  • Page 1 UT-PM-LCD-UM-2022-Mar Martrix Series User Manual...
  • Page 2 UT-PM-LCD-UM-2022-Mar...
  • Page 3 UT-PM-LCD-UM-2022-Mar Thank you for using our products! Third-party registered trademark: Shanghai Union Technology Corporation (UNIONTECK) declares that all trademarks are the property of their legal owners. Shanghai Union Technology Corporation hereby declares that, all the information provided in this document is correct at the time of printing, and subject to change due to improvements in performance and quality of the product without prior notice.
  • Page 4 UT-PM-LCD-UM-2022-Mar Foreword This Manual is a user manual designed for Martrix520/Martrix190 3D printer. It comprehensively describes main principles, technical, structural and design characteristics, precautions, and post processing of 3D printer, and contains guidelines for application and maintenance of equipment. Besides of hardware structure of equipment, this Manual also contains information about control system, data preparation software and optional post processing tools.

  • Page 5: Table Of Contents

    UT-PM-LCD-UM-2022-Mar Contents 1. Safety Alert ........................ 1 2. Introduction ........................2 2.1 Product Overview .................... 2 2.2 Packing list .......................3 3. The Touchscreen User interface .................5 3.1 Print Interface ....................5 3.2 Control Interface ....................5 3.3 Functional Interface ..................7 3.4 Hardware Interface ..................
  • Page 6 UT-PM-LCD-UM-2022-Mar 8.2 Precautions for daily operation and use .............34 8.1 Regular maintenance procedure ..............34 9. After-sales service & warranty .................36 FCC WARNING ......................37...

  • Page 7: Safety Alert

    UT-PM-LCD-UM-2022-Mar 1. Safety Alert 1) Receipt to determine the appearance and mechanical structure of the machine. 2) When removing the printed model from the platform with a shovel, be careful not to put your hand in the forward direction of the shovel. 3) In case of emergency, turn off the power of the machine directly.

  • Page 8: Introduction

    UT-PM-LCD-UM-2022-Mar 2. Introduction Product Overview The overall appearance of the machine is shown in Figure 2.1 below: Figure 2.1 Overall appearance of the machine The structure of the back of the machine is introduced as shown in Figure 2.2 below: WIFI interface main switch Cooling fan...

  • Page 9: Packing List

    UT-PM-LCD-UM-2022-Mar The internal structure of the Martrix machine is shown in Figure 2.3 below: Magnetic door switch Flashlight Pallet Filter fan Filter fan Thermomete Heating fan Camera Resin tank fixing handle Screen and mounting plate Display USB interface Power-on touch key Figure 2.3 Internal structure Packing list Name...
  • Page 10 UT-PM-LCD-UM-2022-Mar Metric Allen Wrench 1Unit 1.5/2.5/3/4/5#, for leveling pallets, changing Six-Piece Set screens, etc 200 mesh filter For filter resin Gloves 1Box To stay safe and clean U disk For test documents & model storage Tool Box For tools storage Watering Can For alcohol cleaning use（250ml）...

  • Page 11: The Touchscreen User Interface

    UT-PM-LCD-UM-2022-Mar 3. The Touchscreen User interface Dscon software is divided into four interfaces: printing interface, control interface, function interface, and hardware interface. There is an exit button at the top right of the interface. Print Interface Figure 3.1 below shows the printing interface of Dscon: Figure3.1 Print interface Hard Disk: The location where the print files are stored inside the machine;...
  • Page 12 UT-PM-LCD-UM-2022-Mar Figure3.2 Control interface 1) Action bar Move to the top: the pallet moves to the highest point of the z-axis; Stop motion: stop the motion part; Return to zero: the pallet moves to the lowest point of the z-axis; Set zero position: Set the zero position (the lowest point of the z-axis) when printing.

  • Page 13: Functional Interface

    UT-PM-LCD-UM-2022-Mar Functional Interface Figure 3.4 below shows the functional interface of Dscon: Figure 3.4 Function interface 1) Information bar Log: record the operating status of the machine; About: company information, software information. 2) Setting bar Basic settings: set language, etc.; Advanced settings: set the printing parameters of the machine, etc.
  • Page 14 UT-PM-LCD-UM-2022-Mar Lighting: The light inside the machine will be on long after the sliding door is pushed Heating: The heating fan starts to work to heat the resin in the resin tank; Screen: The 10.1-inch screen is a high-precision screen, and the 13.3-inch screen is a large-size screen.

  • Page 15: Workspace Preparation And Initial Setup

    UT-PM-LCD-UM-2022-Mar 4. Workspace Preparation and Initial Setup Resin Tank Membrane Change and Installation Instructions 1) Resin tank membrane replacement Remove the 8 screws of the fixed frame, the screw style is shown in Figure 4.1 below: Figure4.1 Remove the frame Figure4.2 Detached frame Take out the frame and remove the screws that fix the frame.

