash and it is particular- ly useful for heavily soiled loads (can be used only on some programmes as shown in the table of programmes).
Page 18
5-Control panel 5-13 -STEAM LEVEL 5-14 • After selecting the STEAM CARE PRO programme, you can use this button to choose between three steam treatments of diff erent intensities, designed only for dry garments and depending on the type of fabric: (default selection) - COTTON This programme is used for cotton garments.
Page 19
5-Control panel • We recommend a bucket self-cleaning after using the washing machine for 50 times. • When using this program, please do not put any clothes detergent or washing machine cleaner. Note: Options These options must be selected before pressing the START/PAUSE button. If an option is selected that is not compatible with the selected programme then the option indicator light goes off...
Page 20
5-Control panel 5.6.2 Change the language • If you want to change the setting language you will have to press simultaneously “Delay” and “Option” buttons for about 5 seconds, the language choose last time will appear on display, and you will be able to choose a new language (by pressing button “speed” or ”temperature”).
6-Programmes • Yes, Optional, º Detergent compartment for: Detergent Softener or care product Prewash max. kg 10.5 • • • • • 8 30 30 º 1000 1000 Auto Care • • • • • • 9 10 10.5 12 40 40 º...
Page 22
6-Programmes Description of programmes To clean diff erent types of fabrics and various levels of dirt, the washing machine has specifi c programs to meet every need of washing (see table of programmes). Note: Choosing programme Choose programme in accordance with the laundry instructions appearing on labels, especially the maximum recommended temperature.
Page 23
6-Programmes FITNESS CARE The perfect combination of time and performance. Created to eliminate dirt from athletic garments and sportswear. A low temperature wash recommended for small loads of synthetic items. RINSE This program performs 2 rinses with an intermediate spin (which can be reduced or excluded by using the appropriate button).
7-Consumption Scan QR code on energy label for energy consumption information. The actual energy consumption may diff er from the declared one according to local conditions. Note: Auto Weight The appliance is equipped with a loading recognition. At low loading, energy, water and washing time will be reduced automatically in some programmes.
8-Daily use 8.1 Power supply Connect the washing machine to a power supply (220V to 240V~/50Hz; Fig. 8-1). Please refer also to section INSTALLATION (see P28). 8.2 Water connection Before connecting check the cleanliness and clar- ity of the water inlet. Tun on the tap (Fig.
Page 26
8-Daily use 8.4 Care chart Washing Washable up to 95°C Washable up to 60°C Washable up to 60°C normal process normal process mild process Washable up to 40°C Washable up to 40°C Washable up to 40°C normal process mild process very mild process Washable up to 30°C Washable up to 30°C...
8-Daily use 8.6 Selecting detergent Washing effi ciency and performance is determined by used detergent quality. Use only machine wash approved detergent. If needed use specifi c detergents, e.g. for synthetic and woolen fabric. See tips for countertop detergent stickers. Do not use dry cleaning agents such as trichloroethylene and similar products.
8-Daily use 8.7 Adding detergent 1. Slide out the detergent drawer. 2. Put the required chemicals into corresponding compartments (Fig. 8-4) 3. Push back the drawer gently. Note: Detergent Remove detergent residues before next wash cycle from the detergent drawer. Do not overuse detergent or softener.
Page 29
6-Daily use 8.11 Start wash programme Touch “Start/Pause” button (Fig. 8-7) to start. Appliance operates according to present settings. Changes are only possible by cancelling the pro- gramme. 8.12 Interrupt / cancel wash programme To interrupt a running programme press gently “Start/Pause“. The LED above the button is fl...
9-Remote control (Wi-Fi) 9.1 General This appliance is equipped with Wi-Fi technology that allows you to control it remotely via App. WARNING! Please observe the safety precautions in this user manual and make sure that these are complied with even when operating the appliance via the hOn APP while you are away from home.
Page 31
9-Remote control (Wi-Fi) 9.4 Appliance pairing (on app) 1. The App is available for devices running both Android and iOS, both for tablets and for smartphones. 2. Get all the details of the Wi-FI functions by browsing the App in DEMO mode. The frequency of the home Wi-Fi network has to be set on the 2.4 GHZ band.
10-Care and Cleaning 10.1 Cleaning the detergent drawer 10-1 Take always care there are no detergent residues. Clean the drawer regularly (Fig. 10-1): 1. Pull out the drawer until it stops. 2. Press the release button and remove the drawer. 3.
Page 33
10-Care and Cleaning 10.5 Long periods of disuse 10-6 10-7 If the appliance is left idle for a longer period: 1. Pull out the electrical plug (Fig. 10-6). 2. Turn off water supply (Fig. 10-7). 3. Open the door to prevent formation of moisture and odours.
Page 34
10-Care and cleaning 9. Clean carefully pump fi lter, e.g. using running 10-15 10-14 water (Fig. 10-14). 10. Refi x it thoroughly (Fig. 10-15). 11. Close service fl ap. CAUTION! Pump fi lter sealing has to be clean and unhurt. If the lid is not full tightened, water can escape.
11-Troubleshooting Many occuring problems could be solved by yourself without specifi c expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
Page 36
11-Troubleshooting Problem Cause Solution • Temperature sensor error. • Contact the After sales service. • Heating error. • Contact the After sales service. • Motor error • Contact the After sales service • Water level sensor error. • Contact the After sales service. •...
Page 37
11-Troubleshooting Problem Cause Solution Excessive foam fl oats • Detergent is not a appropriate. • Check detergent recommen- drum and/or deter- dations. gent drawer. • Excessive use of detergent. • Reduce amount of detergent. Automatic adjust- • Washing programme duration will •...
12-Technical data 11.1 Additional technical data H7W 448* H7W 449* H7W 610* H7W 69* H7W4105* H7W 412* Voltage in V 220-240 V~/50Hz Current in A Max. power in W 1900 Water pressure in MPa 0,03-≤P≤1 Netto weight in kg 11.2 Product dimensions PRODUCT DIMENSIONS H7W 448* H7W 449* H7W 610* H7W 69* H7W4105* H7W 412* Overall height of product mm...
If you cannot fi nd a solution there, please contact your local dealer or the Assistence Area on the Hoover website where you can fi nd information on Warranties, Accessories and Spare Parts and Contact numbers. To contact our Service, ensure that you have the following data available.
