UnionTech RSPro Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RSPro Series
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSPro Series and is the answer not in the manual?

Questions and answers

Related Manuals for UnionTech RSPro Series

Summary of Contents for UnionTech RSPro Series

  • Page 1 RSPro Series User Manual...
  • Page 3 User Manual of RSPro Series 3D Printer Third-party registered trademark: Shanghai Union Technology Corporation (UNIONTECH) declares that all trademarks are the property of their legal owners. Shanghai Union Technology Corporation hereby declares that, all the information provided in this document is correct at the time of printing, and subject to change due to improvements in performance and quality of the product without prior notice.
  • Page 4 User manual of RSPro series 3D printer Foreword This Manual is a user manual designed for RSPro600 2.0/ RSPro800 2.0 3D printer. Due to different device configurations, the device you purchased may not have all of the following features and accessories, please refer to the actual configuration.
  • Page 5 User manual of RSPro series 3D printer Documents attached to equipment The documents provided with 3D printer provide extensive information for understanding and the application of 3D printer functions, including the following two items: User Manual: This document contains basic information about how to use 3D printer...

  • Page 6: Table Of Contents

    User manual of RSPro series 3D printer Contents 1. Introduction to RSPro series 3D printer ..............1 2. Technical Parameters of Equipment ................2 2.1 Technical parameters of RSPro600 2.0 ............2 2.2 Technical parameters of RSPro800 2.0 ............3 3. Introduction to Main Structures .................4 3.1 Mechanical system ...................4...
  • Page 7 User manual of RSPro series 3D printer 4.3 Production control area ..................22 4.4 Production information monitoring ............... 25 4.5 Production steps .....................28 4.6 Advanced control and process parameter setting ...........29 4.6.1 Operator mode ..................30 4.6.2 Engineer mode ..................33 4.6.3 Experts mode ..................
  • Page 8 User manual of RSPro series 3D printer 7.1.9 Maintenance of transmission lens ............72 7.1.10 Beam expander maintenance ............73 7.1.11 Maintenance of static focusing lens ..........73 7.2 Mechanical maintenance ................74 7.2.1 Maintenance of mechanical systems ...........74 7.2.2 Limit release ..................75 7.2.3 Linear guide maintenance ..............75...

  • Page 9: Introduction To Rspro Series 3D Printer

    This 3D printer improves the efficiency of the shoes mold production greatly. This Manual comprehensively describes technical parameters, main principles, technical, structural and design characteristics, precautions, and post processing of the RSPro series 3D printer, and contains guidelines for application and maintenance of equipment.

  • Page 10: Technical Parameters Of Equipment

    User manual of RSPro series 3D printer 2. Technical Parameters of Equipment Technical parameters of RSPro600 2.0 Appearance： Building range: 600×600×500mm or 23.6×23.6×19.7 in （Full Vat） Layer thickness: 0.05-0.25mm or 0.002-0.01 in Supported file formats: Accuracy: ±0.1mm (L＜100mm)or ±0.1%×L (L≥100mm) or ±0.004 in (L＜3.9 in) or ±0.1%×L (L≥3.9 in)

  • Page 11: Technical Parameters Of Rspro800 2.0

    User manual of RSPro series 3D printer Technical parameters of RSPro800 2.0 Appearance： Building range: 800×800×550mm or 31.5×31.5×21.6 in （Full Vat） Layer thickness: 0.07-0.25mm or 0.003-0.01 in Supported file formats: ±0.15mm (L ＜ 100mm) or ±0.15%×L (L ≥ 100mm) Accuracy: ±0.006 in (L＜3.9 in) or ±0.15%×L (L≥3.9 in)

  • Page 12: Introduction To Main Structures

    User manual of RSPro series 3D printer 3. Introduction to Main Structures The RSPro series 3D printer is mainly composed of three parts: mechanical system, optical system, and control system. Figure 3.1 Main structure diagram Mechanical system The mechanical system is mainly composed of frame, elevator system, resin tank, recoating system, liquid level adjustment system, and automatic resin refill system.

  • Page 13: Frame

    3.1.2 Elevator system Elevator system is an important part of the RSPro series 3D printer, Since the travelling accuracy of elevator determines the uniformity and accuracy of layer thickness of building parts, the travelling accuracy of elevator can directly determine the accuracy of building parts.