  • Page 16: Leveling

    UT-PM-LCD-UM-2022-Mar 2) Resin tank installation instructions Check whether the release film is intact. As shown in Figure 4.4 below: Figure4.4 Detection of release film Figure4.5 Orientation of resin tank Install the resin tank above the screen and tighten the wrench, paying attention to the orientation.
  • Page 17 UT-PM-LCD-UM-2022-Mar Figure4.8 Return to zero command Insert the attached feeler gauge (0.1mm) into the four corners of the pallet, as shown in Figure 4.9 below: Figure4.9 Detecting the gap between the pallet and the screen If the tightness of the four corners is the same and the feeler gauge is not easy to insert, there is no problem in leveling.
  • Page 18 UT-PM-LCD-UM-2022-Mar cannot be inserted into a corner, the corner of the pallet is too tight, then loosen the top screw and tighten the top screw. It should be noted that when adjusting the screw, the amplitude should not be too large to prevent the screen from being crushed. As shown in Figure 4.10: Figure4.10 Schematic diagram of top wire and wire drawing...

  • Page 19: Onboarding And First Print

    UT-PM-LCD-UM-2022-Mar 5. Onboarding and First Print Data processing software This section will introduce the installation of the data processing software Polydevs DLP, the function introduction of the software, and the use of the software. Polydevs is a data preprocessing software for additive manufacturing, 3D printing that makes it quick and easy to prepare and optimize printed parts, ensuring high-quality parts.

  • Page 20: Introduction To Polydevs Dlp Function Modules

    UT-PM-LCD-UM-2022-Mar as shown in Figures 5.3 and 5.4 . Figure 5.3 Figure 5.4 As shown in Figure 5.5 and 5.6, click Next and select the installation directory according to the prompts, the default is in the root directory of the C drive, and click the install button.
  • Page 21 UT-PM-LCD-UM-2022-Mar 5.8 below. 1.Top toolbar 5.Zoom control buttons 6.View toggle 2.Left toolbar buttons 3.Print platform 7.The view area of the object being printed 4.Coordinate 8.Bottom status bar Figure 5.8 Working interface 1．Top toolbar Includes file, edit, perspective, support, help. You can select the appropriate function according to your needs.

  • Page 22: Introduction To The Usage Process

    UT-PM-LCD-UM-2022-Mar 3．Print platform Places the printed part and displays the printable range of the machine. 4．Coordinate Displays the position of the current platform XZY three axes. 5．Zoom control buttons Zooms in and out of the platform field of view. The buttons from left to right are zoom in, restore, and zoom out, respectively.
  • Page 23 UT-PM-LCD-UM-2022-Mar 2) Import process packages Device: Select the saved models and process packages for direct application. New Device: Select the appropriate model and process package and save it as equipment for your next use. Package: Preset the optimization parameters corresponding to the material and model, and the printing parameters can not be adjusted additionally after application.
  • Page 24 UT-PM-LCD-UM-2022-Mar Click the " " button on the left ribbon, find the model file (.stl suffix) in the pop-up file manager window, double-click the file directly or click the Open button in the lower right corner to import the part. 4) Adjust the part Figure 5.11 After importing the part, the part needs to be positioned and bug fixed.
  • Page 25 UT-PM-LCD-UM-2022-Mar Figure 5.13 If the bottom of the part is not parallel to the bottom of the platform, click the specify the bottom surface - the bottom of the model, and then complete the adjustment. Figure 5.14 Click the to open the Model Location interface to adjust the placement of the model or directly drag the coordinate system on the model to adjust the model position.
  • Page 26 UT-PM-LCD-UM-2022-Mar Figure 5.15 Figure 5.16 The thickness Figure 5.17 The thickness of the shell is 1mm of the shell is 3mm 6) Honey Part Figure 5.18...
  • Page 27 UT-PM-LCD-UM-2022-Mar When shelling, select a face to be deleted, the inside will have the honeycomb structure filled, check the punch button, create holes inside the honeycomb structure, increase the flow of resin. It is recommended to use the honeycomb structure function when printing models with a flatter surface.
  • Page 28 UT-PM-LCD-UM-2022-Mar Bar Support & Only Baseboard ： Bar support generates supports and baseplates, and Only Baseboard generates only baseplates. Script ： Click to save the current parameters as the support script, click to delete the current support script, and click to set the current script as the default script.
  • Page 29 UT-PM-LCD-UM-2022-Mar different parts, so as to achieve the effect of saving material and strengthening stability, the bifurcation connection between the supports can provide better stability for the support, and the number of supports can be reduced to save materials. The following images 5.22 - 5.28 show the sample results generated by the command.

