OPERATING INSTRUCTIONS
ZF BIKE ECO SYSTEM
EN
ZF BIKE ECO SYSTEM
© 2025-03
Your dealer:
ZF Micro Mobility GmbH
Escher-Wyss-Strasse 25
88212 Ravensburg
info@zfmicromobility.com
Responsible for technical content:
ZF Staňkov s.r.o.
Plant Staňkov
Ohučov 25
345 61 Staňkov
Czech Republic
https://www.zf.com/ebike
info.zf-micromobility@zf.com
4179.700.009 2025-03-27
4179.700.009 2025-03-27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIKE ECO SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZF BIKE ECO SYSTEM

  • Page 1 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM ZF BIKE ECO SYSTEM © 2025-03 Your dealer: ZF Micro Mobility GmbH Escher-Wyss-Strasse 25 88212 Ravensburg info@zfmicromobility.com Responsible for technical content: ZF Staňkov s.r.o. Plant Staňkov Ohučov 25 345 61 Staňkov Czech Republic https://www.zf.com/ebike info.zf-micromobility@zf.com...
  • Page 2 (cover title) OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM OVERALL SYSTEM 4179.700.009 2025-03-27...
  • Page 3 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 4179.700.009 2025-03-27...
  • Page 4: Table Of Contents

    Introduction ........................1 About this original operating manual ............... 1 Imprint ........................2 Available languages ....................2 Intended use of the ZF Bike Eco System ..............3 Foreseeable misuse ....................4 Responsibilities of the Operator ................5 Residual risks ......................6 Risk minimization through built-in safety functions ..........
  • Page 5 ZF BIKE ECO SYSTEM Radio interface of Core Controller ................12 SIMPLIFIED EU DECLARATION OF CONFORMITY ..........12 Consumer information on data storage ..............12 Function of the ZF Bike Eco System ................13 Basic principle of drive support ................13 5.1.1 Application of drive system ................13 5.1.2...
  • Page 6 Charger ......................... 23 Wiring harness ...................... 24 Batteries of the ZF Bike Eco System ................25 Designated use ...................... 25 Technical Data ....................... 25 Safety notes ......................26 Behavior after contact with battery acid ..............29 Battery use/operation .................... 29 Battery LED Indicator .....................
  • Page 7 9.11 Scope of Supply .....................50 9.12 Troubleshooting .....................50 Quick Start for Normal Use ..................51 10.1 Switching the ZF Bike Eco System on and off ............51 10.2 Selecting the support level ..................54 10.3 Character of Support Modes ..................55 General operation ......................56 11.1...
  • Page 8 Data screen ....................61 11.3.3 Walk mode screen ..................62 11.3.4 Navigation screen ..................64 11.4 Settings screens – settings of the ZF Bike Eco System ......... 65 11.4.1 Navigating within the Settings menu ............66 11.4.2 Brightness ..................... 67 11.4.3 Reset Trip .....................
  • Page 9 12.5 Other ........................81 Care and Maintenance ....................82 13.1 Hazards due to pressure jet cleaning ..............82 13.2 Firmware update via the ZF Bike Eco System app ..........83 Storage ........................83 14.1 Suitable state of charge of the battery..............83 Transportation ......................84 15.1 Protective measures in case of rain, dust, and extreme temperatures ....84 15.2...
  • Page 10 19.1 ZF CentriX mid-mounted motor ................90 19.1.1 Electrical connected loads ................90 19.1.2 Mechanical Data ................... 90 19.1.3 Environmental conditions ................90 19.2 Core Controller ...................... 91 19.3 Remote ........................91 19.4 Color display ......................91 19.5 Battery SI 504 ......................92 19.6...
  • Page 11: Introduction

    Introduction About this original operating manual This operating manual for the ZF Bike Eco System from ZF Micro Mobility GmbH is part of the original operating instructions for the entire pedelec. It is therefore another applicable document for the entire documentation on the components of this system installed in your pedelec.
  • Page 12: Imprint

    345 61 Staňkov Czech Republic Reprinting, translation, any duplication, or other commercial use, including excerpts on dig- ital media, is not permitted without prior written consent of ZF Staňkov s.r.o. Available languages These overall operating instructions are available in the following languages:...
  • Page 13: Intended Use Of The Zf Bike Eco System