  • Page 14: Replaceable Tank Structure

    User manual of RSPro series 3D printer temperature. Figure 3.3 Structure diagram of resin tank The resin tank is composed of an interconnected main tank and area of the liquid level detection. A liquid level sensor installed above the later to detect the change of liquid level and then feed it back to PLC, that will then control the counterweight, to keep the liquid level stable.

  • Page 15: Automatic Resin Refill System

    User manual of RSPro series 3D printer Since resin tank has independent foot margins, to ensure it works normally after each time of tank replacement, the height of foot margins of both resin tank and frame shall be kept unchanged after each time of tank replacement.

  • Page 16: Recoating System

    User manual of RSPro series 3D printer Figure 3.4 Structure diagram of automatic resin refill system 3.1.6 Recoating system The recoating system is used to recoat a cured layer with a thin layer of resin to continue curing process, and RSPro equipment adopts absorption type recoating mechanism.

  • Page 17: Liquid Level Adjustment System

    Z axis lifting mechanism, equipment vibration, or electromagnetic interference, etc. The RSPro series equipment adopts the counterweight filling liquid level control principle, as shown in Figure 3.6, composed of a liquid level sensor and...

  • Page 18: Optical System

    User manual of RSPro series 3D printer counterweight. The liquid level sensor detects the liquid level of resin in the main tank in real time. When the Z axis moves up/down, it inevitably causes the change of liquid level in the main tank, and the counterweight automatically goes up or down according to the detected liquid level to balance level fluctuation and form dynamic stability so as to maintain the stability of liquid level.

  • Page 19: Scanner Scanning System

    User manual of RSPro series 3D printer Output wavelength 355nm Frequency 30-150KHz Maximum Output power 5000mW 3.2.2 Scanner scanning system Equipment model RSPro600 2.0/RSP800 2.0 Brand SCANLAB Scanner model ScanCube10Ⅲ Scanning area 600mm×600mm/800mmx800mm Reference scanning speed 8-15m/s Maximum scanning speed 18m/s Scanner is a special swing motor, with the same rationale as galvanometer;...

  • Page 20: Optical Path Components

    User manual of RSPro series 3D printer 3.2.3 Optical path components Optical path components mainly refer to some small optical components and parts in the optical path, mainly including components of the focussing and retroreflector, the former of which is designed to expand and then focus laser beam always on the working plane.

  • Page 21: Optical Path Protective Cover

    User manual of RSPro series 3D printer Please do not adjust without authorization.  3.2.4 Optical path protective cover In the area where the whole optical path passes, the optical path is covered with a metal box to ensure that optical components and parts in the whole optical path are not contaminated by dust and protect operator from exposure to laser.

  • Page 22: Industrial Personal Computer

    User manual of RSPro series 3D printer Figure 3.11 Basic structure diagram of control system 3.3.1 Industrial personal computer The control computer is used to store and process documents and control the whole machine. When producing, the control software outputs scanning path...

  • Page 23: Scanner Motion Control Card

    User manual of RSPro series 3D printer Equipment RSPro600/ RSPro800/ RSPro600 2.0/RSPro800 2.0 model Brand Siemens Model IPC3000 I3-4130 Hard disk 500G Memory 8GB DDR3 Monitor Industrial LCD monitor I/O port 4×com, 2×RS232 (three extensible) PCI×2 PCIE×2 3.3.2 Scanner motion control card The ON/OFF of laser, moving &...
  • Page 24 User manual of RSPro series 3D printer adjustment, and closed-loop motion control of Z axis and blade, etc. When the equipment gives warning messages or fault alarms, lamps of corresponding colors of the status indicator on the top of equipment will flash.

  • Page 25: Temperature Control System

    User manual of RSPro series 3D printer b. In case of emergency stop action, the red light will flash at the speed of 2S with buzzer. c. When the door protection function is turned on and the door protection is triggered during the work process, the red light will flash at the speed of 0.5s...

  • Page 26: Negative Pressure Control

    User manual of RSPro series 3D printer 3.3.7 Negative pressure control The absorption blade of equipment is provided with the automatic negative pressure regulation function; the PLC control software, based on the information collected from negative pressure sensor, adopts PID control algorithm to automatically adjust the output pulse width of PWM to regulate the operation of vacuum pump, so as to realize fully closed-loop control of negative pressure of blade.