  • Page 30: On-Board Process

    UT-PM-LCD-UM-2022-Mar parameters for later calling, click the Auto Generate Support button to add support, and click the Edit Support button to manually adjust the support. Controls the hierarchical view Figure 5.30 When manually adjusting the support, you can slide the right side to control the hierarchical view button to see where you need to add support, use the left mouse button to click the location where you need to manually add support to add support anchor points, click the support anchor point to remove support, and click Discard...

  • Page 31: Disembarkation Process

    UT-PM-LCD-UM-2022-Mar After ensuring that all parameters on the machine are accurate, select the file to be printed in the U disk of the printing interface, and then click "Start". After clicking OK, the interface will display the information of the print file. After checking the information is correct, select "OK"...
  • Page 32 UT-PM-LCD-UM-2022-Mar Figure 5.4 Schematic diagram of shovel After the parts are printed, you need to select the "debris cleaning" function in the control interface to clean up the residue deposited in the resin tank. After the debris has been cleaned up, use the provided tweezers to pick up the flakes from the sides of the resulting flakes.
  • Page 33 UT-PM-LCD-UM-2022-Mar Figure5.6 Resin Filtration...

  • Page 34: Machine Screen Change Operation Method

    UT-PM-LCD-UM-2022-Mar 6. Machine screen change operation method This chapter will explain how to switch between the 10.1-inch and 13.3-inch screens of the Martrix520 machine. Remove the fixing screws In the Martrix520 machine, both the 10.1-inch screen and the 13.3-inch screen are fixed to the machine by four screws, so we first need to use an all-hex wrench to remove these four screws.

  • Page 35: Pallet Leveling

    UT-PM-LCD-UM-2022-Mar are applied, you need to manually check whether the screen is still shaking to make sure that the machine screen is fixed to death. Pallet leveling See Pallet Leveling in Section 4.2 for details. Adjust software parameters 1) After the above work is completed, the following operations need to be carried out in the software.

  • Page 36: Check The Screen

    UT-PM-LCD-UM-2022-Mar Check the screen After the above steps are completed in the "Control" command, select "Debris Cleanup" to see if the screen is intact. As shown in Figure 6.4 below: Figure 6.4 Check the screen Install the resin tank After all the above operations are complete, place the resin tank above the screen to make sure that the snap is aligned with the hole on the resin tank, and press the wrenches on both sides to make sure that the resin tank will not move again.
  • Page 37 UT-PM-LCD-UM-2022-Mar normally connection Turn the power switch on the The main power switch on the back of back to "I" printer is not turned on Replace the fuse and restart the The fuse system of printer blows out printer Program startup failed to find optical Check the connecting cable of the machine optical scanner...

  • Page 38: Troubleshooting Of Building Part

    UT-PM-LCD-UM-2022-Mar absorb resin during The negative pressure is not adjusted Adjust the negative pressure production properly Building failure results in that the blade Check support, process parameters Failure shutdown touches limit switch and blade, etc. Fault of liquid level balance system Check The liquid level in the resin tank is too Unstable liquid level...
  • Page 39 UT-PM-LCD-UM-2022-Mar unstable appropriately and print again Building resin is dampened, resulting in Replace resin and control ambient soft details humidity The post curing time or light intensity is Adjust post curing-related not enough parameters Light projection parameters are Softened structure of Adjust light projection parameters incorrect, and resin is not cured building part...

  • Page 40: Care & Maintenance

    UT-PM-LCD-UM-2022-Mar 8. Care & Maintenance Regular maintenance procedure Please refer to the following procedure for daily maintenance of the printer: 1) Confirm all switches are in off state and unplug all cables connected to the printer. 2) Wipe the whole building platform of printer with clean non-woven fabrics wetted with a little alcohol to clear off residual resin.
  • Page 41 UT-PM-LCD-UM-2022-Mar they are in good condition. 4) It's strictly prohibited to tear up, alter and move the nameplate and warning signs of the printer without permission. 5) Mechanisms of the printer must be inspected regularly for missing, lose or damaged parts. 6) Safety gears of the printer must be inspected regularly to ensure their functionality and stability.

  • Page 42: After-Sales Service & Warranty

    It's strictly prohibited for any organization or individual to pass on any data of Martrix520 or 190 printer to other organizations or individuals without written authorization of UnionTech, and relevant personnel shall be investigated for legal responsibility according to law once verified.

  • Page 43: Fcc Warning

    UT-PM-LCD-UM-2022-Mar FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 44 UT-PM-LCD-UM-2022-Mar should be installed and operated with minimum 20cm distance between the radiator and your body: Use only the supplied antenna.