    ZF BIKE ECO SYSTEM Intended use of the ZF Bike Eco System The ZF Bike Eco System is intended for use in pedelecs (in accordance with EN 15194:2017+A1:2023). The ZF Bike Eco System with all its components may only be used in the pedelec intended for this purpose in the combination provided.
  • Page 14: Foreseeable Misuse

    Foreseeable misuse The manufacturer is not responsible for any other use of the ZF Bike Eco System, e.g., when taken from the pedelec and/or in other combinations or with modifications. Functional safety of drive system can only be warranted with original compo- nents of ZF Bike Eco System.
  • Page 15: Responsibilities Of The Operator

    ZF BIKE ECO SYSTEM Responsibilities of the Operator Pedelecs with the ZF Bike Eco System have the same status as bicycles in Germany, which means that children can theoretically also ride them. Even a mentally impaired person could ride it.
  • Page 16: Residual Risks

    Residual risks Even if you use the ZF Bike Eco System as intended, residual risks remain. The possibility of these residual risks cannot be excluded despite careful development by ZF Micro Mobility GmbH and the pedelec manufacturer. These residual risks can be reduced, but not eliminated. They are unpredictable. Make your-...
  • Page 17: Risk Minimization Through Built-In Safety Functions

    Risk minimization through built-in safety functions The ZF Bike Eco System is intended for pedelecs, which are defined in the EU by the EN 15194:2017+A1:2023 standard. The conformity of your pedelec with EN 15194 is veri- fied in the EU-prescribed CE process. EN 15194:2017+A1:2023 is harmonized with Ma- chinery Directive 2006/42/EC.
  • Page 18: Marking Of Warning Notices

    This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. A TIP provides key information to make procedures easier or clearer. ZF Micro Mobility GmbH...
  • Page 19: Safety Notes

    Hazards during maintenance, service, and repair The user must not perform any technical service, overhaul, or repair work on the ZF Bike Eco System. The components of the drive system may only be replaced by trained specialist personnel in your dealer's workshop.
  • Page 20: Hazards Due To Hot Surfaces

    Hazards due to hot surfaces The ZF Bike Eco System uses suitable controls to prevent temperatures above 60°C on touchable surfaces. However, slightly higher values may occur for a short time. Please note that a motor that has run hot, for example, will heat up adjacent frame parts and may startle you in case of contact.
  • Page 21: Hazards Due To The Radio Interface

    ® The Bluetooth word trademark and its logo are registered trademarks and the property of Bluetooth SIG, Inc. Any use of this word trademark/logo by ZF Micro Mobility GmbH is un- der license. 11 | 4179.700.009 2026-03-27...
  • Page 22: Used Technologies

    This data is only read out if the dealer diagnostic tool is connected. ZF Micro Mobility will never disclose this data to others, except in the cases listed below. ZF Micro Mobility can commission a contractual partner with data management.
  • Page 23: Function Of The Zf Bike Eco System

    5 Function of the ZF Bike Eco System Basic principle of drive support The ZF Bike Eco System is an assisted drive system for pedelec. Depending on the user's pedaling force, it amplifies this force with the power of an electric motor, making it easier to ride than a conventional bicycle.
  • Page 24: Push Assist

    5.2.2 Push assist In addition, a pedelec equipped with ZF Bike Eco Systems is fitted with a push assist that allows purely electric driving up to 6 km/h at the touch of a button. Reasons for lack of support The ZF Bike Eco System does not support you •...
  • Page 25: Components Of The Zf Bike Eco System

    6 Components of the ZF Bike Eco System Overview and short description The ZF Bike Eco System is a component kit that allows for various combinations to be used in your pedelec, depending on the requirements of the pedelec. The following contains an overview of the existing components in the ZF Bike Eco System, but usually only one combination will be installed on your vehicle.
  • Page 26: Drive Unit And Accessories

    Drive unit and accessories • ZF CentriX drive unit with chainring and spider • Speed sensor of the drive unit Shown spider is provided by pedelec maker and not supplied by ZF Micro Mobility. | 16 ZF Micro Mobility GmbH...
  • Page 27: Description