  • Page 27: File Operation

    User manual of RSPro series 3D printer in Figure 5.1: Figure 5.1 RSCON Program Interface File operation 4.2.1 File import Click the "Import file" icon in the file control area, and the file import dialog box pops up (Figure 5.2). In the file selection window, the program automatically detects cli (UCF or USP) files contained in the file directory, and automatically match body layering files and support layering files.

  • Page 28: Production Simulation

    User manual of RSPro series 3D printer corresponding to it or the name of support file is different from the name of body file; if a cli file is displayed in yellow, it indicates the file is only a support cli file, and there is no body file corresponding to it or it has a different name from the body file.
  • Page 29 User manual of RSPro series 3D printer Figure 5.3 Production simulation control bar The file list displays imported files, layer thickness and total height of part; the production of a file can be cancelled by double clicking the box on the left of file name to select the file during simulated production, and the background of the selected file goes dark;...

  • Page 30: Production Control Area

    User manual of RSPro series 3D printer Display the cross-section information of the next 10th layer, e.g. if the current layer is the 100th layer, click this icon to display the cross section of the 110th layer. Display the cross-section information of the previous 10th layer.
  • Page 31 User manual of RSPro series 3D printer Figure 5.5 Production control area Description of icons in the production control area: Options Description Switch for preparation before production: click the icon before each production to initialize the equipment, and the icon becomes green...
  • Page 32 User manual of RSPro series 3D printer Blade clearing; after the icon is clicked, the blade moves to the position set in the program for user to clear dirt at the bottom of blade. Recoating test; the blade moves forth and back once to test the recoating range.

  • Page 33: Production Information Monitoring

    User manual of RSPro series 3D printer Lock screen of software; click the icon to switch to the lock screen interface. Production information monitoring (1) File interface information display area: Cross-section contour information of layering files can be displayed in the center of program interface, and the position of parts in the figure is consistent with their position on the platform.
  • Page 34 User manual of RSPro series 3D printer production speed, and production status bar, etc. a. The liquid level detection diagram displays the fluctuation of liquid level in the latest 15 times in real time; Figure 5.7 Display of liquid level fluctuation b.
  • Page 35 User manual of RSPro series 3D printer d. The operation status bar displays the current work status of machine; when the user performs liquid level adjustment, Z axis lifting and other relevant operations, the status of executed work order is displayed in this area;...

  • Page 36: Production Steps

    User manual of RSPro series 3D printer : Click the icon to hide the production status window, with the number of error messages displayed at the top right corner. Production steps (1) Start the RSCON program, and the system initialization dialog box pops up, as shown in Figure 5.12;...

  • Page 37: Advanced Control And Process Parameter Setting

    User manual of RSPro series 3D printer The start height is 0 by default. Click "Continued" if continuing to produce by following a part previously produced. During production, it's allowed to click the button to pause, click the button to continue production and click the button to end production as needed.

  • Page 38: Operator Mode

    User manual of RSPro series 3D printer Figure 5.14 Login mode / password 4.6.1 Operator mode This authority is the lowest one. It only displays the main interface and the most basic function control interface, and can only perform printing operations.
  • Page 39 User manual of RSPro series 3D printer Figure 5.16 Hardware parameter setting window Figure 5.17 Production parameter setting window...
  • Page 40 User manual of RSPro series 3D printer Figure 5.18 Scanning parameter setting window Figure 5.19 System parameter setting window...

  • Page 41: Engineer Mode

    User manual of RSPro series 3D printer Figure 5.19 Network settings window 4.6.2 Engineer mode It contains all operator permissions, and adds permissions to control the axis. There must be no mechanical or dimming action when opening the door. Figure 5.20 RSCON Program Interface...
  • Page 42 User manual of RSPro series 3D printer Figure 5.21 Hardware control window Figure 5.22 Production parameter setting window...
  • Page 43 User manual of RSPro series 3D printer Figure 5.23 Production parameter setting window Figure 5.24 Scanning parameter setting window...
  • Page 44 User manual of RSPro series 3D printer Figure 5.25 Liquid level parameter setting window Figure 5.26 System parameter setting window...

  • Page 45: Experts Mode

    User manual of RSPro series 3D printer Figure 5.27Network settings window 4.6.3 Experts mode It contains all permissions of engineer operators, and opens all permissions interface. Figure 5.28 RSCON Program Interface...
  • Page 46 User manual of RSPro series 3D printer Figure 5.29 Hardware control window Figure 5.30 Production parameter setting window...
  • Page 47 User manual of RSPro series 3D printer Figure 5.31 Production parameter setting window Figure 5.32 Scanning parameter setting window...
  • Page 48 User manual of RSPro series 3D printer Figure 5.33 Liquid level parameter setting window Figure 5.34 System parameter setting window...

