- Page 1 ADVANCE RELEASE! (Product coming F/W 2017) User Guide OMNI 97 For iPad 9.7”, iPad Pro 9.7” and iPad Air 2 Better Connection. Better Protection. [ Issued 09.07.2017. Version R1 ]...
-
Page 2: Read Before Use
PIVOT products maximize protection and minimize the need to remove the device from your PIVOT case. If you need to remove your device, please refer to this document or visit PIVOT online for instructions to avoid unnecessary damage to your device and PIVOT case. -
Page 3: Device Compatibility
The PIVOT OMNI 97 is a multi-generational device solution. With the use of the PIVOT Universal Spacer, the OMNI 97 fits the Apple™ iPad 9.7”, iPad Pro 9.7” and the Air 2. Features such as camera, audio jack openings and button access have been shifted to accommodate the various locations of these features across the di erent devices. -
Page 4: Installing Device
Installing Device Align device camera and buttons with the corresponding access points in the case body and press the corners of the device into the case in the order shown. The device will snap securely into the case’s perimeter seal. Pro Tip! Open the ID window and write your info on the ID card before... - Page 5 Keyboard Compatible To convert for use with the Apple™ Smart Keyboard, simply remove the protective side edge to reveal the Smart Connector. Using your thumb and forefinger, begin disengaging the clips by gripping the side edge firmly and rocking with mild force until the clip gently unlocks. Start with one end and continue releasing the clips as you move across the full length.
- Page 6 (Viewing Slots) Assembly: Align the folio cover with the back of the Pivot case as shown. Ensure the folio’s mounting plate is placed flat against the back of the case with the three slots directed towards the clip. Slide the folio into the mounting channel and secure with the clip.
- Page 7 Kickstand Hinge Use your folio cover for convenient viewing in four di erent angles. Open the folio cover and fold into the position show. Engage the flanges on the edge of the case with the viewing slots for superior stability. Label Area 1/2”...
- Page 8 Using The Folio Cover The OMNI 97 Folio Cover is easy and intuitive to use. Simply follow the instructions below when opening and closing your cover. 1. Release the folio latch at the front right edge 2. Open the cover 3.
-
Page 9: Incorrect Use
WARNING! Do not use excessive force when using the Folio Cover. Do not bend the cover backwards over the Pivot Clip. The Folio Cover is not intended to bend this way. This type of misuse can cause damage and is... - Page 10 PIVOT Mount. Universal Mounts Your PIVOT case is designed to work with a wide variety of patented PIVOT Mounting Solutions. Prior to connecting the PIVOT case to the mount, confirm the mount is in the correct location and is fully secure.
- Page 11 “Click!” Incorrect Mount Alignment Shown below is an example of an incorrect alignment of the mounting plate and PIVOT case. The clip is not properly engaged with the mounting plate and is not holding the case in the locked position. The mounting plate is not fully inserted into the mounting channel and will not support the weight of the case and device.
-
Page 12: Getting Started
Before beginning any clip replacement Flex procedure, please ensure you have a Spring compatible Pivot Clip Kit. The PIVOT OMNI 97 case uses the PCK-2 Assembly, Pivot Clip Gen 2.0. It is not compatible with older version of the PIVOT clip. Required: 1 Unit PCK-2 Assembly, Gen 2.0... - Page 13 Pro Tip! After the hinge pin has been removed, relieve pressure on the clip slowly until the spring is no longer under tension. This will ensure the clip and spring can be removed safely. Remove Hinge and Clip c) With one hand, hold the clip firmly against the case, apply even pressure to the clip. d) Using pliers with other hand, pull the hinge pin out.
-
Page 14: Tech Specs
TECH SPECS (For Reference Only) Orthographic Views: 248.40 20.55 20.55 124.19 177.85 88.93 44.13 4.46 53.00° Center axis of PIVOT rotation Interior View:... -
Page 15: Additional Information
Thank you. Additional Information To learn more about your PIVOT case, please visit pivotcase.com for instructional videos, product support and additional information about PIVOT products. You’ll find valuable online resources provided to enhance your user experience and see the complete line of PIVOT products.