    6.2.1 Description The supportive drive of the ZF Bike Eco System is provided by the CentriX drive unit. The drive unit is an integrated functional unit that contains the actual electric motor, a special shaft transmission, the freewheels and the electronic motor control with sensors for pedal torque , cadence and temperature monitoring.
  • Page 28: Core Controller

    Core Controller The Core Controller is the integrated interface module of the ZF Bike Eco System. It is equipped with BLE, i.e., a Bluetooth® Low Energy wireless interface. Once activated, it of- fers extended functions in combination with a smartphone app.
  • Page 29 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM Properties of the Dataline port • The maximum charging power is 7.5 W. If the drive system enters light reserve mode with the battery pack almost empty, the Dataline connection is deactivated, and charg- ing will no longer be possible.
  • Page 30: Handlebar Operating Elements

    Handlebar operating elements The remote is the handlebar operating element with function buttons. Display elements The color display is the multifunctional handlebar display module with “touch” function | 20 ZF Micro Mobility GmbH...
  • Page 31: Batteries

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM Batteries There are currently two batteries with different capacities available for the ZF Bike Eco Sys- tem, both of which fit into the same battery holder, battery terminal M. • Battery SI 504 with 500 Wh •...
  • Page 32: Battery Terminal

    Battery terminal Battery terminal M contains the battery rail, the plug interface module with rear-light out- put and the lock mechanism. • BT-M for SI 504 and SI 756 batteries | 22 ZF Micro Mobility GmbH...
  • Page 33: Charger

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM Charger BC 200 is the standard charger of the ZF Bike Eco System and delivers a charging power of 200 W. • BC 200 Further technical data on the individual components can be found at the end of this manual in the chapter of the same name, “Technical Data”.
  • Page 34: Wiring Harness

    Data bus cable between battery terminal and Core Controller • Diagnostic cable with magnetic plug between Core Controller and service PC • Charging cable with magnetic plug between Core Controller and mobile device (vari- ants) | 24 ZF Micro Mobility GmbH...
  • Page 35: Batteries Of The Zf Bike Eco System

    The use of this rechargeable battery is exclusively intended for the power supply of compat- ible systems from ZF Micro Mobility GmbH and may not be used for other purposes. This battery is qualified for Pedelecs following EN 15194:2017+A1-2023. The battery is safe to operate when delivered.
  • Page 36: Safety Notes

    Do not connect the (+) and (-) pins or other contacts to metal objects. Do not transport or store the rechargeable battery together with metal objects such as necklaces, hair- pins or metal shavings. Short circuit, overheating, burns or other injuries may result. | 26 ZF Micro Mobility GmbH...
  • Page 37 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM • The rechargeable battery and charger may not be deformed or opened. The application of soldering tin is prohibited. • The rechargeable battery may not be subjected to mechanical shocks, as this can result in damage to the battery.
  • Page 38 • If the rechargeable battery swells or starts to smoke, please inform the fire department immediately, carefully remove other batteries if possible, and evacuate all persons from the danger zone. | 28 ZF Micro Mobility GmbH...
  • Page 39: Behavior After Contact With Battery Acid

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM • Keep the rechargeable battery away from children; playing with the rechargeable bat- tery is strictly prohibited. Improper use can lead to serious injury or even death. • This battery is not intended for use by persons (including children) with reduced physi-...
  • Page 40: Battery Led Indicator

    Do not use a defective rechargeable battery and please contact the point of sale or a bicycle dealer. • Before removing or reinserting the battery, switch off the battery or the ZF Bike Eco System completely. Battery LED Indicator The rechargeable battery has three LEDs for indicating the battery's state of charge and error messages.
  • Page 41 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 31 | 4179.700.009 2026-03-27...
  • Page 42: Operating Temperature Ranges

    If you do not need the charging port on the bicycle, please cover it with the dust cover to prevent dirt from getting into the contacts. • Check the cable and the power plug for damage before plugging them in. If you notice any damage, please replace the power cable. | 32 ZF Micro Mobility GmbH...
  • Page 43 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM • To avoid electric shock, only touch the charger with dry and clean hands. Also ensure that the charger is not exposed to moisture. • Please do not cover the rechargeable battery and charger during charging.
  • Page 44: Notes On Storage