  • Page 49: Core Tech Mode

    User manual of RSPro series 3D printer Figure 5.35 Network settings window Figure 5.36 System parameter setting window 4.6.4 Core Tech Mode Including all permissions of experts, the door can be opened with mechanical and laser adjusting actions. 4.6.5 Hardware control...
  • Page 50 User manual of RSPro series 3D printer axis, liquid level and blade, and set the ON/OFF of laser and vacuum pump. As shown in Figure 5.14. Figure 5.14 Hardware control window Description of icons in the hardware control window: Input the travel distance of blade, of which the value...

  • Page 51: Parameter Setting

    User manual of RSPro series 3D printer ON/OFF Laser power Laser power ON/OFF supply Scanner Scanner power ON/OFF ON/OFF Lighting ON/OFF of lighting lamp in building room ON/OFF If the driver breaks down, i.e. it's found the motor Fault clear stops running, check the box and click the clear button to remove the fault.
  • Page 52 User manual of RSPro series 3D printer Options Description Functions Start height Set the production height from which the blade starts to work Blade Recoating times Set the recoating times of blade in each layer Building height Set the height of platform at the start of production...
  • Page 53 User manual of RSPro series 3D printer Figure 5.16 Hardware parameter setting window Description of icons in the hardware parameter window: Options Description Speed Set the traveling speed of blade Recoating distance Set the max. travel distance of blade at recoating...
  • Page 54 User manual of RSPro series 3D printer the set value, a warning message will be given in the operation status area. Clearing height Set the position of platform at blade clearing Stirring height_1 Set the start position of platform at resin stirring...
  • Page 55 User manual of RSPro series 3D printer mode Both X direction filling and Y direction filling in one layer X direction filling every layer Y direction filling every layer Line Spacing Distance between filling lines (mm) Resin parameter(mm) Resin Resin parameter(mJ/cm...
  • Page 56 User manual of RSPro series 3D printer Warning A warning will be given if the position of counterweight is lower than the value Lower limit at liquid level adjustment or detection to prompt insufficient resin, and now resin should be added.

  • Page 57: Operational Safety Guidelines

    User manual of RSPro series 3D printer Parameter operation The user can save the current program parameters in a file for future use. Input the name of saved file Read the selected parameter file from the list of parameter files...
  • Page 58 User manual of RSPro series 3D printer  It's prohibited for the user to modify the circuits and wiring at the electric panel without authorization.  Please immediately press the emergency stop button in case of emergencies.  It's strictly prohibited to splash substances that decompose resin or react chemically with resin into the resin tank of equipment, including water, alcohol or other resin, etc.

  • Page 59: Equipment Hardware Operation Methods

    User manual of RSPro series 3D printer relevant professionals if not familiar with such regulations.  Enhance the safety awareness of operator, comply with all safety regulations, and stay alert to danger; discuss relevant professionals on the circumstances that may cause danger.
  • Page 60 User manual of RSPro series 3D printer Figure 6.1 Control panel Machine power-on operation: Confirm the emergency stop is released, turn on the power switch, and press the power button of industrial personal computer; the main power is on, the power indicator on the panel is on, and the computer starts with self-check.

  • Page 61: Startup Steps

    User manual of RSPro series 3D printer key is on, the key goes out by pressing it. The keys on the panel are not interlocked. 5.2.2 Startup steps 1) Power on the machine by the methods above; 2) Start RSCON software;...
  • Page 62 User manual of RSPro series 3D printer  Open control software, select port, link to communicate, complete initialization.  Open SHT – ON.  Open DIO-ON.  Wait for current rise, until the system status bar display current value correctly, and wait for 3 to 5 minutes warming up.
  • Page 63 User manual of RSPro series 3D printer c. After "No Errors" appears at the lower right corner, click the button 1 "Emission" to turn to "ON", and now the button turns from grey to green; d. Click "Current set" to adjust current until the power displayed at the lower right corner reaches the required power;...

  • Page 64: Refill Operation

    User manual of RSPro series 3D printer 5.2.3 Refill operation 1) Judge whether it is necessary to refill: At the beginning, reset the Z axis platform, adjust the liquid level to the set position, and then judge the position of counterweight: if it is closer to the lower limit, it's needed to add resin, and if closer to the upper limit, it indicates too much resin is added;...

