This machine is not suitable for minors to
use or food processing.
This machine could transfer photos,words on
cotton, fiber, metal, ceramic, glass etc. suitable
for producing gift, advertisement etc.
Technical Parameters:
Machine Type: Cap&Label Heat Press
Application: Cap, Label, etc.
Voltage: 110V/220V
Power: 0.7kW
Time Range: 0~999 sec.
Max. Temp.: 245°C (473°F)
Heating Element: 12"x15"
Package Size: 63*48*36cm
G.W: 18kg
Usage
1.Connect with power plug, turn on power switch, the indicator light works, then you can set your desired right temp and time.
2. After set, the machine will heat up(200℃ about 15 minutes)
3. Raising up handle, place printing materials on working table, try for a right pressure.
4. When machine reaches the set temp, then place the printing materials on working table, press down the handle, then push the time clock, when reaching
the set time, the machine sounds, then lift up the handle and take out the printing materials.
brildor.com
③
⑦
④
Cap Heat Press Machine
1
②
①
CP3815
① Handle Grip
⑥
② Pressure Knob
③Swing-arm
④ Heat Platen
⑤ Under Platen
⑥ LCD Control Panel
⑦ Wing Nut
⑤
Advertisement
Related Manuals for Brildor CP3815
Summary of Contents for Brildor CP3815
- Page 1 Package Size: 63*48*36cm G.W: 18kg Cap Heat Press Machine CP3815 Usage 1.Connect with power plug, turn on power switch, the indicator light works, then you can set your desired right temp and time. 2. After set, the machine will heat up(200℃ about 15 minutes) 3.
- Page 2 Add a little lubricating oil into screw connection Pressure know is hard to adjust Heating Platen does not work Faulty in controller/ solid relay/ heating element Hard to lift heating platen Outer clockwise adjust pressure knob Alarm does not sound Controller problem or time switch broken brildor.com...