    Take the battery to be recycled back to the point of sale or to a bicycle dealer. Lithium-ion batteries are recyclable, valuable resources. In accordance with Directives 2012/19/EU and 2023/1542, rechargeable batteries that are no longer usable must be collected separately and recycled in an environmentally friendly man- ner. | 34 ZF Micro Mobility GmbH...
  • Page 45: Guarantee Conditions

    The battery comes with a two-year warranty. During this period, any defects that are de- monstrably due to material defects or manufacturing defects will be remedied by replacing or repairing the defective parts. ZF Staňkov s.r.o. reserves the right to choose the method of remedying defects.
  • Page 46: Inserting The Battery

    1). After insertion, the rechargeable battery must be guided parallel to the rail in the direction of the contacts. Figure 1: Inserting the rechargeable battery SI 504 and SI 756: Then latch the locking system in using the release lever and lock it with the key. | 36 ZF Micro Mobility GmbH...
  • Page 47: Removing The Rechargeable Battery

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM Safety instructions: There is a risk of pinching your fingers when inserting or removing the battery. Perform the movement carefully. The risk increases if there is dirt on the bat- tery or battery holder. Keep them clean.
  • Page 48: Transportation

    If you have any further questions about transportation, please contact the point of sale or a bicycle dealer. 7.16 Declaration of conformity The declaration of conformity of batteries SI 501 and SI 756 batteries can be viewed on the following page: https://www.zfmicromobility.com | 38 ZF Micro Mobility GmbH...
  • Page 49: State Of Charge And Range

    ZF BIKE ECO SYSTEM 8 State of Charge and Range To use the drive support provided by the ZF Bike Eco System, the battery must be suffi- ciently charged. Frequent charging is generally not a problem with lithium-ion batteries, but it is not recommended to leave the charger connected to the battery for long periods of time.
  • Page 50: Charging Strategy

    Charging strategy When using a new battery or a new ZF Bike Eco System powered pedelec for the first time, fully charge the battery once. Observe whether the charging process runs smoothly and contact your dealer if anything is unclear. There is electric energy involved.
  • Page 51: Evaluating The Existing Battery Capacity

    This is called the light reserve area (LRA) Your influence on the range The level of support selected by the ZF Bike Eco System has a direct influence on the achievable range with the given battery capacity and its state of charge (available amount of energy).
  • Page 52: Cases In Which Range Will Decrease Noticeably

    If the tire pressure is too low • If the chain runs poorly, i.e., not smoothly. • If the brake is not well adjusted and, for example, is constantly dragging and thus hav- ing a constant braking effect. | 42 ZF Micro Mobility GmbH...
  • Page 53: Influence Of Optional Consumers

    Wh/km are typical for pedelecs, according to the abovementioned dependencies. (Riding with support). The battery in the ZF Bike Eco System knows your current consumption based on the kilo- meter last ridden (in Wh/km). Together with the remaining battery capacity, the remaining range can thus be determined.
  • Page 54: Bc 200 Charger

    Nominal voltage is a classification. The (approx. average) cell nominal voltage of a lithium- ion cell is 3.6 V. For the ZF Bike Eco System, 14 cell groups are connected in series. The result is a total cell nominal voltage of 14 x 3.6 V = 50.4 V, which is slightly higher than the system's nominal voltage of 48 V.
  • Page 55: Intended Use

    The charger is designed and manufactured using the state-of-the-art technology. The charger is safe to operate when delivered. The ZF product can be dangerous if it is used improperly or not as intended by unauthorized and untrained persons.
  • Page 56 • Use the charger only for systems of the ZF Bike Eco System, otherwise there is a risk of explosion and fire. • To avoid the risk of an electric shock, do not unplug a wet plug from the bike. If the charger plug is already wet inside or outside before charging, do not connect the charger to the bike.
  • Page 57: Technical Data

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM • The charger must be placed on a solid surface during the charging process, as it may get damaged if it is dropped. • If the charger is not to be used for a longer period, please disconnect it from the power supply to prevent damage caused by overvoltage.
  • Page 58: Operation

