- Page 1 USER GUIDE PIVOT A32A For iPad Pro 11-inch (M4) [ Issued 04.21.2025 Version R02 ] Better Connection. Better Protection.
-
Page 2: Read Before Use
PIVOTcase.com to avoid damaging your device or case. NOTE: Your PIVOT case will hold your device firmly on all sides in order to protect it from accelerated impacts and other hazards. Once installed, your device is not intended to be easily removed. -
Page 3: Device Compatibility
PIVOT A32A DEVICE INSTALLATION Device Compatibility The PIVOT A32A is compatible with the features and accessories* for the iPad Pro 11-inch (M4). Supported Device: iPad Pro 11-inch (M4) Did You Know? Apple AirTag (optional, not included): It is recommended Apple AirTag is installed before installing device into case. -
Page 4: Installing Device
Installing Device Align the device camera and buttons with the corresponding access points in the case body and press the corners of the device into the case beginning with the camera and button area. The device will snap securely into the case’s perimeter seal. Pro Tip! If the case does not snap easily onto the device, double check the alignment of... - Page 5 Viewing Slots Assembly: Align the folio cover with the back of the PIVOT case as shown. Ensure the mounting plate is placed flat against the back of the case with the three slots directed towards the clip. Slide the folio into the mounting channel and secure with the clip.
- Page 6 Engage the flanges on the edge of the case with the viewing slots for superior stability. Using The Folio Cover The PIVOT A32A Folio Cover is easy and intuitive to use. Simply follow the instructions below when opening and closing the cover.
-
Page 7: Incorrect Use
WARNING! Do not use excessive force when using the Folio Cover. Do not bend the cover backwards over the PIVOT Clip. The Folio Cover is not intended to bend this way. This type of misuse can cause damage and is not covered under warranty. - Page 8 Locate the Center Finger Tab and lift gently. Apply Pro Tip! constant force while lifting to disengage the two Once open, adjust the angle of the PIVOT Snap-Closures, which are located to the left and Kickstand evenly on both sides to prevent right of the Center Finger Tab.
-
Page 9: Adjusting Viewing Angle
Adjusting Viewing Angle Adjust the viewing angle of the PIVOT Kickstand by rotating the left and right Legs of the kickstand evenly to the desired position. The PIVOT Kickstand Hinges provide a preset resistance force, which supports a range of viewing angles up to 120-degrees. - Page 10 You may hear an audible “click” when the closures engage with the case body. Incorrect Use The PIVOT Kickstand is durable if used as intended. However, it can be damaged if misused and put under repeated stress. Do not attempt to force the PIVOT...
- Page 11 WARNING! Do not use excessive force when opening, closing, or adjusting the kickstand, or attempt to force the kickstand beyond its intended range of motion. Damage resulting from such misuse is not covered under warranty.
- Page 12 Apple AirTag* to ensure both your device and PIVOT case are trackable anytime, anywhere. 1. Place the empty A32A case on a flat surface, facing upward with camera turret in upper left corner as shown. 2. Place the Apple AirTag* device into the provided AirTag Socket and gently press device into place as shown.
- Page 13 Screen Cover. Pencil Grip The Apple Pencil and similarly sized styluses snap firmly into the PIVOT Pencil Grip for secure storage when correctly installed in the orientation illustrated. The Pencil Tip Cradle* helps prevent accidental release of the Apple Pencil.
-
Page 14: Accessory Slots
PIVOT ACCESSORY SLOTS Accessory Slots This PIVOT case is compatible with select PIVOT accessories, such as the PIVOT Hand Strap. The Accessory Slots are located to the left and right of the clip with removable rubber inserts. Refer to the accessory product instructions for information on installation and removal of accessories. - Page 15 “CLICK.” 3. Depress the PIVOT Clip and reverse the process above to disconnect the case from the mount.
- Page 16 Incorrect Mount Alignment Shown below is an example of an incorrect alignment of the mounting plate and PIVOT case. The clip is not properly engaged with the mounting plate and is not holding the case in the locked position. The mounting plate is not fully inserted into the mounting channel and will not support the weight of the case and device.
-
Page 17: Getting Started
Before beginning any clip replacement Flex procedure, please ensure you have a Spring compatible PIVOT Clip Kit. The PIVOT A32A case uses the PCK-2 Assembly, Gen PIVOT Clip 2.0. It is not compatible with older versions of the PIVOT clip. Required: 1 Unit PCK-2 Assembly, Gen 2.0... - Page 18 Removing Hinge and Clip c) With one hand, hold the clip firmly against the case, apply even pressure to the clip. d) Using pliers with other hand, pull the hinge pin out. (Be careful, the clip is under spring tension.) e) Remove clip while holding the spring in place.
-
Page 19: Tech Specs
TECH SPECS (For Reference Only) Orthographic Views: Interior View:... -
Page 20: Additional Information
Thank you. Additional Information To learn more about your PIVOT case, please visit pivotcase.com for instructional videos, product support and additional information about PIVOT products. You’ll find valuable online resources provided to enhance your user experience and see the complete line of PIVOT products.