  • Page 65: Part Building Operation Steps

    User manual of RSPro series 3D printer operation, open the metal cover of laser power detector, start the RSCON software, click "Power detection", and the current laser power will be automatically displayed in the RSCON program interface a few minutes later.

  • Page 66: Part Taking And Post Processing

    User manual of RSPro series 3D printer 5) Start production, and make sure the system is initialized or ready for production before production; 6) Observe the building process at set intervals (e.g. 15min), pause or quit production in case of any abnormality, and rebuild or continue production after eliminating faults or modifying process parameters;...

  • Page 67: Door Protection Function

    User manual of RSPro series 3D printer Quit RSCON, shut down the computer, press the emergency button and then turn off all power. Door protection function 5.3.1 Operator mode / Engineer mode / Experts mode  Machine’s power on standby 1、When any door is opened, the door protection switch will be triggered，and...

  • Page 68: Post Processing Technique

    User manual of RSPro series 3D printer 6. Post processing Technique Post processing quality requirements: Good looking, clean, no scratch on the surface, and not sticky. The operation procedure is as follows: 1) Before the prototype is taken out of machine, view drawings of data to determine the overall structure and support surface structure of the part to be cleaned;...

  • Page 69: Daily Maintenance

    User manual of RSPro series 3D printer 10~20min secondary light curing in the sunlight or UV light drying oven. The curing time can reach up to two hours when high strength is required; 9) After the prototype is cleaned, pay attention to proper placement of prototype to prevent deformation.

  • Page 70: Laser Maintenance

    User manual of RSPro series 3D printer 2. reflector mirror maintenance; 3. Maintenance of variable spot module; 4. Scanning galvanometer maintenance; 5. Dynamic focusing lens maintenance; 6. Field lens maintenance; 7. Scanning galvanometer protection window maintenance; 8. Transmission lens maintenance;...
  • Page 71 User manual of RSPro series 3D printer Normal state Laser speckle processing method:...
  • Page 72 User manual of RSPro series 3D printer 3) If the laser is not used for a long time, it needs to be powered up every half month to extend the service life. 4) When installation the laser or returning it to the factory for repair, please handle it lightly.

  • Page 73: Reflector Mirror Maintenance

    User manual of RSPro series 3D printer there is a large amount of dust, wool, and other impurities accumulated on the fan's heat sink. Please clean the laser after power off, taking care not to damage the fan blades. 7.1.3...

  • Page 74: Variation Spot Maintenance

    User manual of RSPro series 3D printer 7.1.4 Variation spot maintenance Variable spot module plays the role of expanding beam focus and adjusting spot size 1) Spot size concentricity. Regularly check the diameter and concentricity of the large and small spots every 6 months. If there is a deviation, please adjust the diameter of the small and large spots according to the requirements of each model.
  • Page 75 User manual of RSPro series 3D printer cleaning the lens. If it is still> 5%, please contact the supplier to replace the lens. Need professional instruments, please contact after-sale maintenance. 3）Cleaning the module lens Illustration of front focus variable spot module lens:...
  • Page 76 User manual of RSPro series 3D printer Exploded view of assembly and disassembly 图 9 拆镜片工具图示。 Remove and clean lens order: 1) Remove the three screws that press the lens at the lens mounting tube A with the hexagonal socket and take out the lens mounting tube A.

  • Page 77: Maintenance Of Scanning Galvanometer

    User manual of RSPro series 3D printer 3) If the lens is dirty, remove the lens and clean it. Use tool A to remove the ring A of the lens mounting tube A and take out the first lens. Use the tool B to remove the lens holder B and take out the third lens, spacer and second lens.

  • Page 78: Maintenance Of Dynamic Focusing Lens

    User manual of RSPro series 3D printer observe the size change. If the change is large, it is greater than the standard accuracy of the equipment. Need professional instruments, please contact after-sale maintenance. 7.1.6 Maintenance of dynamic focusing lens Dynamic focusing mainly plays the role of beam focusing, realizing real-time dynamic focusing.

  • Page 79: Field Lens Maintenance

    User manual of RSPro series 3D printer maintenance. 3) Abnormal sound check, if there is abnormal sound during the process, if any, please contact the supplier. 7.1.7 Field lens maintenance Field lens mainly plays a focusing role 1) Under the surface of the field lens, observe the surface of the field lens every 6 months to see if there are any resin, dust and other pollutants.