    LED, you can connect the e-bike / battery to the charger. Errors If the battery is placed in the e-bike during the charging process, you can view any error messages in the ZF Ride app. Additional the charger has an LED that displays the device status. LED color...
  • Page 59: Conformity

    If there is an odor or smoke or if the battery is too hot to touch, interrupt the charging pro- cess immediately and contact the customer service for the vehicle or battery manufacturer or ZF Micro Mobility. If possible, carry the battery or charger outside, e.g., under a roof, until it has been cleared.
  • Page 60: Scope Of Supply

    However, the charging pro- Check whether the charger Allow them to cool down cess starts and ends immedi- and the battery heat up. to room temperature. ately when the LEDs start flashing. | 50 ZF Micro Mobility GmbH...
  • Page 61: Quick Start For Normal Use

    10 Quick Start for Normal Use 10.1 Switching the ZF Bike Eco System on and off The ZF Bike Eco System is switched on and off at the Core Controller. The Core Controller is often located in the top tube, below the handlebars.
  • Page 62 This animation signals that the software is starting up. The details given below During this time, the color display will show a logo. For example, the ZF logo. At the end of the start-up animation of the LED ring on the Core Controller, the LEDs change to indicate the battery's current state of charge.
  • Page 63 When the ZF Bike Eco System is fully operational, the handlebar display shows the stand- ard display (ride screen) with the current speed, range and selected support level. By default, the ZF Bike Eco System starts with the last support level you selected so that you can set off immediately.
  • Page 64: Selecting The Support Level

    10.2 Selecting the support level You can choose between four support modes and riding without support: ECO – ACTIVE – SPORT – BOOST – OFF. All other ZF Bike Eco System functions are available to you even without drive support.
  • Page 65: Character Of Support Modes

    Until recently a special feature of a pedelec, dynamic adaptation to the rider's request for assistance (adaptivity) is now integral to the control of all support levels. With the ZF Bike Eco System, adaptivity is particularly important in ACTIVE and SPORT mode, as it energeti- cally releases the power when required and yet the range does not suffer greatly.
  • Page 66: General Operation

    In addition to the simplified operation using the two buttons on the Core Controller, the combination of remote and color display is the most convenient way to control the ZF Bike Eco System and maintain an overview of all functions at all times.
  • Page 67 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM The color display is the information center of the ZF Bike Eco System. Its surface is touch-sensitive, which makes it possible to operate the system using swipe and tap gestures. These gestures are explained below.
  • Page 68: Touch Control Of The Color Display - Gestures And Tapping

    In the Settings menu, you can scroll up and down a list to display additional items. Example views of the color display: Opening a submenu by tapping, scrolling the list up or down, confirming the selection by tapping again. | 58 ZF Micro Mobility GmbH...
  • Page 69: Riding Screens - Displays During The Ride

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 11.3 Riding screens – displays during the ride During normal use of supported riding, the color display will show you all the information you need on the riding screens. The display is subdivided into the following: •...
  • Page 70: Ride Screen

    With its central number display, the ride screen is the default screen of the color display in the ZF Bike Eco System. In addition to speed, the large number in the middle can be personalized to show one of a selection of current values.
  • Page 71: Data Screen

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 11.3.2 Data screen In addition to the header and footer, you can place four other current data types on info tiles in the data screen display. You can create a personalized compilation from the large selection of available information.
  • Page 72: Walk Mode Screen

    11.3.3 Walk mode screen Walk mode is the push assist function of the ZF Bike Eco System. For your safety, it is acti- vated in two stages. 1. If the Walk button on the remote is pressed, the Walk mode display will appear.
  • Page 73 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 4. While you hold down the up button on the remote and push assist is powered by the motor, the current speed will be displayed. 5. To exit Walk mode, release the up button on the remote or press any other button.
  • Page 74: Navigation Screen

    If dashes appear in the fields instead of the above display, this information is missing, and you must pair the smartphone for the first time or pair it again. You may also be notified to start navigation in the ZFMM Ride app now. | 64 ZF Micro Mobility GmbH...
  • Page 75: Settings Screens - Settings Of The Zf Bike Eco System

    A long press on the info button “i” on the remote or a downward swipe on the color display will take you to the Settings screens of the ZF Bike Eco System. You can navigate to the following menu items using the up and down buttons or by swiping up and down on the color display: •...
  • Page 76: Navigating Within The Settings Menu

    The top list item “Back” will take you back to the next higher level. By scrolling to “EXIT” at the top of the list and tapping to confirm, you can exit the settings screens and get back to your last selected view, usually the home screen. | 66 ZF Micro Mobility GmbH...
  • Page 77: Brightness

    11.4.3 Reset Trip Here you can set the tour data under “Trip” to zero. This reset has no influence on the total mileage of your ZF Bike Eco System. 67 | 4179.700.009 2026-03-27...
  • Page 78: System

    You can also choose between 12 h and 24 h display for the time. 11.4.5 Display Factory Reset – factory settings Here you have the option of resetting all color display settings, especially if the overview has been lost. However, Trip will also be reset. | 68 ZF Micro Mobility GmbH...
  • Page 79: Data Screen

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 11.4.6 Data screen By tapping, you can set or remove check marks and thus decide whether one or two data screens are to be displayed within the riding screens. To personalize the data screens, also refer to Chapter “Personalization menu”.
  • Page 80: Information

    11.4.8 Information Basic information on your ZF Bike Eco System can be called up here. Divided into components, the respective status is displayed, e.g., the serial number of the motor unit, its total mileage, current software (bootloader version; firmware version).
  • Page 81: Personalization Menu

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 11.5 Personalization menu One or two data screens can be displayed within the riding screens, each with four info tiles, which display up to eight types of data from a selection. By tapping the tile, data from a selection can be filled or later changed to other data types.
  • Page 82: Switching On The Lights

    “Auto” can only be selected if a brightness sensor is present. If there is no brightness sensor in the system, the ZF Bike Eco System will use a date- and time-controlled auto mode for the lights, which, however, works less precisely.
  • Page 83: Switching Off The Zf Bike Eco System

    ZF BIKE ECO SYSTEM 11.7 Switching off the ZF Bike Eco System Press the power button on the Core Controller for 1 second to switch off the ZF Bike Eco System. Depending on whether you have personalized the system with your name or not, the display will show “Bye”...
  • Page 84: Automatic Switch-Off

    11.9 Forced switch-off If you recognize the rare partial failure of a component, you can force a complete shut- down of the ZF Bike Eco System by pressing and holding the power button (>10 sec- onds). Subsequent reactivation enables the ZF Bike Eco System to be started up in an orderly manner.
  • Page 85: Display During Charging

    ZF BIKE ECO SYSTEM 11.10 Display during charging The battery of the ZF Bike Eco System can be charged while inserted in the pedelec or separately. During the charging process inside the Pedelec, the color display remains switched off and the Core Controller provides information on the battery's state of charge via its LEDs, which flash in 8% increments.
  • Page 86: Charging A Mobile Device

    11.12 Error, warning, and info displays Note any system codes shown on the color display, which can make the initial analysis much easier when contacting the dealer by telephone. Please also refer to Chapters 17 and 18. | 76 ZF Micro Mobility GmbH...
  • Page 87: Zf Ride App

    12 ZF Ride App 12.1 Download of the app With the ZF Ride app, we offer you a comprehensive companion to your ZF Bike Eco System e-bike for navigation, route planning and riding statistics. The app is available on the Apple App Store and Google Play Store.
  • Page 88: Map Download

    For using the navigation function, you need to download the offline map for your desired country. You also have the option to download multiple maps. 12.3 Functions & Screens The ZF Ride app offers you various functions and features for more comfort and riding pleas- ure. 12.3.1 Navigation You have the option of using the built-in navigation function: •...
  • Page 89: Dashboard

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM • Range display: Depending on the charge level and the selected route option, the maximum achievable range is displayed for your route. • Recording option: The circle symbol on the left-hand side tells you whether the route is being recorded or not.
  • Page 90: Trips

    Navigation: Customizable settings and navigation language • Maps: Possibility to download additional maps (worldwide) • Account: User's personal information such as weight, height, date of birth and gender • Info: General information about the app and privacy policy | 80 ZF Micro Mobility GmbH...
  • Page 91: Other