  • Page 80: Scanning Galvanometer Protection Window Maintenance

    User manual of RSPro series 3D printer 7.1.8 Scanning galvanometer protection window maintenance The galvanometer protection window is located below the galvanometer to prevent dust resin from splashing back onto the scanning lens. 1) Scan the upper and lower surfaces of the galvanometer protective window.

  • Page 81: Beam Expander Maintenance

    User manual of RSPro series 3D printer the transmission lens every 6 months to see if there is any resin, dust, etc. on the surface of the transmission lens. 7.1.10 Beam expander maintenance Beam expander for spot magnification 1) Lens contamination. Check the spot of light entering and exiting the beam expander every 6 months.

  • Page 82: Mechanical Maintenance

    User manual of RSPro series 3D printer 1) Lens contamination. Check the spot of light entering and exiting the static focusing lens every 6 months. The power ratio is used to judge whether the lens is contaminated. If there is damage, please use 99% alcohol or acetone, grease-free paper or cotton swab to wipe off the pollutants.

  • Page 83: Limit Release

    User manual of RSPro series 3D printer damaging the surface of the device; 7) Do not hit the device with a blunt device to prevent the surface of the device from deforming; 7.2.2 Limit release Z axis limit A limit occurs when the Z axis moves downward or upward beyond the limit position.
  • Page 84 User manual of RSPro series 3D printer about 32 ~ 150cst to lubricate the linear guide. The loss of lubricating oil is faster than that of lubricating grease. When using it, you must pay attention to whether the oil supply is sufficient. If the lubrication is insufficient, it may cause abnormal wear of the linear guide and reduce its service life.

  • Page 85: Ball Screw Maintenance And Care

    User manual of RSPro series 3D printer 6) Improper tilting of the linear guide may cause the slider to slide out of the guide due to its own weight. Please keep the linear guide horizontal when moving the linear guide.

  • Page 86: Cleaning Of The Scraper

    User manual of RSPro series 3D printer face of the ball nut, and the other end is fixed to the support seat of the ball screw. If the ball screw is in a concealed position, the seal ring can be used for protection and the seal ring can be installed at both ends of the nut.
  • Page 87 User manual of RSPro series 3D printer Grave l surface Specifications:  1. Polished surface There are two types of polished surface, a gravel surface and a diamond surface. 2. Shape There are different shapes, with and without guardrail. Format: Cli,...
  • Page 88 User manual of RSPro series 3D printer Second step; cleaning the scraper Put on gloves, first check the residue on the bottom of the scraper by hand, then rub it gently with a polishing sand bar / silicone board, and clean it a few times in places with solid particles.

  • Page 89: Electrical Maintenance

    User manual of RSPro series 3D printer After sanding, check by hand if the bottom is clean, otherwise repeat the second step. Step 4: Scraper return to zero In the RSCON interface, pull down the hardware control interface and click on the scraper to return to zero.

  • Page 90: Level System Maintenance

    User manual of RSPro series 3D printer Software maintenance: 1. The hardware driver adopts a conservative strategy. As long as the application is stable, the strategy must be updated carefully, and other software is not allowed to be installed on the work computer.

  • Page 91: Electrical Panel Maintenance

    User manual of RSPro series 3D printer 7.3.3 Electrical panel maintenance The appearance of the panel is kept tidy. Relays, contactors, circuit breakers, the appearance is kept clean, the contacts are intact, there is no overheating, the contactors are no noise, Check the cooling fan of the electric panel every month to ensure that the cooling fan can work normally without vibration and noise.
  • Page 92 User manual of RSPro series 3D printer Open hole in the part or change Cup mouth effect the building direction Foreign matter on the bottom surface Clean the bottom surface of blade of blade Building failure results in that the...
  • Page 93 User manual of RSPro series 3D printer Unstable temperature in the building Overhaul the air conditioning room system The bottom of part is The stabilizing time of scanner is not Start building half an hour after inclined enough the driver is powered on...
  • Page 94 User manual of RSPro series 3D printer (support building) Support is scratched with Take out the foreign matter on the a line during building Foreign matter on the bottom of blade bottom of blade (support building) The blade is too high...
  • Page 95 User manual of RSPro series 3D printer The emergency stop switch is turned Turn on the emergency stop The machine cannot be switch started The fuse is blown Replace it with spare fuse The vacuum pump is broken Replace the vacuum pump...