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 12.5 Other Display Integration If your bike is equipped with a display, selected information from the connected app can also be displayed on the display, such as ride information and simplified navigation com- mands. For more information, see the chapter on the description of the display.
  • Page 92: Care And Maintenance

    13 Care and Maintenance 13.1 Hazards due to pressure jet cleaning The components of the ZF Bike Eco System are protected against all weather conditions. The entire system is rated IP 55. Nevertheless, water and accompanying dirt can get into the housing if strong jets of water with increased pressure, such as those from a high-pressure cleaner, are aimed at the seals.
  • Page 93: Firmware Update Via The Zf Bike Eco System App

    Via the Core Controller's Bluetooth interface together with the ZF Bike Eco System app on your smartphone, the ZF Bike Eco System is in principle able to receive new firmware for individual components (OTA update) and then import it centrally (also called a flash pro- cess).
  • Page 94: Transportation

    15 Transportation The ZF Bike Eco System is designed for use in damp and dusty environments, i.e., for eve- ryday use in the city or outdoors. However, the following must be observed when transport- ing it on bicycle racks, especially on vehicles such as buses, trains or your own car. In addi- tion to water and dust, extreme temperature conditions can also arise during transportation.
  • Page 95: Transport To Vacation Destinations

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 15.2 Transport to vacation destinations Find out about the conditions of carriage for pedelecs from your travel company or the planned public carrier in good time before starting your journey. Bus, train, ferry, forwarding agent.
  • Page 96: Disposal Instructions (Eu)

    Like all electrical or electronic products and batteries made available on the market in the European Union, the components of the ZF Bike Eco System must be returned to the ma- terial cycle at the end of their service life or when they have been replaced due to a defect.
  • Page 97: System Messages

    ZF BIKE ECO SYSTEM 17 System Messages The ZF Bike Eco System offers various options for detecting the cause of a malfunction or lack of function. You can do a lot of troubleshooting yourself. In addition to instructions on various general error patterns, the ZF Bike Eco System uses system event messages to give you and your dealer much more information.
  • Page 98 Reboot the system. If the error persists, 1524 has detected an please contact the dealer. error. Error 1030, 1130, Communica- Communication Please contact your dealer. 1230, 1330, 1430, tion error detected. 1530, 1630 Continued next page | 88 ZF Micro Mobility GmbH...
  • Page 99 OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM Display line 1 Display line 2 Description Measure Error 1034 Authentication Authentication error de- Please contact your dealer. Error 1234 tected. Error 1160 Bluetooth Bluetooth error Please contact your dealer. Error 1161 Mobile phone charg-...
  • Page 100: Technical Data

    European transitional climates or warm continental climates (coasts). The entire system is rated as protection class IP 55 against ingress of dust and water. Indi- vidual components achieve even higher protection classes, as listed below. 19.1 ZF CentriX mid-mounted motor 19.1.1 Electrical connected loads Nominal voltage input...
  • Page 101: Core Controller

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 19.2 Core Controller Supply voltage 12 V DC Operating temperature -5°C to +40°C Storage temperature + 10°C to + 40°C Humidity, use and storage 5% - 100% relative humidity (RH) Degree of Protection IP 55 Radio Interface Bluetooth©...
  • Page 102: Battery Si 504

    19.7 Battery Terminal M Case Color Black Supply voltage 48 V Operating temperature -5°C to +40°C Storage temperature 10°C to 40°C Humidity, use and storage 5% - 100% relative humidity (RH) Degree of Protection IP 55 | 92 ZF Micro Mobility GmbH...
  • Page 103: Bc 200 Charger

    OPERATING INSTRUCTIONS ZF BIKE ECO SYSTEM 19.8 BC 200 charger Supply voltage 180 – 264 V AC / 47-63 Hz Operating temperature 0°C to 40°C Storage temperature 20°C to 60°C Humidity, use and storage 10% - 90% relative humidity (RH)
  • Page 104: Conformity

    20 Conformity The ZF Bike Eco System doesn’t constitute a pedelec in accordance with EN 15194:2017+A1:2023, but rather its drive system. As such, it fulfills the EC Declaration of Incorporation (DoI) in accordance with Annex II-B of the Machinery Directive.
